JOHN BEAN 42011S14 Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0248 Flat Washer
2 6-0059 Lock Washer
3 6-0035 Hex Nut
4 6-1134 Self Tapping Screw
5 6-0267 Cotter Pin, 1/8dia. X 1lg.
6 6-0996 Ali/Etl Decal
7 6-1583 "Hydraulic Leveling " Decal
8 6-0206 Shoulder Bolt
9 1-0938 Safety Pin
10 1-0415 Safety Pulley
11 1-1115 Safety Spring
12 6-0808 Flat Washer
13 6-1135 Plastic Knob
14 3-0439 Safety Cover
15 1-1113 Safety Release Handle
16 2-0902 Safety Dog, Left Side
17 1-1291 Cable Connecting Bracket
18 6-0737 Hex Nut
19 6-0738 Flat Washer
20 6-1379 Wedge Anchor
21 6-0027 Hex Bolt
22 6-0626 1/4id Fender Washer
23 1-0939 Plunger Spring
24 4-0413 Tower Weldment, Left Side
25 1-0745 Pivot Plunger
26 6-0000 Grease Fitting
27 6-0437 Roll Pin, 1/8dia. X 1lg.
28 2-0249 Rack
29 1-0208 Knob
30 1-1135 Threaded Rod, 3/8-16unc X 1 1/2lg.
31 3-0571 Short Outer Arm Tube Weldment, Right Side
32 3-0572 Short Outer Arm Tube Weldment, Left Side
33 4-0456 Short Locking Arm Assembly, Right Side
34 4-0455 Short Locking Arm Assembly, Left Side
35 2-1085 Short Inner Arm Weldment
36 3-0569 Long Outer Arm Tube Weldment, Right Side
37 3-0570 Long Outer Arm Tube Weldment, Left Side
38 4-0454 Long Locking Arm Assembly, Right Side
39 4-0453 Long Locking Arm Assembly, Left Side
40 2-1082 Long Inner Arm Weldment
41 1-1099 Center Pin
42 1-1091 Adapter Pin
43 3-0582 High Step Position Adapter
44 3-0583 Low Position Adapter
45 1-0262 Arm Stop
46 6-0339 Hex Bolt
47 6-0056 Lockwasher
48 2-0929 Arm Pin Weldment
49 6-0423 Hex Bolt
50 4-0414 Tower Weldment, Right Side
51 6-0069 Shoulder Bolt
52 0-0203 Safety Cover W/Decals, Right Side
53 6-0594 Safety Instructions Decal
54 2-0872 Safety Dog, Right Side
55 1-1119 Carriage Stop
57 6-0294 Hex Nut
58 1-1116 Safety Cable Pulley
59 3-0488 Crossmember Weldment
60 1-1372 Safety Release Cable
61 6-0291 Hex Bolt
62 0-0204 Safety Cover W/Decals, Left Side
63 6-0595 "Warning Decal
64 6-0592 Caution Decal
65 6-0603 "Safety Release" Decal
67 1-0333 Pivot Pin
68 6-1172 Serial # Tag
69 4-0392 Carriage Weldment
70 2-0772 Glide Bearing
71 6-0295 Flat Washer
72 6-0296 Lockwasher
73 6-0315 Hex Bolt
74 1-1439 Actuator Bar
75 6-1404 Foam Guard
76 6-0169 Self Tapping Screw
77 6-1403 Electrical Utility Box
78 6-0916 Microswitch
79 1-1379 Actuator Extension
80 6-1133 Cable Connector
81 6-1359 Elec. Cable 12/3 X 141lg. Sow
82 6-0032 Hex Hd. Nut
83 6-0178 Hex Hd. Bolt
84 6-0056 Lockwasher
85 6-1759 Electrical Cord Clip, 5/8
88 6-0438 Set Screw
90 6-0908 Shoulder Bolt
93 6-0185 Shoulder Bolt
95 1-1378 Actuator Mtg. Bracket
96 2-1143 Limit Switch Mtg. Bracket
97 6-0177 Hex Hd. Bolt
98 6-1466 6/32 Screw
99 6-0027 Hex Hd. Bolt
100 2-1477 Angle Bracket



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0012 Elbow
2 6-0345 Adapter, 3/8npt - 3/8jic X 2 1/4lg.
3 6-0286 Union, 3/8 Jic Male
4 0-0207 Gland Seal Kit, Right Side
5 6-0056 Lockwasher
6 2-1065 Hydraulic Tube Assembly
7 2-0930 Piston Tube, Right Side
8 3-0480 Hydraulic Cylinder AssY, Right Side
9 6-0284 Tee, 3/8 Swivel Nut
10 6-0021 Cap, 3/8jic
11 6-0580 Allen Hd. Setscrew
12 2-0619 Piston
13 0-0159 Piston Seal Kit, Right Side
14 1-0725 Keeper Washer
15 1-0102 Hydraulic Tube Assembly
16 6-0425 Shoulder Bolt
17 2-1140 Hydraulic Tube Assembly
18 6-0804 Elbow
19 6-0293 Hex Bolt
20 6-0061 Flat Washer
21 6-1176 Power Pack
22 6-1266 Lift Operation" Decal
23 6-0028 Hex Hd. Bolt
25 1-1341 Hydraulic Hose Assembly
27 2-0886 Hydraulic Tube Assembly
28 6-0422 Velocity Fuse, 4gpm
29 6-1362 Hydraulic Valve Block
30 2-1064 Hydraulic Tube Assembly
31 6-1372 Branch T Jic All Ends
32 3-0428 Cylinder Barrel Weldment, Left Side
33 6-0631 Uni-Torque Locknut
34 2-0521 Piston Spigot
35 0-0160 Piston Seal Kit, Left Side
36 2-0793 Piston Rod Weldment, Left Side
37 0-0206 Gland Seal Kit, Left Side
38 4-0289 Hydraulic Cylinder AssY, Left Side
39 2-0959 Hydraulic Tube Assembly
40 6-0340 Circlip
41 2-0802 Cylinder Barrel Weldment, Right Side
42 6-0674 Lockwasher
43 6-0294 Hex Nut
44 6-1353 Round Hd. Bolt
45 6-0170 Tube Clamp
46 2-0887 Hydraulic Tube Assembly
47 6-1389 Hydraulic Valve Block AssY (C/W Fittings)
51 6-0281 Adapter, 1/4 Npt, M - 1/4 Jic M
53 6-0276 Adapter, 1/4npt Male - 3/8jic Male



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0881 Microswitch
2 6-1084 Microswitch Boot
  6-0773 Motor 230 Vac, 1ph, 60 Hz
4 0-0197 Motor Adapter
5 6-1085 Socket Hd.Cap Scw, L/4-20unc X 5/8"Lg.
6 6-0056 Lockwasher
7 6-1086 Allen Hd. Flat Scw, L/4"-20unc X 3/4"Lg.
8 6-0774 Coupling
9 6-0776 Release Bracket & Handle Assembly
10 6-0880 Valve Cartridge Release
11 6-1087 Valve Cartridge Check
12 6-1324 Fixed Relief Valve, Rv24
13 6-1089 Relief Valve Cap
14 6-0875 Reservoir "0"Ring
15 6-0782 Pump Assembly
16 6-1090 Pump Mounting Bolt
17 0-0198 Inlet Plumbing Kit
18 6-0786 Inlet Hose / Filter Assembly
19 0-0199 Pump "O" Ring Kit
20 6-0783 Return Tube
21 6-1376 Breather-Filler Cap (Plastic)
22 6-1399 Reservoir (Plastic)
23 6-1091 Reservoir Screw
24 6-1133 Cable Connector, 3/8
