WHEELTRONICS 7010 Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 4-0165 Medium Locking Arm Assembly (R.S.)
2 4-0230 Short Locking Arm Assembly (R.S.)
3 6-0901 Hex Bolt
4 6-0032 Hex Nut
5 6-0060 Flat Washer
6 1-0939 Plunger Spring
7 1-0333 Pivot Pin
8 1-0334 Plunger Pin
9 6-0437 Roll Pin, 1/8 X 1lg.
10 2-0249 Rack
11 6-0438 Set Screw
12 1-0387 Threaded Rod, 3/8-16 Unc X1 1/2 Lg.
13 1-0208 Knob
14 4-0232 Tower Weldmentfright Side
15 1-0415 Safety Cable Pulley
16 6-0069 Shoulder Bolt
17 3-0097 Tower Support Angle Right Side
18 1-0927 Safety Cable
19 1-0766 Cable Roller
20 6-0907 Shoulder Bolt
21 2-0690 Safety Cover
22 6-0505 Self Tap Screw
23 2-0686 Safety Dog Welding, Right Side
24 1-0938 Safety Pin
25 6-0267 Cotter Pin 1/8 Dia. X 1lg.
26 6-0907 Shoulder Bolt
27 6-0294 Hex Nut
28 1-0940 Safety Spring
29 6-0169 Self Tap Screw
30 6-0035 Hex Nut
31 6-0059 Lock Washer
32 1-0877 Carriage Stop
33 6-0767 Hex Bolt
34 6-0861 Fiat H.D. Sock Cap Screw
35 6-0084 Self Lube Bearing
36 2-0694 Chain Cut To Size
37 2-0740 Wheel Chain
38 2-0674 Fork Welding (Right Side)
39 6-0921 1/8- Npt. Grease Fitting, 90 Degrees
40 1-0932 Fork Pin Welding
41 6-0126 Hex Bolt
42 6-0056 Lock Washer
43 3-0218 Adjustable Truck Pad Assy (Options)
44 3-0194 Standard Truck Pad (Options)
45 3-0170 Low Lifting Pad Neoprene (Options)
46 2-0304 Low Lifting Pad
47 2-0732 Tower Brace
48 4-0176 Mediuim Locking Arm Assy (Left Side)
49 4-0231 Short Locking Arm Assy (Left Side)
50 6-0423 Hex Bolt
51 6-0664 Hex Nut
52 2-0439 Arm Pin
53 6-0246 Shoulder Bolt
54 2-0661 Link Fork
55 4-0228 Tower Weldment Assy (Left Side)
56 4-0229 Carriage Weldment (Right Side)
57 6-0479 Free Decal
58 3-0388 Safety Rack Welding (Right Side)
59 6-0045 Hex Bolt
60 3-0389 Safety Rack Welding (Left Side)
61 6-0862 Flat Hd Sock Cap Screw
62 6-0551 Self-Lube Bronze Bearing
63 6-0036 Hex Nut
64 6-0064 Flat Washer
65 6-0316 Wedge Anchor
66 2-0677 Fork Welding (Left Side)
67 4-0225 Carriage Weldment (Left Side)
68 6-0233 Retaining Ring, For Wheel 1 3/8 I.D.
