Direct Lift PRO 9D Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7270-073 Column A, Slave Side
2 BH-7270-074 Column B, Master Side
3 BH-7270-075 Upright
4 BH-7270-076 Cross Beam Assembly
5 BH-7006-01 Power Unit
6 Call For Details M12x40 Hex Bolt
7 Call For Details 012 Flat Washer
8 Call For Details 012 Lock Washer
9 Call For Details M12 Hex Nuts
10 Call For Details M8x25 Hex Bolt
11 Call For Details 08 Flat Washer
12 Call For Details Washer
13 BH-7270-047 Saddle Pad Assembly
14 Call For Details 08 Lock Washer
15 Call For Details M8 Hex Nuts
16 BH-7270-077 Front Arm B
17 BH-7270-045 Long Arm
18 BH-7270-078 Lifting Pad Assembly
19 BH-7270-005 Lift Pad Weldment
20 BH-7560-04 Rubber Pad
21 Call For Details M6x20 Pad Screw
22 BH-7270-079 Adapter Weldment
23 BH-7270-080 Rubber Pad
24 Call For Details M6x16 Screw
25 BH-7270-046 Front Arm A
26 Call For Details Carriage
27 BH-7270-004 Arm Pin
28 BH-7075-03 3/4"x 5-1/2" Anchor Bolt
29 BH-7270-007 Short Truck Adapter
30 BH-7270-008 Tall Truck Adapter B
31 Call For Details M6x16 Hex Bolt
32 Call For Details 06 Lock Washer
33 Call For Details 06 Flat Washer
34 BH-7270-081 Hydraulic Hose Guide
35 Call For Details M6x25 Screw
36 BH-7270-082 Cable Pulley Bracket A
37 BH-7270-083 Lock Release Cable Pulley
38 Call For Details M6 Nylon Lock Nut
39 BH-7270-084 Overhead Cross Beam, Section A
40 BH-7270-085 Overhead Cross Beam, Section B
41 Call For Details M12x25 Hex Bolt
42 BH-7270-086 4" Cable Pulley
43 BH-7270-087 Spacer A
44 BH-7270-088 Spacer B
45 BH-7270-089 Top Cable Pulley Shaft
46 BH-7270-090 Stop Non-Rotator Bar
47 Call For Details M8x16 Hex Bolt
48 BH-7270-091 Hydraulic Cylinder
49 Call For Details M6x8
50 BH-7270-092 Cover
51 BH-7270-032 UHWM Sliding Bearing Block
52 Call For Details M10x035 Knob
53 Call For Details M10 Hex Bolt
54 Call For Details 010 Lock Washer
55 Call For Details 010 Flat Washer
56 BH-7270-028 Gear Rack
57 BH-7270-029 Spacer
58 BH-7270-030 Spring
59 BH-7270-031 Gear Rack Shaft
60 Call For Details 03x26 Roll Pin
61 BH-7270-093 Equalizing Cable
62 BH-7270-094 Safety Release Cable
63 Call For Details M6x12 Bolt
64 BH-7270-095 Cable Pulley Shaft
65 BH-7270-013 4.75" Cable Sheave
66 BH-7270-096 Hydraulic Hose A
67 BH-7270-081 Hydraulic Hose Guide
68 BH-7270-099 T-Fitting
69 BH-7270-097 Hydraulic Hose B
70 BH-7270-098 Hydraulic Hose C
71 BH-7270-024 90 Fitting
72 BH-7270-100 Pipe Fitting
73 BH-7270-101 Shut-Off Cable
74 Call For Details M6x50 Bolt
75 Call For Details Aluminum Clevis



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7270-102 Cover B
2 BH-7270-103 Latch Shaft
3 BH-7270-104 Bushing A
4 BH-7270-106 Spring A
5 BH-7270-108 Safety Latch
6 BH-7270-109 Threaded Shaft
7 BH-7270-110 Safety Cam Plate, Slave Side
8 Call For Details M8 Nut
9 BH-7270-107 Spring B
10 BH-7270-105 Bushing B
11 Call For Details M10x16 Hex Head Screw
12 Call For Details M6x35
13 BH-7270-113 Cable Pulley Bracket B
14 BH-7270-083 Lock Release Cable Pulley
15 Call For Details M6 Nylon Lock Nut
16 Call For Details 06 Flat Washer
17 Call For Details 06 Lock Washer
18 Call For Details M6x16 Hex Bolt
19 Call For Details M6x8 Screw
20 Call For Details Knob
21 BH-7270-112 Cover A
22 BH-7270-111 Safety Cam Plate, Master Side
23 Call For Details 010 Flat Washer
24 Call For Details M6 Nut
25 Call For Details 010 Lock Washer
26 Call For Details Nut M10
27 BH-7270-114 Safety Release Handle
