JOHN BEAN 207 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 3-0362 | Hydraulic Cylinder Assembly |
| 2 | 6-0800 | Sleeve Bearing |
| 3 | 6-0799 | Sleeve Bearing * |
| 4 | 6-0798 | Wiper Ring * |
| 5 | 1-0880 | Gland * |
| 6 | 2-0616 | Piston Rod Weldment |
| 7 | 1-0881 | Piston |
| 8 | 6-0579 | Seal & Wiper Ring * |
| 9 | 1-0725 | Keeper Washer |
| 10 | 6-0581 | External Snap Ring * |
| 11 | 2-0614 | Cylinder Tube Weldment |
| 13 | 1-1726 | Velocity Fuse Assembly |
| 14 | 2-1174 | Neoprene Riser |
| 15 | 2-0163 | Riser, Short |
| 16 | 2-0164 | Riser, Tall |
| 17 | 1-0569 | Lifting Arm |
| 18 | 1-0584 | Scissor Pin B |
| 19 | 6-0076 | Upper Cam Follower |
| 20 | 1-0228 | Spacer |
| 21 | 6-0672 | Hex Nut |
| 22 | 1-0561 | Safety Pin |
| 23 | 1-0562 | Safety Stop |
| 24 | 6-0040 | Jam Nut |
| 25 | 2-0259 | Roller Assembly |
| 31 | 6-0060 | Flat Washer |
| 32 | 6-3889 | Button Head Bolt |
| 33 | 0-0190 | Hydraulic Cylinder Seal Kit * |
| 34 | 1-0130 | Cam Follower |
| 35 | 6-3959 | Loop Clamp |
| 36 | 6-0081 | Spring |
| 37 | 6-0042 | Nylon Locknut |
| 38 | 6-0030 | Hex Head Bolt |
| 39 | 6-0058 | Lockwasher |
| 40 | 1-0608 | Keeper Bracket |
| 41 | 6-0063 | Flat Washer |
| 42 | 6-2450 | Tee Fitting, Jic M C/W Jam Nut |
| 43 | 1-3177 | Hydraulic Hose AssY |
| 44 | 4-0154 | Bottom Frame Weldment |
| 45 | 1-0589 | Lever Weldment |
| 48 | 6-3334 | Air/Hydraulic Pump |
| 59 | 1-2368 | Hydraulic Hose Assembly |
| 60 | 1-0583 | Scissor Pin A |
| 61 | 1-0574 | Center Shaft |
| 63 | 6-0329 | Retaining Ring |
| 64 | 1-0599 | Bottom Hinge Pin |
| 65 | 6-0438 | Set Screw |
| 66 | 6-1881 | Button Head Cap Screw |
| 67 | 6-0072 | Retaining Ring |
| 68 | 1-0598 | Top Hinge Pin |
| 69 | 1-0262 | Arm Stop |
| 70 | 3-0287 | Scissor Arm Assembly |
| 71 | 6-0328 | Thrust Washer |
| 72 | 3-0286 | Top Cover Weldment |
| 6-3334 | Air/Hydraulic Pump | |
| 6-0710 | -Adapter, 3/8 Poly To Npt Male | |
| 6-0178 | 1/4-20 X 3/4lg Gr8 Hex Head Bolt | |
| 6-0060 | 1/4 Sae Flat Washer | |
| 6-0056 | 1/4 Lock Washer | |
| 6-0032 | 1/4-20 Hex Nut | |
| 6-0015 | Elbow |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 6-3348 | Resevoir Cap Assembly |
| 2 | 6-3349 | Release Guide Assembly |
| 3 | 6-3350 | Flow Restrictor Assembly |
| 4 | 6-3351 | Coupler Assembly |
| 5 | 6-3352 | Coupling V-Retainer |
| 6 | 6-3353 | Plunger & Spring Kit |
| 7 | 6-3354 | Hydraulic Cylinder Assembly |
| 8 | 6-3355 | Air Piston Assembly |
| 9 | 6-3356 | Air Motor Assembly |
| 10 | 6-3357 | Coupler Kit |
| 12 | 6-3359 | Relief Valve Assembly |
| 13 | 6-3360 | Base |
| 14 | 6-3361 | Reservoir |
| 15 | 6-3365 | Poppet Guide Assembly |
| 16 | 6-3368 | Boot |
| 17 | 6-3366 | Handle |
| 18 | 6-3367 | Rubber Sleeve |
