Direct Lift PRO 9F Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7270-056 Column Weldment, Power Unit
2 BH-7270-057 Column Weldment, Driven
3 Call For Details Power Unit
4 Call For Details 08 Flat Washer
5 Call For Details M8x35
6 Call For Details Shock Absorption Washer
7 BH-7270-058 Carriage Weldment
8 Call For Details 08 Lock Washer
9 Call For Details M8 Nut
10 BH-7270-059 Rocker
11 BH-7270-060 Shaft
12 BH-7270-061 Bracket Weldment
13 BH-7270-048 Rubber Insert
14 Call For Details Socket Head Screw
15 Call For Details 012 Flat Washer
16 Call For Details 012 Lock Washer
17 Call For Details M12x35 Hex Head Bolt
18 BH-7270-062 Mudsill Weldment
19 Call For Details M12x40 Hex Head Bolt
20 BH-7075-03 Anchor Bolt 3/4" x 5-1/2"
21 BH-7270-007 Adapter B
22 BH-7270-008 Adapter A
23 BH-7270-063 Top Sheave Weldment
24 BH-7270-013 4.75" Cable Sheave
25 Call For Details Flat Washer
26 Call For Details 025 Snap Ring
27 Call For Details M12 Nut
28 BH-7270-014 Hydraulic Cylinder
29 BH-7270-015 Leaf Chain
30 BH-7270-016 Pin, Leaf Chain
31 Call For Details 02x20 Cotter Pin
32 BH-7270-064 Cable Wheel
33 BH-7270-018 Cable Wheel Shaft
34 BH-7270-065 Cable (call to verify)
  BH-7274-076 Cable (call to verify)
35 BH-7270-066 Hydraulic Hose
36 BH-7270-024 Fitting, Right Angle
37 BH-7270-025 Inside & Outside Fitting, Right Angle
38 BH-7270-067 Bulkhead Fitting, Right Angle
39 Call For Details Hose Clip
40 Call For Details Cross Screw M6x8
41 BH-7270-021 Fitting, 45 Angle
42 BH-7270-068 Hydraulic Hose



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7270-115 Plastic Knob
2 Call For Details M10 Nut
3 Call For Details 010 Lock Washer
4 Call For Details 010 Flat Washer
5 BH-7270-028 Gear Rack
6 BH-7270-029 Spacer
7 BH-7270-030 Spring
8 BH-7270-031 Pull Handle
9 Call For Details 03x26 Parallel Pin
10 BH-7270-058 Carriage Weldment
11 BH-7270-069 Rubber Block
12 Call For Details Fastener Screw M6x35, NCHB
13 Call For Details Hex Head Bolt M20x50, Grade 8.8
14 BH-7270-033 Spring
15 BH-7270-034 Spring
16 Call For Details 020 Lock Washer
17 Call For Details M20 Nut
18 BH-7270-035 Bushing
19 BH-7270-036 Safety Block Organ
20 Call For Details 035 Snap Ring
21 Call For Details 036 Flat Washer
22 Call For Details Socket Head Screw
23 BH-7270-037 Chain Lock
24 Call For Details Flat Washer 08
25 BH-7270-070 Connecting Rod Clevel
26 BH-7270-071 Chain Lock Weldment
27 Call For Details 3/16" Cap Nut
28 Call For Details M8 Nylon Insert Nut
29 BH-7270-072 Spring
30 Call For Details M8 Nut
31 Call For Details Washer
