Forward RAPTOR Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 Call For Details Carriage Assembly
2 Call For Details Carriage Weldment
3 Call For Details Offside Leg Weldment
4 Call For Details Offside Leg Assembly
5 BH-7500-62A 3/4" Klip-Ring
6 BH-7239-79 Arm Restraint Spring
7 BH-7239-78S Arm Restraint Pin Spacer
8 BH-7239-78 Actuator Pin
9 F-RP-250-1500 1/4" Roll Pin x 1-1/2
10 BH-7089-99A 5" Nesting Pad Extension
11 BH-7239-120 Nesting Pad Extension Kit
12 BH-7235-72 1-1/2" Pad Extension
13 BH-7089-99B 6" Pad Extension
14 BH-7089-98 3" Pad Extension
15 BH-7239-48 Front Inner Arm
16 F-EB-0250-20-1250 1/4-20 x 1-1/4" Elevator Bolt
17 BH-7235-90 Rubber Pad Kit - standard duty
17 BH-7235-90K Rubber Pad Kit - heavy duty
18 BH-7235-90A Rubber Pad - standard duty
18 BH-7235-90AX Rubber Pad - heavy duty
19 BH-7089-97A Adapter Base Only
20 BH-7089-97 Adapter Base and Pad
21 F-FW-0250-USS 1/4" Flat Washer
22 F-NL-0250-20 1/4-20 Nylock Nut
23 Call For Details Inner Arm Stop Screw
24 BH-7239-82A Outer Rear Swing Arm
25 BH-7239-82 Rear Swing Arm Assembly
26 BH-7239-69 Front Swing Arm Assembly
27 BH-7239-69A Outer Front Swing Arm
28 BH-7239-47 Rear Inner Arm
29 Call For Details Long Arm Assembly
30 Call For Details Long Arm
31 F-HC-0375-16-1500 3/8-16 x 1-1/2" Hex Head Capscrew
32 BH-7545-17 Arm Restraint Engage Gear
33 BH-7545-16 Arm Restraint Gear
34 BH-7239-108 Carriage Lock Release Rod
35 F-FW-0375-USS 3/8" Flat Washer
36 BH-7235-65 Cap Nut
37 BH-7235-45 Safety Latch Weldment
38 Call For Details Column
39 Call For Details Column
40 BH-7235-34 Swing Arm Pin
41 BH-7237-86 Spring Latch
42 F-RR-0375 3/8" Klip-Ring
43 BH-7235-63 Latch Wipe Out
44 BH-7203-041 Top Rail Snap Ring
45 F-FW-1250 SAE 1-1/4" SAE Washer
46 BH-7006A Power Unit
47 F-NL-0312-18 5/16-18 Nylock Nut
48 F-HN-0312-18 5/16-18 Hex Nut
49 F-HC-0312-18-1250 5/16-18 x 1-1/4" Hex Head Capscrew
50 BH-7239-109 Hydraulic Hose Kit
51 BH-7236-42 Hydraulic Hose 56"
52 BH-7239-110 Rubber Grommet
53 F-3705-6 3/8" JIC Tee
54 F-HN-0500-13 1/2-13 Hex Nut
55 F-HC-0250-13-1750 1/2-13 x 1-3/4" Hex Head Capscrew
56 F-FW-0500 1/2" Flat Washer
57 BH-7512-89 1/4" Shim (50 Pack)
57 BH-7512-90 1/16" Shim (50 Pack)
57 BH-7512-91 1/8" Shim (50 Pack)
57 BH-7512-92 Shim Assortment (150 Pack)
59 BH-7075-03 Anchor Bolt
60 BH-7011-10 Power Unit Vibration Damper Gasket
61 F-A3405-6-6 9/16" O-ring to 3/8" MJIC Elbow
62 Call For Details 1/4" Push to Lock Plug
63 F-JN-0750-16 3/4-16 Jam Nut
64 F-HN-0750-16 3/4-16 Hex Nut
65 BH-7236-99 Elbow
66 BH-7236-52 By Pass Return Line 34"
67 BH-7239-96 24" Plastic Tie Wrap
68 BH-7236-02 Hyd Cylinder
69 F-NL-0500-13 1/2-13 Nylock Nut
70 BH-7239-111 Cylinder Bushing
71 BH-7239-112 3/8" MNPT Breather
72 F-HC-0500-13-0500 1/2-13 1/2" Hex Head Capscrew
73 BH-7239-113 Overhead Structure
74 F-HC-0250-20-0500 1/4-20 S x 1/2" Hex Head Capscrew
75 BH-7239-104 Overhead Limit Switch Assembly
76 BH-7239-103 Overhead Limit Bar Assembly
77 F-HC-0250-20-2000 1/4-20 x 2" Hex Head Capscrew
78 BH-7239-99 Overhead Switch Spacer
79 F-FLN-0250-20 1/4-20 Flange Lock Nut
80 BH-7237-57 Hydraulic Hose 222"
81 BH-7239-60A Equalizer Cable 33' 4"
82 BH-7239-115 Sheave Assembly
83 BH-7239-116 Sheave Pin
84 Call For Details Column Extension Assembly
85 Call For Details Column Extension Weldment
86 BH-7235-27 Carriage Slider Block
  BH-7239-77-1 Arm Restraint Kit (one arm)
  BH-7239-77-4 Arm Restraint Kit (entire lift)
