Forward DPO9A Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7089-97 Adapter Base and Pad 1-1/4" Pin
2 BH-7239-17 Short Inner Swing Arm
3 BH-7235-41 Outer Front Swing ArmRH
4 BH-7235-34 Swing Arm Pin 8"
5 BH-7239-225 Outer Rear Swing Arm RH
6 BH-7239-21 Inner Rear Swing Arm
7 BH-7235-91 Bumper Strip 4-5/8" Long
8 BH-7089-99B 6" Pad Extension
  BH-7089-98 3" Pad Extension
  BH-7235-72 1-1/2" Pad Extension
9 BH-7203-041 Top Rail Snap Ring
10 BH-7235-66 Cable Sheave 6-1/8" arm lock
11 BH-7239-128 Sheave Bushing assembly
12 BH-7235-00 Cable Sheave 4-3/4"
13 BH-7235-27 Carriage Slider Block
14 BH-7006-01 Power Unit AB-1135, RV19
15 F-HN-0312-18 5/16" - 18 Hex Nut
16 F-NL-0312-18 5/16-18 Nylock Nut
17 F-HC-0312-18-1000 5/16-18 x 1" Hex Head Capscrew
18 F-A3105-6-6 3/8" O-Ring to 3/8" Male JIC
19 BH-7235-67 3/8" JIC 90 Swivel Nut
20 F-HN-0750-16 3/4-16 Hex Nut
21 F-JN-0750-16 3/4-16 Jam Nut
22 F-3405-6-6 Elbow
23 BH-7236-42 Hydraulic Hose 56"
24 BH-7236-39 Hydraulic Hose 62"
25 BH-7239-88 1/8" Cable Clamp Threaded
26 BH-7239-89 Overhead Limit Cable Ring
27 F-JN-0562-18 3/8" Bulkhead Nut
28 F-FW-0562-SAE 9/16" Flatwasher
29 F-3965-6 3/8" JIC Bulkhead Run Tee
30 F-3355SW-6 3/8" JIC 45 Swivel Nut
31 BH-7235-09C Limit Switch Cable 1/16" x 16'
32 BH-7239-90 1/16 Cable Clamp
33 BH-7236-32 3/8" Hose x 86" High Press
34 F-3605-6-6-6 3/8" JIC Branch T to 3/8" MNPT
35 BH-7236-41 Hydraulic Hose 114"
36 BH-7235-08 Equalizer Cable
37 BH-7239-100 Overhead Weldment 113"
38 BH-7235-17 Cylinder Mount Weldment
39 BH-7236-44 Hydraulic Hose 209"
40 F-NL-0500-13 1/2-13 Nylock Nut
41 F-HC-0500-13-5000 1/2-13 x 5" Hex Head Capscrew
42 BH-7236-02 Hydraulic Cylinder
43 Call For Details Column
44 BH-7075-03 3/4" x 5-1/2" Anchor Bolt
45 BH-7235-56 Arm Restraint Plunger 7"
46 BH-7235-51 Arm Restraint Slider Rear
47 BH-7239-42 Carriage Weldment
48 BH-7235-51 Arm Restraint Slider Bar Front 8"
49 BH-7239-226 Outer Rear Swing Arm LH
50 F-HC-0500-13-0750 1/2-13 x 3/4" Hex Head Capscrew
51 F-LW-0500 1/2" Lock Washer
52 BH-7235-42 Inner Front Swing Arm LH
53 Call For Details Power Unit Column






Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 F-EB-0250-20-1000 1/4" x 1" Elevator Bolt
2 BH-7235-90A Rubber Pad - standard duty
  BH-7235-90 Rubber Pad Kit - standard duty
  BH-7235-90AX Rubber Pad - heavy duty
  BH-7235-90K Rubber Pad Kit - heavy duty
3 BH-7089-97 Adapter Base and Pad 1-1/4" Pin
4 F-FW-0250-USS 1/4" Flat Washer
5 F-HN-0250-20 1/4"-20 Hex Nut



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
KIT BH-7235-23 Arm Rest. Kit
1 BH-7235-24E Arm Restraint E-Clip 5/8"
2 BH-7235-51 8" Slider
3 BH-7235-54 Arm Restraint Slider Rear 11.75
4 BH-7235-56 Arm Restraint Plunger 7"
5 BH-7235-25 Arm Restraint Spring
6 F-FW-0625-SAE Arm Restraint Washer 5/8"
-- BH-7235-23C Edge Protector




Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 F-NL-0750-16 3/4-16 Nylock Nut
2 F-FW-0750 3/4" Flatwasher
3 BH-7239-95 Latch Pivot
4 BH-7239-94 Safety Latch
5 F-HC-0750-16-2000 3/4-16 x 2 Hex Head Capscrew
6 F-FW-0375-USS 3/8 Washer
7 BH-7237-19 Lock Release Rod 17"
8 BH-7235-63 Safety Latch Release Pawl
9 BH-7235-65 Cap Nut
10 BH-7237-86 Spring Latch
11 F-CP-094-1500 Cotter Pin 3/32" x 1-1/2"
