Forward 12000AR Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7238-52 | Column |
| 2 | Call For Details | Cross Rail Assembly |
| 3 | BH-7238-51 | Column Muffler Main |
| 4 | BH-7238-50 | Column Muffler Main Power |
| 5 | Call For Details | Top Rail |
| 6 | BH-7006A | Power Unit |
| 7 | F-HN-0312-18 | 5/16-18 Hex Nut |
| 8 | F-HC-0312-18-1000 | 5/16-18 x 1 Hex Head Capscrew. |
| 9 | F-HN-0500-13 | 1/2-13 Hex Nut |
| 10 | F-FW-0500 | 1/2" Flat Washer |
| 11 | F-LW-0500 | 1/2" Lock Washer |
| 12 | F-HN-0750-10 | 3/4-10 Nut for Safety Rod |
| 13 | F-NL-1000-14 | 1-14 Nylock Nut |
| 14 | F-FW-1000-SAE | 1" Flat Washer |
| 15 | BH-7238-81 | Safety Rod |
| 16 | BH-7237-59 | Hydraulic Hose 45" |
| 17* | BH-7028 | Chain for Cross Rail 271 pitches |
| Call For Details | Chain Top Rail Short 155 pitches | |
| Call For Details | Chain Top Rail Long 402 pitches | |
| 18 | F-SB-0312-18-1500 | 5/16 x 1-1/2 Shoulder Bolt |
| 19 | F-FW-1125 | 1-1/8 Flat Washer |
| 20 | BH-7028-01 | Master Link |
| Call For Details | Master link | |
| 21 | F-NL-1125-12 | 1-1/18-12 Nylock Nut |
| 22 | BH-7075-03 | 3/4 x 5-1/2 Anchor Bolt |
| 23 | F-HC-0500-13-1750 | 1/2-13 x1-3/4 Hex Head Capscrew |
| 24 | BH-7236-49 | Hydraulic Hose 106" |
| 25 | BH-7238-62 | Track End Stop |
| 26 | BH-7238-83 | Drive On Ramp |
| BH-7238-82 | Ramp Wheel |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7238-76 | Locknut |
| 2 | Call For Details | Washer |
| 3 | BH-7203-041 | Top Rail Snap Ring |
| 4 | BH-7238-90 | Top Rail Latch Ear |
| 5 | BH-7235-69 | Lock Nut |
| 6 | BH-7237-88 | Latch Cam |
| 7 | BH-7236-03 | Hydraulic Cylinder Price 72" |
| BH-7235-13 | Hyd Cylinder Seal Kit 72" Waltco | |
| BH-7235-13C | Hyd Cylinder Seal Kit 72" Prince | |
| BH-7235-16 | Hyd Cylinder Seal Kit 72" Holmac | |
| 8 | BH-7238-92 | Top Rail Wheel |
| 9 | Call For Details | Chain Top Rail Short 155 pitches |
| Call For Details | Chain Top Rail Long 402 pitches | |
| 10 | BH-7238-64 | Chain Pin |
| 11 | BH-7238-94 | Cylinder-Chain Connector |
| 12 | BH-7238-90 | Top Rail Latch Ear |
| 13 | BH-7238-93 | Top Rail Latch Pivot Pin |
