SUN EELR132AJK Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 3-0842 Base Frame Weldment
2 3-0824 Outer Scissor Weldment
3 3-0825 Inner Scissor Weldment
4 6-0807 Washer
5 1-2270 Scissor Center Shaft
6 1-1159 Center Pipe Spacer
7 6-0146 Spring Pi, 3/16 X 2 Lg
8 6-2230 Bushing
9 6-0328 Thrust Washer
10 1-1269 Cam Follower
11 1-0228 Spacer
12 6-0040 Jam Nut
13 2-1586 Scissor Pin
14 6-0056 Lockwasher
15 6-0554 Hex Hd Bolt
16 3-0725 Top Weldment
17 1-1997 Roller Assembly
18 1-1998 Roller Shaft
19 2-1572 Lifting Arm Weldment
20 6-0030 Hex Hd Bolt
21 6-0058 Lockwasher
22 1-2045 Stack Pad Assembly Complete
23 1-2030 Stack Pad Weldment
24 6-2050 Rubber Pad
25 6-0178 Hex Hd Bolt
26 1-1993 Stack Pad Adapter, 3"
27 2-1580 Stack Pad Adapter, 6"
28 3-0474 Cylinder Assembly Complete
29 1-1767 Velocity Fuse
30 2-0911 Cylinder Tube Weldment
31 1-1152 Gland
32 6-0653 Rod Wiper
33 6-0581 Snap Ring
34 1-1148 Keeper Washer
35 6-1166 Seal And Wear Ring
36 1-1150 Piston
37 2-0913 Piston Rod Weldment
38 1-1158 Outside Cylinder Shaft
39 1-1163 Inside Cylinder Shaft
40 2-1577 Safety Stop Weldment
41 1-0561 Safety Pin
42 6-0438 Set Screw
43 6-0671 Clip
44 1-2271 Safety Lever Arm
45 6-0251 Knob
46 2-1585 Guard Rail
47 6-0008 Hex Hd Bolt
48 6-0060 Flat Washer
49 6-0032 Hex Nut
50 2-0259 Roller Assembly Complete
51 6-0206 Shoulder Bolt
52 6-0223 Thrust Washer
53 2-0098 Track Roller Assembly
54 6-0224 Thrust Washer
55 1-0204 Spring Stem
56 6-0081 Spring
57 6-0042 Nylon Locknut
58 1-0765 Hydraulic Hose
59 1-1062 Flow Control
60 3-0841 Roller Adapter
61 6-1353 !4-20unc X 3/8 Lg
  6-1428 Air/Hydraulic Pump Complete
  3-0826 Scissor Assembly Complete
  6-0015 Street Tee
  6-0710 Npt To 3/8 Polytube
  6-0536 Tube Clamp
  6-0967 90 Elbow



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-2332 Filler Plug
2 6-2333 Screw
3 6-2334 Clamp
4 6-2335 Pump Housing
5 6-2336 Bladder
6 6-2337 Pump Body
7 6-2338 Valve Screw
8 6-2339 Copper Washer
9 6-2340 U-Cup
10 6-2341 Compression Spring
11 6-2342 Retainer
12 6-2343 Bumper
13 6-2344 Spring Guide
14 6-2345 Piston Ring
15 6-2346 O-Ring
16 6-2347 Gasket
17 6-2348 Piston End Casting
18 6-2349 Piston Poppet
19 6-2350 Compression Spring
20 6-2351 Flat Hd Screw
21 6-2352 Soc. Hd Screw
22 6-2353 Lockwasher
23 6-2354 Piston Body
24 6-2355 Exhaust Valve System
25 6-2356 O-Ring
26 6-2357 Compression Spring
27 6-2358 Rear Head
28 6-2359 Screw
29 6-2360 O-Ring
30 6-2361 Piston
31 6-2362 Compression Spring
32 6-2363 Steel Ball
33 6-2364 Steel Ball
34 6-2365 Plug
35 6-2366 Relief Valve
36 6-2367 End Filler Cap
37 6-2368 O-Ring
38 6-2369 Compression Spring
39 6-2370 O-Ring
40 6-2371 Valve Stem
41 6-2372 Screw
42 6-2373 O-Ring
43 6-2374 Button Hd Screw
44 6-2375 Screw
45 6-2376 Special Washer
46 6-2377 O-Ring
  6-2404 Repair Kit



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-2378 Knob
2 6-2379 Muffler
3 6-2380 Decal
4 6-2381 Knob
5 6-2382 Warning Decal
6 6-2383 Compression Spring
7 6-2384 Pivot Cam
8 6-2385 O-Rtng
9 6-2386 O-Ring
10 6-2387 Steel Ball, 7/32
11 6-2388 Ball Guide
12 6-2389 Compression Spring
13 6-2390 Bushing
14 6-2391 Retaining Ring
15 6-2392 Swivel Block
16 6-2393 Plug
17 6-2394 Filter Disc
18 6-2395 Retaining Ring
19 6-2396 Poppet Retainer
20 6-2397 Poppet
21 6-2398 Backup Washer
22 6-2399 O-Ring
23 6-2400 Swivel Fitting
24 6-2401 Decal
25 6-2402 Washer
  6-2404 Repair Kit
