Direct Lift PROV10 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | Call For Details | Column |
| 2 | Call For Details | Up-Column |
| 3 | Call For Details | Cross Beam A |
| 4 | Call For Details | Column B |
| 5 | Call For Details | Cross Beam B |
| 6 | Call For Details | Power Unit |
| 7 | Call For Details | Front Arm |
| 8 | Call For Details | Swing Arm Pin |
| 9 | Call For Details | Carriage |
| 10 | Call For Details | New Long Arm |
| 11 | Call For Details | Half Moon Gear, Arm Lock |
| 12 | Call For Details | Lock Washers 010 |
| 13 | Call For Details | Bolt M10x35 |
| 14 | Call For Details | Front Arm |
| 15 | BH-7270-061 | Lift Pad |
| 16 | BH-7560-04 | Rubber Pad |
| 17 | Call For Details | M6x20 Pad Screw |
| 18 | BH-7274-074 | Adapter B |
| 19 | BH-7274-073 | Adapter A |
| 20 | BH-7075-03 | Anchor Bolt 3/4"x140 |
| 21 | Call For Details | Bolt M8x35 |
| 22 | Call For Details | Flat Washers 08 |
| 23 | Call For Details | Washer |
| 24 | Call For Details | Lock Washers 08 |
| 25 | Call For Details | Nut M8 |
| 26 | Call For Details | Bolt M12x40 |
| 27 | Call For Details | Flat Washers 012 |
| 28 | Call For Details | Lock Washers 012 |
| 29 | Call For Details | Nut M12 |
| 30 | BH-7274-075 | Shaft |
| 31 | Call For Details | Pipe A |
| 32 | BH-7270-013 | 4.75 Chain Sheave |
| 33 | Call For Details | Pipe B |
| 34 | BH-7270-090 | Stop Non-Rotator Bar |
| 35 | Call For Details | M8x20 Bolt |
| 36 | Call For Details | Hose Guide Plate |
| 37 | Call For Details | Flat Washers 06 |
| 38 | Call For Details | Lock Washers 06 |
| 39 | Call For Details | M6 Nut |
| 40 | Call For Details | Hydraulic Hose Guide |
| 41 | Call For Details | Bolt M6x20 |
| 42 | Call For Details | Bolt M12x25 |
| 43 | BH-7270-083 | Cable Sheave |
| 44 | Call For Details | Nylon Lock Nut M6 |
| 45 | BH-7270-082 | Cable Sheave Bracket A |
| 46 | Call For Details | Screw M6x25 |
| 47 | Call For Details | CLPE |
| 48 | Call For Details | Screw M6x16 |
| 49 | Call For Details | 7" Board |
| 50 | Call For Details | 3" Board |
| 51 | Call For Details | Pin |
| 52 | Call For Details | Lifting Pad A (Option) |
| 53 | Call For Details | Lifting Pad |
| 54 | Call For Details | Cable Sheave |
| 55 | Call For Details | Sheave Axes |
| 56 | Call For Details | Bolt M8x16 |
| 57 | Call For Details | Board |
| 58 | BH-7270-069 | Rub Blocks |
| 59 | Call For Details | Arm Lock Pin |
| 60 | Call For Details | Spring |
| 61 | Call For Details | Gear Rack |
| 62 | Call For Details | Roll Pin 6x40 |
| 63 | Call For Details | Pipe |
| 64 | Call For Details | Snap Ring 025 |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | Call For Details | Hydraulic Hoses |
| 2 | BH-7270-054 | T Fitting |
| 3 | Call For Details | Hydraulic Hoses |
| 4 | Call For Details | Cylinders |
| 5 | Call For Details | Line Connecting |
| 6 | Call For Details | Steel & Rubber Washer 14 |
| 7 | Call For Details | Pipe |
| 8 | Call For Details | Power Unit |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | Call For Details | Shut-Off Cable |
| 2 | Call For Details | Aluminum Clevis |
| 3 | Call For Details | Bolt M6x50 |
| 4 | Call For Details | M6 Nut |
| 5 | Call For Details | Flat Washers 06 |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | Call For Details | 2.5 L= 7686 Cable |
| 2 | BH-7274-077 | Cable 391" long |
| 3 | Call For Details | Flat Washers 020 |
| 4 | Call For Details | Nylon Lock Nut 3/4-16 |
| 5 | Call For Details | Carriage |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7270-103 | Shaft for Latch |
| 2 | Call For Details | Screw M10x16 |
| 3 | BH-7270-104 | Sleeve |
| 4 | BH-7270-106 | Spring |
| 5 | BH-7270-108 | Safety Latch |
| 6 | BH-7270-111 | Turn Board |
| 7 | Call For Details | M6 Nut |
| 8 | Call For Details | M6x35 Bolt |
| 9 | BH-7270-110 | Turn Board |
| 10 | BH-7270-109 | Turn Pin |
| 11 | Call For Details | Special Shoulder Bolt |
| 12 | Call For Details | Flat Washer 010 |
| 13 | Call For Details | Lock Washers 010 |
| 14 | Call For Details | Nut M10 |
| 15 | BH-7270-114 | Safety Release Handle |
| 16 | BH-7270-115 | Plastic Knob M10x35 |
| 17 | Call For Details | Flat Washers 06 |
| 18 | Call For Details | Screw M6x16 |
| 19 | BH-7270-112 | Safety Latch Cover A |
| 20 | BH-7270-107 | Spring |
| 21 | BH-7270-105 | Sleeve |
| 22 | BH-7270-113 | Cable Sheave Bracket B |
| 23 | Call For Details | Lock Washers 06 |
| 24 | Call For Details | Bolt M6x16 |
| 25 | BH-7270-083 | Cable Sheave |
| 26 | Call For Details | Nylon Lock Nut M6 |
| 27 | BH-7270-102 | Safety Latch Cover B |
