SUN EELR130A Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 3-0723 | Base Frame Weldment |
| 2 | 3-0824 | Outer Scissor Weldment |
| 3 | 3-0825 | Inner Scissor Weldment |
| 4 | 6-0807 | Washer |
| 5 | 1-2270 | Scissor Center Shaft |
| 6 | 1-1159 | Center Pipe Spacer |
| 7 | 6-0146 | Spring |
| 8 | 6-2230 | Bushing |
| 9 | 6-0328 | Thrust Washer |
| 10 | 1-1269 | Cam Follower |
| 11 | 1-0228 | Spacer |
| 12 | 6-0040 | Jam Nut |
| 13 | 2-1586 | Scissor Pin |
| 14 | 6-0056 | Lockwasher |
| 15 | 6-0554 | Hex Hd Bolt |
| 16 | 3-0725 | Top Weldment |
| 17 | 1-1997 | Roller Assembly |
| 18 | 1-1998 | Roller Shaft |
| 19 | 2-1572 | Lifting Arm Weldment |
| 20 | 6-0030 | Hex Hd Bolt |
| 21 | 6-0058 | Lockwasher |
| 22 | 1-2045 | Stack Pad Assembly Complete |
| 23 | 1-2030 | Stack Pad Weldment |
| 24 | 6-2050 | Rubber Pad |
| 25 | 6-0178 | Hex Hd Bolt |
| 26 | 1-1993 | Stack Pad Adapter, 3" |
| 27 | 2-1580 | Stack Pad Adapter, 6" |
| 28 | 3-0474 | Cylinder Assembly Complete |
| 29 | 1-1767 | Velocity Fuse |
| 30 | 2-0911 | Cylinder Tube Weldment |
| 31 | 1-1152 | Gland |
| 32 | 6-0653 | Rod Wiper |
| 33 | 6-0581 | Snap Ring |
| 34 | 1-1148 | Keeper Washer |
| 35 | 6-1166 | Seal And Wear Ring |
| 36 | 1-1150 | Piston |
| 37 | 2-0913 | Piston Rod Weldment |
| 38 | 1-1158 | Outside Cylinder Shaft |
| 39 | 1-1163 | Inside Cylinder Shaft |
| 40 | 2-1577 | Safety Stop Weldment- |
| 41 | 1-0561 | Safety Pin |
| 42 | 6-0438 | Set Screw |
| 43 | 6-0671 | Clip |
| 44 | 1-2271 | Safety Lever Arm |
| 45 | 6-0251 | Knob |
| 46 | 2-1585 | Guardrail |
| 47 | 6-0008 | Hex Hd Bolt |
| 48 | 6-0060 | Flat Washer |
| 49 | 6-0032 | Hex Nut |
| 50 | 2-6259 | Roller Assembly Complete |
| 51 | 6-0206 | Shoulder Bolt |
| 52 | 6-0223 | Thrust Washer |
| $3 | 2-0098 | Track Roller Assembly |
| 54 | 6-0224 | Thrust Washer |
| 55 | 1-0204 | Spring Stem |
| 56 | 6-0081 | Spring |
| 57 | 6-0042 | Nylon Locknut |
| 58 | 1-0765 | Hydraulic Hose |
| 6-1428 | Air/Hydraulic Pump Complete | |
| 3-0826 | Scissor Assembly Complete |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | FILLER PLUG | 2 |
| 3 | CLAMP | 4 |
| 5 | BLADDER | 6 |
| 7 | VALVE SCREW | 8 |
| 9 | U-CUP | 10 |
| 11 | RETAINER | 12 |
| 13 | SPRING GUIDE | 14 |
| 15 | O-RING | 16 |
| 17 | PISTON END CASTING- | 18 |
| 19 | COMPRESSION SPRING | 2c |
| 21 | SOC. HD SCREW | 22 |
| 23 | PISTON BODY | 24 |
| 25 | O-RING | 26 |
| 27 | REAR HEAD | 28 |
| 29 | O-RING | 30 |
| 31 | COMPRESSION SPRING | 32 |
| 33 | STEEL BALL | 34 |
| 35 | RELIEF VALVE | 36 |
| 37 | O-RING | 38 |
| 39 | O-RING | 40 |
| 41 | SCREW | 42 |
| 43 | SCREW | 44 |
| 45 | WASHER | 46 |
| REPAIR KIT | 1 | |
| 2 | 6-2379 | Muffler |
| 3 | 6-2380 | Decal |
| 4 | 6-2381 | Knob |
| 5 | 6-2382 | Warning Decal |
| 6 | 6-2383 | Compression Spring |
| 7 | 6.2384 | Pivot Cam |
| 8 | 6-2385 | O-Rlng |
| 9 | 6-2386 | O-Ring |
| 10 | 6-2387 | Steel Ball, 7/32 |
| 11 | 6-2388 | Ball Guide |
| 12 | 6-2389 | Compression Spring |
| 13 | 6-2390 | Bushing |
| 14 | 6-2391 | Retaining Ring |
| 15 | 6-2392 | Swivel Block |
| 16 | 6-2393 | Plug |
| 17 | 6-2394 | Filter Disc |
| 18 | 6-2395 | Retaining Ring |
| 19 | 6-2396 | Poppet Retainer |
| 20 | 6-2397 | Poppet |
| 21 | 6-2398 | Backup Washer |
| 22 | 6-2399 | O-Ring |
| 23 | 6-2400 | Swivel Mlling |
| 24 | 6-2401 | Decal |
| 25 | 6-2402 | Washer |
| 6-2404 | Repair Kit |
