WHEELTRONICS 7144 Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0248 1/2" Flat Washer
2 6-0059 1/2" Lock Washer
3 6-0035 1/2"-13 Hex Nut
4 6-1134 Self Tap. Screw, #12 x 1/2"
5 6-0267 Cotter Pin, 1/8" x 1"
6 6-0996 ALI/ETL Decal
7 6-1583 "Hydraulic Leveling" Decal
8 6-0206 Shoulder Bolt, 3/8" x 1"
9 1-0938 Safety Pin
10 1-0415 Safety Pulley
11 1-1115 Safety Spring
12 6-0808 51/64" Flat Washer
13 6-1135 Plastic Knob
14 3-0439 Safety Cover
15 1-1113 Safety Release Handle
16 2-0902 Safety Dog, L.H.
17 1-1291 Cable Connecting Bracket
18 6-0737 Hex Nut, 3/4"-10
19 6-0738 Flat Washer 3/4"
20 6-1379 3/4" x 5-1/2" Anchor
21 6-0027 Hex Bolt, 1/4"-20 x 1-1/4"
22 6-0626 1/4" Fender Washer
23 1-0939 Plunger Spring
24 4-0316 Tower, L.H.
25 1-0745 Pivot Plunger
26 6-0000 Grease Fitting
27 6-0437 Roll Pin, 1/8" x 1"
28 2-0249 Rack
29 1-0208 Knob
30 1-1135 Trd. Rod, 3/8"-16 x 1-1/2"
31 3-0561 Outer Arm Tube, R.H.
32 3-0562 Outer Arm Tube, L.H.
33 4-0464 Locking Arm Assembly, R.H.
34 4-0463 Locking Arm Assembly, L.H.
35 2-1088 Short Inner Arm
36 3-0560 Outer Arm Tube, R.H.
37 3-0559 Outer Arm Tube, L.H.
38 4-0462 Locking Arm Assembly, R.H.
39 4-0461 Locking Arm Aseembly, L.H.
40 2-1086 Inner Arm
41 1-1099 Center Pin
42 1-1091 Adapter Pin
43 3-0582 High Step Position Adpt.
44 3-0583 Low Position Adpt.
45 1-0263 Arm Stop
46 6-0339 Hex Bolt, 1/4"-28 x 5/8"
47 6-0056 Lock Washer, 1/4"
48 2-0439 Arm Pin
49 6-0423 Hex Bolt, 5/16"-18 x 3/4"
50 4-0317 Tower, Rt. Side
51 6-0069 Shoulder Bolt, 3/8" x 5/8"
52 0-0203 Safety Cover with Decals, R.H.
53 6-0594 "Safety Instructions" Decal
54 2-0872 Safety Dog & Spring, Power Side
55 1-1119 Carriage Stop
56 3-0449 Extension, R.H.
57 6-0294 Hex Nut, 5/16"-18
58 1-1116 Safety Cable Pulley
59 6-0908 Shoulder Bolt, 3/8" x 1-1/4"
60 1-1305 Safety Release Cable, 285-1/2
61 6-0291 Hex Bolt, 1/2"-13 x 1-1/2"
62 3-0450 Extension, L.H.
63 6-0595 "Warning" Decal
64 6-0592 "Caution" Decal
65 6-0603 "Saftey Release" Decal
67 6-1230 Eq. Cable Clip, 3/8"
68 6-1118 Serial # Tag
69 4-0420 Carriage, R.S.
70 2-0772 Slider Block
71 4-0424 Carriage, L.S.
72 6-0438 Set Screw, 1/4"-20 x 1/2"
73 2-0883 Tower Brace
74 1-1380 Actuator Bar
75 6-1404 Foam Guard
76 3-0440 Crossmember
77 6-1403 Electrical Utility Box
78 6-0916 Microswitch
79 1-1379 Actuator Extension
80 6-1133 Cable Connector
81 6-1173 Eq. Cable, 16/3 x 117"
82 6-0032 Hex Hd. Nut, 1/4"
83 6-0178 Hex Hd. Bolt, 1/4" x 3/4"
84 6-0056 Lock Washer 1/4"
86 6-0767 Hex Bolt, 1/2"-13 x 2-1/2"
87 0-0204 Safety Cover with Decals, L.H.
