WHEELTRONICS 7012 Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 4-0165 Medium Locking Arm Assembly (R.S.)
2 4-0263 Short Locking Arm Assembly (Right Side)
3 6-0901 Hex Bolt
4 6-0032 Hex Nut
5 6-0060 Flat Washer
6 1-0939 Plunger Spring
7 1-0333 Pivot Pin
8 1-0334 Pivot Plunger
9 6-0437 Roll Pin, 1/8 X 1 Lg.
10 2-0249 Rack
11 6-0438 Set Screw
12 1-0387 Threaded Rod, 3/8-16 Unc X 1 1/2"Lg.
13 1-0208 Knob
14 4-0232 Tower Weldment, Right Side
15 1-0415 Safety Cable Pulley
16 6-0069 Shoulder Bolt
17 3-0097 Tower Support Angle, Right Side
18 1-0941 Safety Cable
19 6-0478 Wheel Decal
19 6-0908 Shoulder Bolt
20 2-0690 Safety Cover
21 6-0505 Self Taping Screw
22 2-0686 Safety Dog Weldment Right Side
23 1-0938 Safety Pin
24 6-0267 Cotter Pin 1/8 Dia. X 1 Lg.
25 6-0907 Shoulder Bolt
26 6-0294 Hex Nut
27 1-0940 Safety Spring
28 6-0169 Self Taping Screw
29 6-0035 Hex Nut
30 6-0059 Lock Washer
31 1-0877 Carriage Stop
32 6-0767 Hex Bolt
33 6-0861 Flat Hd. Screw
34 6-0084 Self Lube Bearing
35 2-0694 Chain Cut To Size
36 2-0740 Wheel Chain
37 2-0674 Fork Welding (Right Side)
38 6-0921 1/8- Npt, 90 Degree, Grease Fitting
39 1-0932 Fork Pin Welded
40 6-0126 Hex Bolt
41 6-0056 Lock Washer
42 3-0218 Adjustable Truck Pad Assembly (Opt.)
43 3-0194 Standard Truck Pad
44 3-0170 Low Lifting Pad Neoprene (Optional)
45 2-0304 Low Lifting Pad
46 2-0732 Tower Brace
47 4-0176 Medium Locking Arm Assembly (L.S.)
48 4-0231 Short Locking Arm Assembly (L.S.)
49 3-0388 Safety Rack Welding (Right Side)
50 6-0423 Hex Bolt
51 6-0664 Hex Nut
52 2-0439 Arm Pin
53 6-0246 Shoulder Bolt
54 2-0661 Link Fork
55 4-0228 Tower Weldment
56 4-0229 Carriage Weldment (Right Side)
57 2-0696 Extension Bracket (Right Side)
58 2-0697 Cable Micro Switch Assembly
59 3-0389 Safety Rack Welding (Left Side)
60 6-0862 Flat Hd Sock Screw
61 6-0551 Self Lube Bronze Bearing
62 6-0290 Hex Bolt
63 3-0403 Cross Member Weldment
64 6-0479 Free Decal
65 2-0677 Fork Welding (Leftside)
66 4-0225 Carriage Weldment (Left Side)
67 6-0233 Retaining Ring, 1 3/8 I.D.
68 6-0629 Self - Lubricating Bushing
69 2-0530 Carriage Wheel Assembly
70 2-0685 Safety Dog Weldment (Left Side)
71 3-0096 Tower Support Angle Left Side
72 6-0047 Hex Bolt
73 6-0736 Wedge Anchor
74 6-0738 Flat Washer
75 6-0737 Hex Nut
76 2-0293 Safety Release Handle
77 6-0295 Plain Washer
78 6-0591 Shoulder Screw
79 1-0259 Cable Connecting Bracket
80 6-0032 Hex Nut
81 6-0863 Serial No. Plate
82 6-0398 Ali Plate
83 6-0592 Caution Decal
84 2-0721 Extension Weldment (Left Side)
85 1-0262 Arm Stop (Top)
86 1-0263 Arm Stop (Side)
87 2-0192 Inner Arm Medium
88 2-0695 Inner Arm Short
89 3-0315 Outer Arm Weldment, Medium (R.S.)
90 3-0318 Outer Arm Weldment, Medium (L.S.)
91 3-0313 Outer Arm Weldment, Short (R.S.)
