SUN EELR116A Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 4-0245 | Alignment Deck Weldment, Left Side (144w/B) |
| 2 | 6-0049 | Tap Bolt |
| 3 | 6-0039 | Jam Nut |
| 4 | 3-0248 | Levelling Leg, Front-Left, Rear-Right |
| 5 | 2-0086 | Plunger Assembly |
| 6 | 6-0291 | Hex Bolt |
| 7 | 2-0999 | Levelling Leg Bracket, Outside |
| 8 | 2-0636 | Spacer Bar |
| 9 | 2-0635 | Retaining Bar |
| 10 | 6-0056 | Lock Washer |
| 11 | 6-0178 | Hex Bolt |
| 12 | 4-0304 | Adapter Tie Bar (Bolster) |
| 13 | 2-1000 | Levelling Leg Bracket, Inside |
| 14 | 6-0767 | Hex Bolt |
| 15 | 6-0059 | Lock Washer |
| 16 | 4-0220 | Turning Radius Plate Assembly (Option) |
| 17 | 4-0246 | Alignment Deck Weldment, R.S. (144w/B) |
| 18 | 2-0851 | Front Wheel Stop |
| 19 | 6-0808 | Flat Washer |
| 20 | 6-1101 | Hex Bolt |
| 21 | 6-1128 | Hex Bolt |
| 22 | 6-1271 | Socket Head Bolt |
| 23 | 2-0637 | Locking Pin Assembly |
| 24 | 6-0505 | Self Tapping Screw |
| 25 | 6-0069 | Shoulder Bolt |
| 26 | 6-0426 | Flat Washer |
| 27 | 3-0197 | Slide Plate |
| 28 | 6-0829 | 1/4 Dia. Ball Bearing |
| 29 | 3-0196 | Bearing Cage |
| 30 | 6-0035 | Hex Nut |
| 31 | 6-0063 | Flat Washer |
| 32 | 3-0457 | Rear Tie Bar |
| 33 | 6-0439 | Flat Washer |
| 34 | 6-0037 | Hex Nut |
| 35 | 3-0506 | Approach Ramp |
| 36 | 6-0115 | Cotter Pin, 1/8 X 2lg. |
| 37 | 1-0095 | Ramp Pin Weldment |
| 38 | 3-0272 | Levelling Leg, Front-Right, Rear-Left |
| 39 | 6-0891 | Hex Bolt |
| 40 | 6-0181 | Lock Washer |
| 41 | 2-0362 | Pull Out Step Assembly |
| 42 | 1-0749 | Safety Walk Tape |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 6-0500 | Frame Clip |
| 2 | 6-0167 | Terminal Bolt |
| 3 | 6-0014 | Street Tee 1/4npt |
| 4 | 6-0015 | Street Elbow |
| 5 | 6-0710 | Polytube Straight Adapter, 3/8 X 1/4npt |
| 6 | 1-0120 | Hose 144w/B |
| 7 | 6-0337 | 12 Coiled Hose |
| 8 | 6-0282 | Plug |
