JOHN BEAN 44110Q Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0650 Power Pack, 220V/1PH
2 4-0186 Power Post
3 3-0487 Safety Rack
4 4-0357 Alignment Deck, L.H.
5 4-0342 Front Crossmember
6 2-0989 Front Wheel Stop
7 6-0737 Hex Nut, 3/4"-10
8 6-0738 Flat Washer, 3/4"
9 6-0736 Wedge Anchor, 3/4" x 4-3/4"
10 6-0668 Hex Hd. Bolt, 3/8"-16 x 1" Gr. 8
11 6-0058 Lock Washer, 3/8"
12 6-0062 Flat Washer, 3/8"
13 6-0423 Hex Hd. Bolt, 5/16"-18 x 3/4"
14 6-0672 Lock Washer, 5/16"
15 6-0059 Lock Washer, 1/2"
16 6-0045 Hex Hd. Bolt, 1/2"-13 x 1"
17 6-0056 Lock Washer, 1/4"
18 6-0178 Hex Hd. Bolt 1/4"-20 x 3/4"
19 2-0635 Retaining Bar
20 6-0426 Flat Washer, 13/32" x 2"
21 6-0069 Shoulder Bolt, 3/8" x 5/8"
22 3-0503 Rear Slip Plate
23 1-1070 Bearing Cage
24 6-0829 Ball Bearing Set
25 1-0787 1/2" Lg. Sheave Spacer
26 2-0557 Sheave Assembly
27 1-0757 Nylon Thrust Washer
28 4-0341 Rear Crossmember
29 2-0637 Locking Pin Assembly
30 6-0505 Self-Tap. Screw, #10 x 1/2"
31 1-0095 Ramp Pin
32 6-0115 Cotter Pin, 1/8" x 2"
33 6-0592 "Caution" Decal
34 6-0351 "Safety Instructions" Decal
35 6-0595 "Warning" Decal
36 3-0502 Approach Ramp
37 3-0347 Post
38 4-0358 Alignment Deck, R.H.
39 1-0798 Sheave Spacer, 2-1/2"
40 1-0788 Sheave Spacer, 1-1/2"
41 2-0566 Deck Sheave Pin
42 6-0801 Shoulder Bolt, 3/8" x 1-1/2"
43 6-0729 Shoulder Bolt, 3/8" x 3/4"
44 1-0769 Lock Safety Pin
45 1-0766 Cable Roller
46 1-0768 Tension Spring
47 1-0771 Crossmember Sheave Pin
48 1-0786 Sheave Spacer, 3/8"
49 2-0990 Safety Shoe Weldment
50 6-1563 Hex Nylon Locknut, 1/4"-28 UNF
51 1-0767 Compression Spring
52 6-0662 Hex Nut, 5/8"-18 UNF
53 6-0663 Intern. Tooth Lock Washer, 5/8"
54 6-0651 Air Cyl., 5-1/2" Rod Lg. (Spr-12)
55 2-0567 Safety Lock Weldment
56 1-0775 Plastic Bracket
57 1-0776 Plastic Guide
58 6-0036 Hex Nut, 5/8"-11, Gr. 8
59 1-0799 Sheave Spacer, 1-3/4"
60 6-0726 Set Screw, 1/2"-13 x 1" Gr. 8
61 1-0943 Sheave Spacer, 2"
62 2-0636 Spacer Bar
63 0-1654 Hydraulic Cylinder
64 6-1160 Locknut, 7/8"-14UNF, Nylon, Inst.
65 6-0004 Wear Ring
66 2-0564 Piston
67 6-1305 "O" Ring
68 6-0003 Piston Seal
69 0-0169 Piston Seal Kit
70 2-0565 Piston Rod
71 6-0664 Hex Nut, 1"-14UNF-2A, Gr. 8
72 2-0561 Cable Flange
73 6-0665 Clamp
74 6-0666 Hex Hd. Bolt, 3/8"-16 x 1-1/4" Gr. 8
75 6-0653 Rod Wiper
76 6-0654 Rod Seal
77 3-0348 Gland
78 6-0655 "O" Ring
79 0-0170 Gland Seal Kit
80 6-0730 Hex Hd. Bolt, 3/8"-16 x 2-3/4"
81 2-0575 Sheave Cover
82 6-1114 Serial Tag
83 6-0996 "ALI/ETL" Tag
84 6-1125 "Caution" Tape (40" Lg.)
85 6-0060 Flat Washer, 1/4"
87 6-0027 Hex Hd. Bolt, 1/4-20 x 1-1/4"
88 6-1637 "Attention" Decal



