BENWIL TPO-55 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7200-50 | Chain Wheel |
| 2 | BH-7200-51 | Metal Spacer |
| 3 | BH-7204-014 | Spacer C |
| 4 | BH-7200-52 | Axle (Driver Post) |
| 4 | BH-7200-53 | Axle (Follower Post) |
| 4 | BH-7200-54 | Axle (Cylinder Yoke) |
| 5 | BH-7200-55 | Cylinder |
| 5 | BH-7200-56 | Cylinder Seal Kit |
| 6 | BH-7200-83 | Safety Bar |
| 7 | BH-7200-57 | Return Spring |
| 8 | BH-7200-58 | Spring Stopper |
| 9 | BH-7211-64 | Leaf Chain Long |
| 10 | Call for Details | Leaf Chain Short |
| 11 | BH-7200-61 | Chain Bracket/Yoke |
| 12 | BH-7204-030 | Control Arm |
| 13 | BH-7200-63 | Control Lever |
| 14 | BH-7203-116 | Grip |
| 15 | BH-7200-64 | Crank Collar |
| 16 | BH-7200-65 | Lock Control Handle |
| 17 | BH-7200-66 | Driver Crank Support |
| 18 | BH-7200-67 | Crank Pin |
| 19 | BH-7200-68 | Rod End Pin Holder |
| 20 | BH-7200-69 | Rod End Pin Holder |
| 22 | BH-7200-71 | Crank |
| 23 | BH-7200-72 | Crank Collar |
| 24 | BH-7200-73 | Crank Rod |
| 25 | BH-7200-74 | Control Lever |
| 26 | BH-7200-75 | Collar |
| 27 | BH-7200-70 | Driver Crank |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7200-25 | Side Roller Assembly |
| 2 | BH-7200-26 | Side Roller Bracket |
| 3 | BH-7201-80 | Roller Assembly |
| 4 | Call for Details | Hook Shaft |
| 5 | Call for Details | Lowering Stop |
| 6 | F-RP-125-1125 | Roll Pin |
| 7 | BH-7215-07 | Hinge Pin |
| 8 | F-RP-125-1500 | Roll Pins |
| 9 | BH-7200-31 | Hook Spring |
| 10 | Call for Details | Lowering Stop |
| 11 | BH-7200-33 | Cover |
| 12 | BH-7204-051 | Door Stop Rubber |
| 13 | BH-7200-34 | Spring |
| 14 | BH-7200-35 | Cover Spring |
| 15 | BH-7209-26 | Round Head Screws |
| 16 | BH-7200-37 | Snap Ring |
| 17 | BH-7200-38 | Catch Gear Collar |
| 18 | BH-7200-39 | Safety Arm - Driver Post |
| 19 | BH-7200-40 | Main Out Lever - Drive Post |
| 20 | BH-7200-41 | Catch Gear Shaft |
| 21 | BH-7200-42 | Sub Out Lever - Follower Post |
| 22 | BH-7200-43 | Safety Arm - Follower Post |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7205 | Rubber Arm Pad |
| 2 | BH-7205-01 | Round Head Screw |
| 3 | BH-7205-02A | Steel Support |
| 3 | BH-7205-02OV | Steel Support |
| 4 | BH-7204-002 | Lift Arm Pin |
| 5 | BH-7204-052 | Washer |
| 6 | BH-7204-006 | Arm Pin Nut |
| 7 | BH-7201-67 | Arm Lock Fitting Pin |
| 8 | BH-7204-053 | Hex Bolt |
| 9 | BH-7203-343 | Lock Washer |
| 10 | BH-7204-054 | Snap Ring |
| 11 | BH-7200-10 | Inner Bar - Restraint |
| 12 | BH-7200-11 | Outer Pipe - Restraint |
| 13 | BH-7200-10A | Complete Arm Rest. 12-5/8" Long |
| 13a | BH-7200-10B | Arm Restraint Mount Bracket |
| 14 | BH-7204-008S | Arm (Right - Short) |
| 14 | BH-7204-008L | Arm (Right - Long) |
| 14 | BH-7204-009S | Arm (Left - Short) |
| 14 | BH-7204-009L | Arm (Left - Long) |
| 15 | BH-7204-007S | Slide Arm |
| 14 | BH-7204-010 | Swing Arm Assembly (Right) |
| 14 | BH-7204-011 | Swing Arm Assembly (Left) |
| 16 | BH-7204-003 | Screw Stopped |
| 17 | BH-7204-004 | Serrated Washer |
| 18 | BH-7204-005 | Screw |
| 19 | BH-7200-12 | 5-1/2" Height Extension |
| 19 | BH-7200-12L | 9" Slip-On Height Ext. |
| 20 | BH-7201-69 | Lock Pin |
| 21 | BH-7201-72 | Roll Pin |
| 22 | BH-7201-70 | Lock Spring |
| 23 | BH-7201-73 | Lock Handle |
