JOHN BEAN 42008S Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0248 Flat Washer
2 6-0059 Lockwasher
3 6-0035 Hex Nut
4 6-1134 Self Tapping Screw
5 6-0267 Cotter Pin, 1/8dia. X 1lg.
6 6-0996 Ali/Etl Decal
7 6-1151 "Hydraulic Leveling" Decal
8 6-0206 Shoulder Bolt
9 1-0938 Safety Pin
10 1-0415 Safety Pulley
11 1-1115 Safety Spring
12 6-0808 Flat Washer
13 6-1135 Plastic Knob
14 3-0439 Safety Cover
15 1-1113 Safety Release Handle
16 2-1901 Safety Dog, Left Side
17 6-2074 5/32 Thimble
18 6-0737 Hex Nut
19 6-0738 Flat Washer
20 6-1379 Wedge Anchor
21 6-0178 Hex Bolt
22 6-0626 1/4id Fender Washer
23 1-0939 Plunger Spring
24 4-0381 Tower Weldment, Left Side
25 1-0745 Pivot Plunger
26 6-0000 Grease Fitting
27 6-0437 Roll Pin, 1/8dia. X 1lg.
28 2-0249 Rack
29 1-0208 Knob
30 1-1135 Threaded Rod, 3/8-16unc X 1 1/2lg.
31 3-0561 Outer Arm Tube Weldment, Right Side
32 3-0562 Outer Arm Tube Weldment, Left Side
33 4-0464 Locking Arm Assembly, Right Side
34 4-0463 Locking Arm Assembly, Left Side
35 2-1088 Short Inner Arm Weldment
36 3-0560 Outer Arm Tube Weldment, Right Side
37 3-0559 Outer Arm Tube Weldment, Left Side
38 4-0462 Locking Arm Assembly, Right Side
39 4-0461 Locking Arm Assembly, Left Side
40 2-1086 Inner Arm Weldment
41 1-1099 Center Pin
42 1-1091 Adapter Pin
43 3-0582 High Step Position Adapter
44 3-0583 Low Position Adapter
45 6-0062 Flatwasher
46 6-0030 Hex Bolt
47 6-0058 Lockwasher
48 2-0439 Arm Pin
49 6-0423 Hex Bolt
50 4-0382 Tower Weldment, Right Side
51 6-0069 Shoulder Bolt
52 0-0203 Safety Cover W/Decals, Right Side
53 6-0594 Safety Instructions Decal
54 2-0872 Safety Dog, Right Side
55 1-1119 Carriage Stop
56 6-2060 Wire Rope Clips
57 6-0294 Hex Nut
58 1-1116 Safety Cable Pulley
59 6-0169 Self Tapping Screw
60 1-2058 Safety Release Cable
61 6-0291 Hex Bolt
62 6-1759 5/8 Electrical Clip
63 6-0595 "Warning" Decal
64 6-0592 Caution Decal
65 6-0603 "Safety Release" Decal
66 6-1466 6/32 Screw
67 6-0177 Hex Hd. Bolt
68 6-1120 Serial # Tag
69 4-0319 Carriage Weldment
70 2-0772 Glide Bearing
71 1-0333 Pivot Pin
72 6-0438 Set Screw
73 2-1477 Angle Bracket
74 1-1380 Actuator Bar
75 6-1404 Foam Guard
76 3-0440 Crossmember Weldment
77 6-1403 Electrical Utility Box
78 6-0916 Microswitch
79 1-1379 Actuator Extension
80 6-1133 Cable Connector
81 6-1173 Elec. Cable 12/3 X 117lg. Sow
82 6-0032 Hex Hd. Nut
83 6-0178 Hex Hd. Bolt
84 6-0056 Lockwasher
85 6-0027 Hex Bolt
86 6-0315 Hex Bolt
87 0-0204 Safety Cover W/Decals, Left Side
88 6-0295 Flat Washer
89 6-0296 Lockwasher
90 6-0801 Shoulder Bolt
91 1-1378 Actuator Mtg. Bracket
92 2-1143 Limit Switch Mtg. Bracket



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0012 Elbow
2 6-0021 Cap, 3/8jic
3 6-0286 Union, 3/8jic Male
4 6-0284 Tee, 3/8 Swivel Nut
5 6-0056 Lockwasher
6 3-0735 Hydraulic Cylinder AssY, Rs
7 6-1956 Power Pack (8k)
  6-1957 Power Pack (9k)
  6-1935 Power Pack (1 Ik)
8 6-0295 Flat Washer
9 6-0425 Shoulder Bolt
10 6-0293 Hex Bolt
11 6-0170 Tube Clamp
12 6-1353 Round Hd. Bolt
13 6-0340 Circlip
14 4-0289 Hydraulic Cylinder AssY, Ls
15 6-0276 Adapter, 1/4npt Male - 3/8jic Male
16 2-0887 Hydraulic Tube AssY, Ls
17 2-1140 Hydraulic Tube AssY (Valve Block To Powerpack)
18 6-0804 Elbow
19 6-1362 Hydraulic Valve Block
20 6-2623 Hydraulic Valve Block AssY (C/W Fittings)
21 6-0674 Lockwasher
22 6-0345 Adapter, 3/8npt - 3/8jic X 2 1/4lg.