90 6-0169 Self Tap. Screw #10 x 3/8"
91 6-0295 Flat Washer 5/16"
92 6-0296 Lock Washer 5/16"
93 6-0185 Shoulder Bolt, 5/16" x 1/4"
94 1-0333 Pivot Pin
95 1-1378 Actuator Mtg. Bracket
96 2-1143 Limit Switch Mtg. Bracket
97 6-0177 Hex Hd. Bolt, 1/4" NC x 2"
98 6-1466 6/32" Screw (Electric Box)
99 6-0027 Hex Hed. Bolt, 1/4" x 1-1/4"



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0881 Microswitch
2 6-1084 Microswitch Boot
3 6-0773 Motor 230 Vac. 1 PH. 60 Hz.
4 0-0197 Motor Adapter Kit
5 6-1085 Skt. Hd. Capscrew 1/4"-20 x 5/8"
6 6-0056 Lock Washer, 1/4"
7 6-1086 Allen Flat Screw 1/4"-20 x 3/4"
8 6-0774 Coupling
9 6-0776 Release Bracket & Handle Assembly
10 6-0880 Valve Cartridge Release
11 6-1087 Valve Cartridge Check
12 6-1317 Fixed Relief Valve, RV 17
13 6-1089 Relief Valve Cap
14 6-0875 Reservoir "O" Ring
15 6-0782 Pump Assembly
16 6-1090 Pump Mounting Bolt
17 0-0198 Inlet Plumbing Kit
18 6-0786 Inlet Hose/Filter Assembly
19 0-0199 Pump "O" Ring Kit
20 6-0783 Return Tube
21 6-1376 Breather-Filler Cap (Plastic)
22 6-1399 Reservoir (Plastic)
23 6-1091 Reservoir Screw
24 6-1133 Cable Connector, 90, 3/8"



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0012 Blkhd. 90 3/8" JIC
2 6-0345 Adpt, 3/8" NPT-3/8" JIC x 2-1/4"
3 6-0286 Union, 3/8" JIC Male
4 0-0162 Gland Seal Kit, R.H.
5 6-0056 Lock Washer, 1/4"
6 2-0716 Hydraulic Tube Assembly
7 2-0801 Piston Tube, R.H.
8 3-0430 Hydraulic Cyl. Assembly, R.H.
9 6-0284 Tee. 3/8" Swivel Nut JIC Male
10 6-0021 Cap. 3/8" JIC
11 6-0580 Hd. Setscrew, 1/4" x 3/8"
12 2-0619 Piston
13 0-0159 Piston Seal Kit, R.H.
14 1-0725 Keeper Washer
15 1-0102 Hydraulic Tube Assembly
16 6-0425 Shoulder Bolt 1/2" x 5/8"
17 2-1140 Hydraulic Tube Assembly
18 6-0804 Elb. 90 9/16" SAE M-3/8" JIC M
19 6-0293 Hex Bolt, 5/16"-18 x 1"
20 6-0061 Flat Washer 5/16"
21 6-1146 Power Pack
22 6-1265 "Lift Operations" Decal
23 6-0028 Hex Hd. Bolt 1/4-20 x 1-3/4"
24 1-0734 Felt Strip (nla)
25 1-1341 Hydraulic Hose Assembly
26 2-0878 Hydraulic Tube Assembly
27 2-0886 Hydraulic Tube Assembly
28 6-0422 Velocity Fuse, 4 GPM
29 6-1362 Hydraulic Valve Block
30 2-0888 Hydraulic Tube Assembly
31 6-1372 Branch "T" JIC All Ends
32 3-0428 Cylinder Barrel, L.H.
33 6-0631 Uni-Torque Locknut, 7/8"-9
34 2-0521 Piston Spigot
35 0-0160 Piston Seal Kit, L.H.
36 2-0793 Piston Rod, L.H.
37 0-0206 Gland Seal Kit, L.H.
38 4-0289 Hydraulic Cylinder Assembly, L.H.
39 2-0879 Hydraulic Tube Assembly
40 6-0340 Circlip
41 2-0802 Cylinder Barrel, R.H.
42 6-0674 Lock Washer 5/16"
43 6-0294 Hex Nut 5/16"-18
44 6-1353 Rnd. Hd. Bolt, 1/4"-20 x 3/8"
45 6-0170 Tube Clamp
46 2-0887 Hydraulic Tube Assembly
47 6-1389 Hydraulic Vave Block Assy. (C/W Fittings)
51 6-0281 Adpt, 1/4" NPT. M-1/4" JIC M
53 6-0276 Adpt., 1/4" NPT. M-3/8" JIC M