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0881 Microswitch & Wiring Assembly
2 6-1084 Microswitch Boot
3 6-0773 Motor 230 V AC, 1 PH. 60 Hz.
4 0-0197 Motor Adapter Kit
5 6-1085 Socket Hd. Capscrew, 1/4"-20 x 1-5/8"
6 6-0056 Lock Washer, 1/4"
7 6-1086 Allen Hd. Flat Screw 1/4" x 3/4"
8 6-0774 Coupling
9 6-0776 Release Bracket & Handle Assembly
10 6-0880 Valve Cartridge Release
11 6-1087 Valve Cartridge Check
12 6-1317 Fixed Relief Valve (RV17)
13 6-1089 Relief Valve Cap
14 6-0875 Reservoir "O" Ring
15 6-0782 Pump Assembly
16 6-1090 Pump Mounting Bolt
17 0-0198 Inlet Plumbing Kit
18 6-0786 Inlet Hose/Filter Assembly
19 0-0199 Pump "O" Ring Kit
20 6-0783 Return Tube
21 6-0784 Breather-Filler Cap
22 6-0785 Reservoir
23 6-1091 Reservoir Screw





Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0709 90 Elbow, 1/8" NPT x 1/4" Poly Tube
2 6-0651 Air Cylinder
3 6-0706 1/4" Poly Tube
4 6-0710 Adpt., 3/8" Poly Tube x 1/4" NPT
5 6-0713 Terminal bolt, 3/4"
6 6-0282 Plug, 1/4" NPT
7 6-0014 1/4" NPT Street Tee
8 6-0015 1/4" NPT Street Elbow
9 6-0707 3/8" Poly Tube
10 6-0804 90 Adpt., 3/8" JIC M x 9/16"-18M
11 6-0714 Hose Guard
12 6-0650 Power pack, 230V/1PH
13 6-0715 Hyd. Hose Assy., 3/8" Swvel x 3/8" JICM, 147"
14 6-0731 Cable Tie
15 6-1095 Hex Nut, #8-32
16 6-0797 Adpt., 3/8" NPT M x 3/8" JIC F Swivel
17 6-0090 Flow Control
18 6-0594 "Notice" Decal
19 6-0796 90 Elbow, 1/4" NPT M x 3/8" NPT F
20 6-0708 Adpt., 1/4" Poly Tube x 1/8" NPT
21 6-0717 Air Valve
22 6-0180 Air Filter
23 6-0718 90 Reducer, 1/4" NPT M x 1/8" NPT M
24 6-0025 Velocity Fuse
25 6-0182 Plug, 1/8" NPT
26 1-1057 Manifold
27 6-0205 Hex Hd. Capscrew, 1/4"-20 x 1-1/2"
28 6-0032 Hex Nut, 1/4"-20
29 6-0056 Lock Washer, 1/4"
30 6-1094 Phil. Hd. Screw, #8-32 x 1"
32 6-0593 "Lift Operation" Decal
33 6-0280 Adpt., 1/8" NPT M x 1/4" JIC M




Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 2-0943 Cable Assembly, 314" Lg. L.F.
2 2-0944 Cable Assembly, 144" Lg. L.R.
3 2-0945 Cable Assembly, 194" Lg. R.R.
4 2-0946 Cable Assembly, 361" Lg. R.F.
5 6-0724 Hex Nut, 7/8"-14 UNF Gr. 8
6 1-0800 Cable Spacer, 2"
7 6-0725 Flat Washer, 7/8"
8 1-0801 Cable Spacer, 1"