23 6-0028 Hex Hd. Bolt
24 6-0294 Hex Nut
25 1-2436 Hydraulic Tube AssY
26 6-1265 Lift Operation" Decal (8k)
  6-1639 Lift Operation" Decal (9k)
  6-1266 Lift Operation" Decal (11k)
27 2-0886 Hydraulic Tube AssY
28 6-0422 Velocity Fuse, 4gpm
29 2-0878 Hydraulic Tube AssY (2-Piece Tower)
30 2-1876 Hydraulic Tube AssY, Rs (2-Piece Tower)
31 2-1877 Hydraulic Tube AssY, Ls (2-Piece Tower)
32 2-1874 Hydraulic Tube AssY, Rs (12 & 14 Tower)
33 2-1873 Hydraulic Tube AssY, (12 Tower)
  2-1875 Hydraulic Tube AssY, (14 Tower)
34 2-1872 Hydraulic Tube AssY, Ls
35 2-1537 Hydraulic Tube AssY (8/9k)
  2-0959 Hydraulic Tube AssY (1 Ik AssY)
  2-1286 Hydraulic Tube AssY (1 Ik Sym)
  0-0551 Gland Seal Kit, Right Side (8/9/1 Ik)
  0-0159 Piston Seal Kit, Right Side (8/9/1 Ik)
  0-0206 Gland Seal Kit, Left Side (8/9/1 Ik)
  0-0160 Piston Seal Kit, Left Side (8/9/1 Ik)



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-1087 Valve Cartridge Check
2 6-2136 Label Installation Autohoist
4 6-1376 Breather Cap & Bladder
6 6-2474 Motor Ac 208-230v. 2hp/Lph/60hz, Blk
7 6-2149 Label Warning Autohoist
9 6-2151 Spring 0.480 X 0.063 X 0.42 Comp
10 6-2152 Return Hose 3/8 Od X 21.5
11 6-2153 Compression Tube Nut
12 6-2154 Compression Tube Sleeve
13 6-2155 Endhead Universal Autohoist
14 6-1958 Pumpassy 2.5 Cc/Rev. Short Spline
15 6-1317 Relief Assembly Fixed 170 Bar
16 6-0880 Valve Cartridge Release Manual
17 6-2473 Wiring Assembly Ac 1ph Fenner
18 6-1090 Bolt
19 6-0774 Coupling Sae 9t-20/40 1.260
20 6-2157 Plumbing Plug
21 6-2158 Seal Shaft 0.500 X 1.00 X 0.25
22 6-2159 Washer
24 6-2161 Plumbing Plug
25 6-2162 Plumbing Magnet
27 6-2164 Screw
28 6-2165 Cover Assy Suction
29 6-2166 Plumbing Clamp Hose Adj. Inlet
30 6-1392 Bolt
31 6-2167 Nut
32 6-2168 Washer3/4 Int. Tooth Lock
33 6-0776 Bracket - Handle Assy Rel Black
34 6-2169 Bolt
35 6-2170 Washer4 Lock Hi-Collar
37 6-1091 Bolt
38 6-0786 Plumbing Assy Inlet 17.24 (3)
39 6-1089 Relief Valve Cap Assembly
40 6-1399 Tank Plastic 6.7 Os 22.50 Blk
41 6-1846 Cable Tie 8 Long White
42 6-0875 O-Ring 2-348 Buna
