HOFMANN EELR703A Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 1-3368 | 3/8 X 19 X 22-1/2 Rubber Pad |
| 2 | 2-2569 | 4 Height Extension Adapter |
| 3 | 2-2570 | 4-1/2 Height Extension Adapter |
| 4 | 6-1379 | 3/4 X 5-1/2 Anchor |
| 5 | 1-3806 | 7/8 X 2-3/4 Piston Top Axle |
| 6 | 2-2561 | 1/4 X 29 Hydraulic Hose M-F |
| 7 | 3-1068 | Cylinder Assembly |
| 8 | 6-3516 | F Pipe X F Pipe Swivel Tee 6-4-4 |
| 9 | 1-3374 | Plastic Lug Nut |
| 10 | 6-4018 | Flow Restrictor |
| 11 | 1-3805 | 3/4 X 2-7/16 Pin |
| 12 | 3-1066 | Lock Leg Assembly |
| 14 | 2-2566 | 11' High Pressure Hose |
| 3-1026 | Pump Stand Bolt |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 6-2298 | Bolt |
| 2 | 6-0774 | Coupling (4 Post Power Pack) |
| 3 | 6-2157 | Plumbing Plug |
| 4 | 6-2158 | Seal Shaft 0.5x1x.25 |
| 5 | 6-2159 | Washer |
| 6 | 62300 | Cordset 16/3 Sjo 8ft 115v Plug |
| 7 | 6-2156 | Wiring Assembly Ac 1ph Fenner |
| 8 | 6-2301 | Package Plug |
| 9 | 6-2157 | Plumbing Plug |
| 10 | 6-2162 | Plumbing Magnet |
| 11 | 6-2302 | Electrical Stakon Nut |
| 12 | 6-2164 | Screw |
| 13 | 6-2165 | Cover Asy Suction |
| 14 | 6-2166 | Clamphoseseadj. Inlet |
| 15 | 6-2303 | Electric Cord Grip 3/4"Npt |
| 16 | 6-2304 | Electric Pipenut |
| 17 | 6-1087 | Valve Cartridge Check |
| 18 | 6-2305 | Valve Load Delay |
| 19 | 6-2167 | Nut |
| 20 | 6-2168 | Washer |
| 21 | 6-1108 | Release Handle AssY |
| 22 | 6-3782 | End Head Univ. |
| 23 | 6-2311 | Elect. Reducer Washer |
| 24 | 6-2169 | Shcs, M6x1 .35mm |
| 25 | 6-2170 | Washer |
| 26 | 6-2600 | Motor(2781-Bc)115/230v,1ph,1hp |
| 27 | 6-1091 | Reservoir Screw |
| 28 | 6-1376 | Breather Filler |
| 29 | 6-0884 | Inlet Hose/Filter Ass'y |
| 30 | 6-1089 | Relief Valve Cap |
| 31 | 6-3783 | Tank 2.0 Gal White |
| 32 | 6-1846 | Cable Tie 8 Long White |
| 33 | 6-1319 | Rv19 |
| 34 | 6-2153 | Compression Tube Nut |
| 35 | 6-2154 | Comp. Tube Sleeve |
| 36 | 6-3786 | Return Tube 1/2 Od 90 Deg |
| 37 | 6-0875 | Reservoir O-Ring |
| 38 | 6-2306 | Pump AssY 0.8 Short Spline |
| 39 | 6-2151 | Spring .48x.063x.42 |
| 40 | 6-0880 | Valve Cartrige Release Manual |
| 41 | 6-2156 | Microswitch W/Snap Lid W-200 |
| 42 | 6-2161 | Plumb. Plug |
| 43 | 6-3466 | Grounding Screw |
| 44 | 6-3996 | Decal |
