JOHN BEAN EELR510A Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 3-1127 | Baseframe Weldment |
| 2 | 3-1124 | Scissor Assembly |
| 3 | 1-3674 | Glide Block W/ C'bore |
| 4 | 6-3958 | Shoulder Bolt |
| 5 | 6-1553 | Nylon Lock Washer |
| 6 | 3-1112 | Top Cover Weldment |
| 7 | 1-4006 | Air Jack Bracket |
| 8 | 6-0126 | Hx Head Bolt |
| 9 | 6-0713 | Terminal Bolt |
| 10 | 6-0710 | Adapter, 3/8" Poly X 1/4" Npt M |
| 11 | 6-1428 | Air/Hydraulic Pump |
| 12 | 6-3010 | 90 Deg. Pneumatic Elbow |
| 13 | 2-2953 | Arm Weldment |
| 14 | 1-3278 | Stack Pad Assembly |
| 15 | 3-1138 | Roller Adapter Weldment |
| 16 | 2-0259 | Roller Assembly |
| 17 | 2-2951 | Safety Weldment |
| 18 | 6-0081 | Spring |
| 19 | 1-4049 | Cylinder Shaft, Lower |
| 20 | 1-4050 | Cylinder Shaft, Upper |
| 21 | 3-1075 | Hydraulic Cylinder Assembly |
| 22 | 1-1999 | Scissor Hinge Pin |
| 23 | 1-2361 | Hinge Pin |
| 24 | 6-3959 | Loop Clamp |
| 25 | 1-3203 | Safety Lever Assembly |
| 26 | 6-3862 | Rubber Grip Handle |
| 27 | 6-0060 | Flat Washer |
| 28 | 6-0056 | Lock Washer |
| 29 | 6-2565 | Bhcs, 1/4"-20unc X 3/4" Lg. |
| 30 | 6-3036 | Bhcs, 1/4"-20unc X 1" Lg. |
| 31 | 2-1580 | Stack Pad Adapter, 6" |
| 32 | 1-3280 | Stack Pad Adapter, 3-1/4" |
| 33 | 6-0438 | Set Screw |
| 34 | 6-0062 | Flat Washer |
| 35 | 6-0058 | Lock Washer |
| 36 | 6-0030 | Hex Hd Bolt |
| 37 | 6-3369 | Nylon Jam Nut |
| 38 | 6-0081 | Spring |
| 39 | 6-0042 | Nylon Lock Nut |
| 40 | 6-0011 | Adapter, 3/8 Npt M X 3/8 Jic M |
| 41 | 6-3861 | Flow Restrictor |
| 42 | 8-0142 | Polytube, 3/8" - 24" Lg |
| 43 | 1-4063 | Hydraulic Hose Assembly |
| 44 | 6-0178 | Hex. Hd Bolt |
| 45 | 6-0032 | Hex Nut |
| 46 | 6-3863 | Decal, Safety Release |
| 47 | 6-3970 | Raise & Lower Warning Decal |
| 48 | 6-1994 | Capacity Decal |
| 49 | 6-3031 | Decal, "Up" |
| 50 | 1-2381 | Keeper Bracket |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 6-3348 | Reservoir Cap Assembly |
| 2 | 6-3349 | Release Guide Assembly |
| 3 | 6-3350 | Flow Restrictor Assembly |
| 4 | 6-3351 | Coupler Assembly |
| 5 | 6-3352 | Coupling V-Retainer |
| 6 | 6-3353 | Plunger & Spring Kit |
| 7 | 6-3354 | Hydraulic Cylinder Assembly |
| 8 | 6-3355 | Air Piston Assembly |
| 9 | 6-3356 | Air Motor Assembly |
| 10 | 6-3357 | Coupler Kit |
| 12 | 6-3859 | Relief Valve Assembly |
| 13 | 6-3360 | Base |
| 14 | 6-3361 | Reservoir |
| 15 | 6-3365 | Poppet Guide Assembly |
| 16 | 6-3368 | Boot |
| 17 | 6-3366 | Handle |
| 18 | 6-3367 | Rubber Sleeve |
