Forward CR14 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | H4P-2100G | Column B |
| 1.1 | H4P-2300GHJ | Safety Ladder Weldment |
| 1.2 | H4P-2304 | Bolt, Safety Adjustment |
| 2 | H4P-3000 | Runway, Driving Side |
| 2.1 | H4P-3100 | Runway Weldment, Driving Side |
| 2.2 | H4P-3003 | Cable Sheave |
| 2.3 | H4P-3001 | Bearing |
| 2.4 | H4P-3005 | Shaft, Cable Sheave |
| 3 | H4P-3200 | Runway, Slave Side |
| 4 | H4P-1100G | Cross Beam Weldment |
| 4.1 | H4P-1157 | Cover A |
| 4.2 | H4P-1159 | Cover C |
| 4.3 | H4P-1158 | Cover B |
| 4.4 | H4P-1001 | Top Cover, Cross Beam Ends |
| 4.5 | H4P-1005 | Shaft, Safety Latch |
| 4.6 | H4P-1009 | Shaft, Cable Sheave, Cross Beam Ends |
| 4.7 | H4P-3006 | Locker, shaft |
| 4.8 | H4P-1021 | Slide Block, Cross Beam |
| 4.9 | H4P-1012 | Shaft |
| 4.10 | H4P-1007 | Cable Sheave |
| 4.11 | H4P-1008 | Spacer C |
| 4.12 | H4P-1016 | Connector Air Cylinder |
| 4.13 | QG01-9100 | Air Cylinder |
| 4.14 | H4P-1002 | Safety Latch |
| 4.15 | Call For Price | 6x 22Pin |
| 4.16 | H4P-1015 | Spring |
| 4.17 | H4P-1003G | Safety Latch, Slack Cable |
| 4.18 | H4P-1006 | Spacer B |
| 4.19 | H4P-1011 | Spacer |
| 4.20 | H4P-1004 | Spacer A |
| 4.21 | Call For Price | M5 Nut |
| 4.22 | H4P-1002DC | Safety Latch |
| 4.23 | H4P-1014 | Roll Sleeve |
| 4.24 | Call For Price | cp 14 Snap Ring |
| 4.25 | H4P-1003DCG | Safety Latch, Slack Cable |
| 4.26 | B24-5x 12 | M5x 12 Screw |
| 4.28 | H4P-1020 | Locker, shaft |
| 5 | H4P-R2000 | Approach Ramp |
| 6 | H4P-4100 | Tire Stopper |
| 7 | P3517 1 Phase | Power Unit |
| P3518 3 Phase | ||
| P3519 1 Phase 50 Hz. | ||
| 8 | Call For Price | M10 x 20 Screw |
| 9 | Call For Price | M10 Nuts |
| 11 | TSV86522S | Air Valve |
| 12 | YG18-9100G | Hydraulic Cylinder |
| 13 | Call For Price | M8 x 25Bolts |
| 14 | Call For Price | 0 8 Lock Washer |
| 15 | Call For Price | 0 8 Flat Washer |
| 16 | Call For Price | M8 Nuts |
| 17 | Call For Price | M16 x 40 Bolts, 12.9 Grade |
| 18 | Call For Price | 0 16 Lock Washer |
| 19 | Call For Price | 0 16 Flat Washer |
| 20 | Call For Price | M16 Nuts |
| 21 | Call For Price | M12 x 20 Bolts |
| 22 | Call For Price | 012 Lock Washer |
| 23 | Call For Price | 0 12 Flat Washer |
| 24 | H4P-4006 | Hinge Pin |
| 25 | Call For Price | 0 3 x 40 Cotter Pin |
| 26 | Call For Price | 3/4x 140 Anchor Bolts |
| 27 | Call For Price | M6 x 10 Screw |
| 28 | Call For Price | 0 6 Flat Washer |
| 29 | Call For Price | 0 12 Snap Ring |
| 30 | Call For Price | M8 x 20 Screw |
| 31 | Call For Price | M10 x 20 Bolt |
| 32 | Call For Price | 010 Lock Washer |
| 33 | Call For Price | M6 Oil Zerk |
| 34 | Call For Price | M10 x 16 Screw |
| 35 | Call For Price | 0 2x 25 Cotter Pin |
| 36 | Call For Price | M20 Nuts |
| 37 | Call For Price | M16 x 30 Bolt |
| 38 | CH4-2003 | Bracket |
| 50 | H4D-Y004 | Fitting, Elbow |
| 51 | H4P-5003 | Cable Connector A |
| 52 | H4P-5004 | Cable Connector B |
| 53 | Call For Price | 0 10 Flat Washer |
| 54 | H4D-Y003 | Fitting, Elbow |
| 55 | Call For Price | M27 x 1.5 Nuts |
| 56 | 30400-9053YZ | Fitting, Elbow |
| 57 | H4D-Y002 | Hydraulic Hose |
| 58 | H4P-6000 | Hydraulic Hose |
| 59 | Call For Price | 0 22 Washer |
| 60 | Call For Price | M22 x 2.5 Lock Nuts |
| 61 | H4P-5002-2 | Cable 219 |
| 62 | H4P-5002-1 | Cable 156 |
| 63 | H4P-5002-4 | Cable 422-1/2 |
| 64 | H4P-5002-3 | Cable 360 |
| 65 | H4P-2200G | Column C |
| 66 | H4P-R1100G | ColumnA |
| 67 | B11-10x25 | M10 * 25 Screw |
| 68 | H4P-3002 | Bracket |
| 71 | B41-12 | 012 FlatWasher |
| 72 | 30400-1999 | Washer |
| 74 | H4P-R3100 | WheelStop |
| 75 | H4P-R3101 | Angle Iron |
| 76 | H4P-R3102 | Rubber |
| 77 | Call For Price | M5* 16 Screw |
| 78 | Call For Price | 05Washer |
| 79 | Call For Price | M5 Nut |
| 80 | FA7366 | Drum Switch Box Assembly |
| 81 | Call For Price | M5 x 10 PHMS, Plated |
