Forward 9000B Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7239-127 | Top Cable Sheave Support |
| 2 | F-HC-0500-13-2500 | 1/2-13 x 2-1/2 Hex Head Capscrew |
| 3 | F-HN-0500-13 | 1/2-13 Hex Nut |
| 4 | F-FW-0500-USS | 1/2" Washer |
| 5 | BH-7235-00 | Cable Sheave 4-3/4" |
| 6 | BH-7236-37 | Hydraulic Hose 117" |
| 7 | Call For Details | 3/8" Pipe Plug |
| 8 | BH-7235-67 | Fitting |
| 9 | F-SB-0250-20-1250 | 1/4-20 x 1-1/4 Shoulder Bolt |
| 10 | F-NL-0250-20 | 1/4-20 Nylock Nut |
| 12 | BH-7089-99B | 6" Nesting Pad Extension |
| BH-7089-99A | 5" Nesting Pad Extension | |
| BH-7089-98 | 3" Nesting Pad Extension | |
| BH-7235-72 | 1-1/2" Nesting Pad Extension | |
| 15 | Call For Details | 3/8" x 1/2" long Self Tapping Screw |
| 17 | BH-7089-97 | Adapter Base and Pad 1-1/4" Pin |
| 18 | BH-7235-90A | Rubber Pad - standard duty |
| BH-7235-90 | Rubber Pad Kit - standard duty | |
| BH-7235-90AX | Rubber Pad - heavy duty | |
| BH-7235-90K | Rubber Pad Kit - heavy duty | |
| 19 | F-EB-0250-20-1250 | 1/4-20 x 1-1/4 Elevator Bolt |
| 20 | F-HN-0250-20 | 1/4-20 Hex Nut |
| 21 | F-FW-0250-USS | 1/4" Washer |
| 24 | Call For Details | 3/8" JIC x 3/8 NPT Elbow |
| 25 | Call For Details | 3/8" x 6 Schedule 80 Pipe Nipple |
| 26 | BH-7236-50 | Hydraulic Hose 68" |
| 27 | Call For Details | Power Unit Column |
| 28 | BH-7239-128 | Sheave Bushing |
| 29 | BH-7203-041 | Top Rail Snap Ring |
| 30 | BH-7239-129 | 7" Cable Sheave |
| 31 | BH-7006-01 | Power Unit |
| 32 | F-HN-0312-18 | 5/16-18 Hex Nut |
| 33 | F-NL-0312-18 | 5/16-18 Nylon Insert Lock Nut |
| 34 | F-HC-0312-18-1250 | 5/16-18 x 1-1/4" Hex Head Capscrew |
| 35 | BH-7235-67 | 9/16" O-Ring to 3/8" JIC Elbow |
| 36 | BH-7236-01 | Hydraulic Cylinder Prince 36" |
| BH-7235-10 | Seal Kit for Waltco Cylinder | |
| BH-7235-11 | Seal Kit for TMS Cylinder | |
| BH-7235-12 | Seal Kit for Holmac Cylinder | |
| BH-7235-12A | Seal Kit for Prince Cylinder | |
| 37 | Call For Details | Lift Chain |
| 38 | BH-7236-10 | Chain Yoke Roller with Bearing |
| 39 | BH-7238-78 | Bearing Shaft Weldment |
| 40 | BH-7239-132 | Bearing 1-1/4" Dia. x 1-3/4 Lg. |
| 41 | F-RR-1250 | 1-1/4" Snap Ring |
| 42 | BH-7235-09F | Equalizer Cable 29' 7" |
| BH-7235-04 | Equalizer Cable 31' 6" | |
| 43 | F-NL-0625-11 | 5/8-11 Nylock Nut |
| 44 | BH-7235-64 | Latch Pivot |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7235-34 | Arm Pin |
| 2 | BH-7545-16 | Main Restraint Gear |
| 3 | F-RP-0250-1500 | 1/4" X 1-1/2" Roll Pin |
| 4 | F-HC-0375-18-1500 | 3/8-16 x 1-1/2" Hex Head Capscrew |
| 5 | BH-7545-17 | Arm Restraint Engage Gear |
| 6 | BH-7239-78 | Arm Restraint Pin |
| 7 | BH-7239-79 | Arm Restraint Spring |
| 8 | BH-7239-77-1 | Arm Restraint Kit (one arm) |
| 9 | BH-7239-77-4 | Arm Restraint Kit (entire lift) |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| BH-7237-30 | Safety Release Assembly (Model and Serial # are required when ordering) | |
| 1 | BH-7239-124 | Slack Chain Rod |
| 2 | BH-7239-78 | Arm Restraint Pin |
| 3 | BH-7239-79 | Arm Restraint Spring |
| 4 | BH-7239-78SP | Arm Restraint Pin and Spring Kit |
| 5 | BH-7239-206 | Slack Chain Lever Linkage |
| 6 | BH-7239-207 | Slack Chain Spring |
| 7 | BH-7239-208 | Slack Chain Lock |
| 8 | BH-7237-19 | Lock Release Rod 17" |
| 9 | BH-7237-86 | Spring Latch |
| 10 | Call For Details | Hex Nut |
| 11 | F-FW-1000-USS | 1 Flat Washer |
| 12 | Call For Details | Retaining Ring |
| 13 | BH-7235-27 | Carriage Slider Block |
| 14 | BH-7235-45 | Latch Weldment |
| 15 | BH-7235-63 | Latch Wipeout |
| 16 | BH-7235-65 | Cap Nut |
| 17 | F-FW-0375-USS | 3/8 Washer |
