JOHN BEAN 48212V Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 4-0160 Base Frame Weldment, Driver Side
2 4-0161 Base Frame Weldment, Passenger Side
3 4-0153 Scissor Weldment
4 4-0158 Alignment Deck, Driver Side
5 4-0T59 Alignment Deck, Passenger Side
6 3-0285 Approach Ramp
7 1-0095 Ramp Pin
8 2-0432 Wheel Stop (Front)
9 6-0291 Hex Nut
10 6-0035 Hex Nut
11 6-0059 Lockwasher
12 6-0177 1/4-20unc X 2 Long
13 3-0300 Levelling Leg, Front Ds, Rear Ps
14 3-0299 Levelling Leg, Front Ps, Rear Ds
15 2-0086 Plunger Pin Assembly
16 2-0071 Safety Release Con. Rod
17 1-0106 Fulcrum Pin 1-1/4 Dla.
18 6-0085 Bushing
19 1-0107 End Hinge Pin 1dia.
20 6-0076 Cam Follower
21 6-0040 Jam Nut
22 2-0405 Safety Bar Weldment
23 1-0547 Pins
24 2-0194 Safety Pedal
25 1-0189 Safety Release Tab
26 2-0428 Safety Release Rod
27 6-0027 Hex Bolt
28 6-0056 Lockwasher
29 6-0032 Hex Nut
30 3-0164 Center Cover
31 6-0000 Grease Nipple
32 6-0077 Cam Follower
33 3-0297 Rear Crossmember Weldment
34 6-0439 Plain Washer
35 6-0172 Rubber Support Assembly
36 3-0298 Front Crossmember
37 1-0698 Toe Guard
38 6-0178 Hex Bolt
39 6-0060 Flat Washer
40 2-0343 Rear Wheel Stop
41 1-0691 Front W/S Bracket - D.S.
42 1-0690 Front W/S Bracket - P.S.
43 2-0118 Outside Leg Bracket
44 6-0140 Wedge Anchor
45 6-0141 Concrete Nail
46 6-0084 Bushing
47 6-0115 Cotter Pin
48 1-0140 Washer
49 6-0146 Spring Pin 3/16 X 2 Long
50 1-0432 Rear Wheel Stop Cup
51 6-0439 Flat Washer
52 1-0728 Shipping Bracket Flat
54 6-0554 Hex Bolt
55 6-0041 Jam Nut
56 6-0050 Tap Bolt



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 4-0160 Base Frame Weldment, Driver Side
2 4-0161 Base Frame Weldment, Passenger Side
3 4-0153 Scissor Weldment
4 4-0162 Service Deck, Driver Side
5 4-0163 Service Deck, Passenger Side
6 3-0285 Approach Ramp
7 1-0095 Ramp Pin
8 2-0432 Wheelstop
9 6-0291 Hex Bolt
10 6-0035 Hex Nut
11 6-0059 Lockwasher
12 6-0177 1/4-20unc X 2 Long
13 2-0071 Safety Release Con. Rod
14 1-0106 Fulcrum Pin 1-1/4 Dla
15 6-0085 Bushing
16 1-0707 End Hinge Pin 1dia
17 6-0076 Cam Follower
18 6-0040 Jam Nut
19 2-0405 Safety Bar Weldment
20 1-0034 Pins
21 2-0194 Safety Pedal
22 1-0189 Safety Release Tab
23 2-0428 Safety Release Rod
24 6-0027 Hex Bolt
25 6-0056 Lockwasher
26 6-0032 Hex Nut
27 3-0164 Center Cover
28 6-0000 Grease Nipple
29 6-0077 Cam Follower
30 3-0298 Rear Crossmember Weldment
31 6-0063 Plain Washer
32 6-0172 Rubber Support Assembly
33 3-0298 Front Crossmember
34 1-0698 Toe Guard
35 6-0178 Hex Bolt
36 6-0060 Flat Washer
37 2-0343 Rear Wheel Stop
38 1-0691 Front W/S Bracket-Weldment
39 1-0690 Front W/S Bracket-Weldment
40 6-0140 Wedge Anchor
41 6-0141 Concrete Nail
42 6-0084 Bushing
43 6-0115 Cotter Pin
44 1-0140 Washer
45 6-0146 Spring Pin 3/16x2 Lg
46 1-0432 Rear Wheel Stop Cup
47 1-0439 Flat Washer
48 1-0728 Shipping Bracket
49 6-0554. Hex Bolt