69 6-0629 Self-Lubricating Bushing
70 2-0530 Carriage Wheel Assy
71 4-0226 Base Weldment
72 3-0096 Tower Support Angle, Left Side
73 6-0047 Hex Bolt
74 6-0736 Weld Anchor
75 6-0738 Flat Washer
76 6-0737 Hex Nut
77 2-0293 Safety Release Handle
78 6-0295 Plain Washer
79 6-0591 Shoulder Screw
80 1-0259 Safety Link L Shape
81 6-0032 Hex Nut
82 2-0685 Safety Dog Weldment (Left Side)
83 6-0863 Serial No. Plate
84 6-0398 Ali Plate
85 6-0592 Caution Decal
86 6-0480 Tronic Decal
87 6-0478 Wheel Decal
88 1-0263 Arm Stop (Side)
89 1-0262 Arm Stop (Top)
90 3-0315 Medium Outer Arm Welding (Right Side)
91 3-0318 Medium Outer Arm Welding (Left Side)
92 3-0313 Right Side Short Outer Arm
93 3-0316 Left Side Short Outer Arm
94 2-0192 Medium Inner Arm Welding
95 2-0695 Short Inner Arm Welding
96 2-0760 Microswitch Assy
97 1-0986 Microswitch Shut-Off Assy



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0860 Power Pack 220v, 1 Ph
2 6-0674 Lock Washer
3 6-0423 Hex Bolt
4 6-0804 9/16-18 Male To 1/4 Jic, Male 90 Elbow
5 1-0942 Tube Assembly To Power Pack
6 1-0725 Keeper Washer
7 0-0159 Piston Seal Kit (Right Side)
8 6-0580 Allen Hd 1/4- 20- Unc 3/8lg. Set Screw
9 2-0664 Piston Tube (Right Side)
10 1-0734 Felt Strip (Right Side)
11 0-0162 Gland Kit (Right Side)
12 2-0662 Cylinder Barrel Weldment
13 6-0425 Shoulder Screw
14 6-0371 Plug
15 6-0813 3/8 Jic, Swivel To 3/8 Jic M, 90 Elbow
16 2-0705 Tube Assembly To Base
17 6-0536 Tube Clamp
18 6-0169 #10- 3/8lg. Self-Tapping Screw
19 6-0286 Union, 3/8m, Jic, 3/8m, Jic
20 3-0397 Tube Assembly 3/8 I.D.
21 3-0398 Tube Assembly 1/4 I.D.
22 6-0278 Elbow
23 3-0399 Tube Assembly, 1/4 I.D.
24 6-0911 Velocity Fuse, 2 Gpm.
25 6-0631 Uni-Torque Lock Nut
26 2-0521 Piston Spigot
27 0-0160 Piston Seal Kit, Left Side
28 2-0669 Piston Rod Weldment, Left Side
29 0-0182 Gland Seal Kit, Left Side
30 6-0866 Elbow
31 4-0227 Double Acting Cylinder Assy, Left Side
32 3-0376 Hydraulic Cylinder Assy, Right Side
33 6-0281 Adapter, 1/4m, Jic 1/4"M, Npt
34 6-0277 Pilot-Operated Check Valve
35 6-0276 Adapter, 1/4m, Npt 3/8M, Jic
36 6-0011 Adapter, 3/8m, Npt 3/8m, Jic
37 3-0400 Hydraulic Fitting Assembly
38 1-0102 Tube Elbow
39 6-0345 Adapter, 3/8 Npt M X 3/8 Jic X 2 1/4lg.
40 6-0910 Flow Control
41 6-0720 Adapter, 3/8m, Npt, 1/4f, Npt
42 6-0274 Elbow
43 6-0271 Tee, 1/4m, Npt, 3/8f, Npt
44 6-0272 Ball Valve
45 1-0281 Tube Assembly, 3/8 I.D.
46 1-0280 Tube Assembly, 1/4 I.D.
47 6-0294 Hex Nut
48 6-0593 Lift-Operating Decal
49 6-0594 Notice Decal
50 6-0595 Warning Decal
51 2-0707 Tube Assembly, 1/4 I.D.
52 6-0721 Elbow



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0773 Motor Ac 230v
2 6-0774 Coupling
3 6-0775 Wiring Assembly Ac
4 6-0776 Bracket Release
5 6-0867 Valve Assembly Release
6 6-0868 Relief Assembly
7 6-0779 O Ring
8 6-0780 Filter Assembly
9 6-0781 O Ring
10 6-0869 Pump With Cover
11 6-0870 Return Tube
12 6-0784 Breather Plastic
13 6-0871 Reservoir (3.25 Liter)
14 6-0872 Plumbing Assembly Inlet