92 3-0316 Outer Arm Weldment, Short (L.S.)



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0860 Power Pack 220v, 1 Ph.
2 6-0674 Lock Washer
3 6-0423 Hex Bolt
4 6-0804 9/16-18 Male To 3/8 J!C Male 90 Elbow
5 1-0942 Tube Assembly To Power Pack
6 1-0725 Keeper Washer
7 0-0159 Piston Seal Kit ( Right Side)
8 6-0580 Allen Hd. 1/4- 20 Unc 3/8 Lg. Set Screw
9 2-0664 Piston Tube (Right Side)
10 1-0734 Felt Strip (Right Side)
11 0-0162 Gland Kit Right Side
12 2-0662 Cylinder Barrel Weldment Right Side
13 6-0425 Shoulder Screw
14 6-0102 Plug
15 6-0284 Tee 3/8 Swivel Nut
16 6-0021 Cap 3/8 Jic
17 6-0536 Tube Clamp
18 6-0169 #10- 3/8 Lg. Self Taping Screw
19 2-0717 Tube Assembly 3/8 I.D.
20 3-0404 Tube Assembly 3/8 I.D. (7012)
21 3-0398 Tube Assembly 1/4 I.D.
22 6-0278 Elbow
23 3-0399 Tube Assembly 1/4 I.D.
24 6-0911 Velocity Fuse 2 Gpm
25 6-0631 Uni-Torque Lock Nut
26 2-0521 Piston Spigot
27 0-0160 Piston Seal Kit (Left Side)
28 2-0669 Piston Rod Weldment (Left Side)
29 0-0182 Gland Seal Kit (Left Side)
30 6-0866 Elbow
31 4-0227 Hydraulic Cylinder AssY Left Side
32 3-0376 Hydraulic Cylinder Assy Right Side
33 6-0281 Adapter 1/4 M, Jic 1/4 M, Npt
34 6-0277 Pilot Operated Check Valve
35 6-0276 Adapter, 1/4 M, Npt, 3/8 M, Jic
36 6-0011 Adapter, 3/8 M, Npt, 3/8 M, Jic
37 3-0400 Hydraulic Fitting Assembly
38 1-0102 Tube Elbow
39 2-0719 Tube Assembly
40 6-0090 Flow Control
41 6-0270 Adapter, 1/4npt M - 3/8npt M
42 6-0274 Elbow
43 6-0271 Tee, 1/4 M. Npt, 1/4 F. Npt
44 6-0272 Ball Valve
45 1-0281 Tube Assembly, 3/8 I.D.
46 1-0280 Tube Assembly, 1/4 I.D.
47 6-0294 Hex Nut
48 6-0593 Lift Operating Decal
49 6-0594 Notice Decal
50 6-0595 Warning Decal
51 2-0707 Tube Assembly, 1/4 I.D.
52 2-0716 Tube Assembly 3/8 I.D. (7012)
53 6-0286 Union 3/8 Jic M.
54 2-0717 Tube Assembly 3/8 I.D. (7012)
55 6-0922 90 Degree Elbow
56 6-0721 90 Degree Elbow



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0881 Microswitch
2 6-1084 Microswitch Boot
3 6-0773 Motor 230 Vac, 1ph, 60 Hz
4 0-0197 Motor Adapter Kit
5 6-1085 Socket Hd.Cap Scw, L/4"-20unc X 5/8lg.
6 6-0056 Lockwasher
7 6-1086 Allen Hd. Flat Scw, L/4-20unc X 3/4lg.
8 6-0774 Coupling
9 6-0776 Release Bracket & Handle Assembly
10 6-0880 Valve Cartridge Release
11 6-1087 Valve Cartridge Check
12 6-1326 Fixed Relief Valve, Rv26
13 6-1089 Relief Valve Cap
14 6-0875 Reservoir 0"Ring
15 6-0782 Pump Assembly
16 6-1090 Pump Mounting Bolt
17 0-0198 Inlet Plumbing Kit
18 6-0786 Inlet Hose / Filter Assembly
19 0-0199 Pump 0" Ring Kit
20 6-0783 Return Tube
21 6-0873 Breather-Filler Cap
22 6-0871 Reservoir
23 6-1091 Reservoir Screw
24 6-1133 Cable Connector, 90, 3/8