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0168 Hose Clamp Hf-5
2 6-0167 Terminal Bolt
3 6-0426 Flat Washer
4 6-0069 Shoulder Bolt
5 1-0117 Locking Pin Assembly
6 6-0505 Self Tap Screw
7 6-0012 Bulkhead,'90 Deg Elbow
8 3-0017 Tube Assembly
9 6-0118 Adapter, 3/8m Jic To 1/4 Fnpt
10 1-0119 Hose Assembly
11 2-0062 Tube Assembly
12 6-0171 Tube, 3/8 X .049 X 20 Long
13 6-0014 Streettee 1/4 Npt
14 6-0015 Street Elbow
15 6-0121 Hose Barb Fitting, 1/4 Npt 3/8 Hose
16 1-0139 Hose, 172" W/B
17 6-0337 Streettee, 1/4 Npt
18 3-0197 Rear Steer Plate
19 6-0427 Ball Bearing
20 6-0017 Sleeve, Jic
21 6-0016 Nut
22 6-0170 Tube Clamp
23 6-0169 Screw
24 6-0178 Hex Bolt
25 6-0056 Lockwasher
26 1-0391 Turn Plate Guide
27 6-0282 Plug
28 3-0196 Bearing Plate



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 3-0000 Hydraulic Cylinder
1-2 3-0077 Tube Weldment
1-3 1-0011 Nut
1-4 1-0008 Gland
1-5 2-0001 Rod Weldment
1-6 6-0001 Wiper Ring
1-7 6-0002 0 Ring
1-8 1-0007 Piston
1-9 6-0003 Seal Ring
1-10 6-0004 Wear Ring
1-11 6-0005 Nut
1-12 6-0007 Bearing
1-13 6-0070 Retaining Ring
1-14 6-0000 Grease Nipple
15 1-0029 Pin
16 6-0340 Retaining Ring
17 6-0025 Velocity Fuse
18 1-0093 Tube Assembly, Cylinder
19 6-0013 Bulkhead, Connector 3/8 Jic C/W Jam Nut
20 1-0649 Hose Assembly, 1200
21 6-0175 Adapter, 45 Deg Elbow
22 2-0068 Bulkhead, 90 Degree Elbow
24 2-0064 Tube Assembly
25 2-0182 Tube Assembly
26 6-0156 Adapter, 3.8 Bsp To 3/8 Jic
27 6-0173 Flow Divider (With Fittings)
28 2-0066 Tube Assembly
29 2-0015 Line Cover
30 6-0171 Supply Tube 20 3/8 X .049 Wall
31 6-0378 Reducer Nipple 3/8 To 1/4
32 6-0016 Nut
33 6-0141 Concrete Nail
34 2-0519 Tube Assembly
35 6-0174 Adapter, Extended 90 Degree
36 6-0017 Sleeve
37 6-0176 Bulkhead Adapter, 3/8 Bsp To 3/8 Jic



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 4-0146 Oil Reservoir
2 6-0102 Plug
3 6-0544 Plange And Pipe For Strainer 12000
4 6-0542 Motor Coupler
5 6-0541 1001 Pump Assembly (Pumps, Block, Flange)
6a 6-0087 Motor, 220 V/1 Phase
6b 6-0446 Motor, 208 V/3 Phase
6c 6-0447 Motor, 550 V/3 Phase
7 6-0089 Plug
8 6-0020 Hydraulic Adapter
9 1-0102 Tube Assembly
10 6-0090 Flow Control Valve
11 6-0011 Adapter, 3/8 Jic To 3/8 Mnpt
12 6-0091 Solenoid Electric Plug
13a 6-0095 Contractor Motor Starter, 220 V/1 Phase
13b 6-0448 Contractor Motor Starter 208 V/3 Phase
13c 6-0449 Contractor Motor Starter 550 V/3 Phase
14 6-0092 Strain Relief Connector, 1/4
15 6-0094 Strain Relief Connector, 1/2
16 6-0096 Remote Hand Control
17 6-0431 Pressure Relief Valve
18 1-0103 Remote Control Cable
19 6-0434 Strainer
20 6-0097 Oil Filer & Tube 12000
22 1-0225 Rubber Gasket
23 6-0032 Nut
24 1-0104 Motor Cable
25 6-0100 Solenoid
26 6-0101 Solenoid Valve Spool 12000, 5000 P.S.
27 1-0105 Solenoid Cable
28 6-0432 Cap Nut
29 6-0099 Filler Cap
30 6-0067 Hex Bolt
31 6-0058 Lockwasher
32 6-0027 Hex Bolt
33 6-0056 Lockwasher
34 6-0145 Manual Descend Valve
35 6-0144 Pressuretime Delay Valve
36 6-0141 Concrete Nail
37 6-0379 Hydraulic Oil, Iso-32
38 6-0093 Strain Relief Connector, 3/8
39 6-0385 Anti Slip Diff Fluid
40 6-0405 Magnet
41 6-0517 Oil Sight Level Plug
