BENWIL TP-9 Parts Breakdown




Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7209-36 00067780 Arm Pin
2 BH-7209-10 00067680 Arm Restraint Assembly
3 BH-7214-02 50509901 Rubber Arm Pad (small)
4 Call For Details 00067700 Adapters
5 BH-7209-09 00067800 Left Lift Arm
5A BH-7209-08 00067720 Right Lift Arm
6 BH-7209-07 00067740 Inner Slide Arm (Right & Left)
7 BH-7209-34 00041371 Chain Wheel
8 BH-7209-35 00067920 Chain Wheel Shaft
9 BH-7209-37 10282360 Lower Pulley Collar
10 BH-7200-63 00043501 Control Shaft
10 BH-7200-75 10161831 Control Shaft Collar
10 BH-7200-74 10161852 Control Lever
10 BH-7209-38 10181022 Crank Pin
11 BH-7203-116 50561801 Vinyl Grip
12 BH-7032 80835427 Leaf Chain
13 BH-7209-39 80839331 Cotter Pin
14 BH-7209-40 00067880 Chain Rod
15 BH-7209-41 10281780 Chain Wheel
16 BH-7209-42 81705030 Oilite Bearing
17 BH-7039 80837049 Leaf Chain
18 BH-7201-80 00043161 Guide Roller Assembly
19 BH-7209-45 10281800 Chain Wheel Shaft
20 BH-7209-46 00067620 Chain Bracket/Yoke
21 BH-7209-47 90960816 Socket Head Capscrew
22 BH-7209-48 80845022 Snap Ring
23 BH-7209-49 10166301 Chain Fitting Plate
24 BH-7209-50 80839700 Offset Link Pin
25 BH-7209-51 90973017 Cotter Pin
26 BH-7209-52 00097200 Cylinder Assembly
27 BH-7204-100 00068040 Cylinder Seal Kit



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7214-02 Rubber Arm Pad (Square)
2 BH-7209-02 Round Head Small Screw
3 BH-7209-03A Screw Up Adapter Only
4 BH-7209-03 Adjust Nut w/Screw Up Adapter
5 BH-7209-05 Adapter Adjuster Stopper
6 BH-7209-06 Serrated Washer
7 BH-7204-005 Flat Head Small Screw
8 BH-7209-07 Slide Arm for TP-9
9 BH-7209-08 Right Lift Arm
9 BH-7209-09 Left Lift Arm
10 BH-7209-10 Arm Restraint Assembly
11 BH-7209-11 Hex Bolt
12 BH-7203-343 Spring Washer
13 BH-7209-12 Guide Roller Assembly
14 BH-7203-041 Snap Ring
15 BH-7209-13 Side Roller
16 BH-7209-14 Power Post Safety Device Assembly
16 BH-7209-15 Slave Post Safety Device Assembly
17 BH-7209-16 Power Post Carriage
17 BH-7209-17 Slave Post Carriage
18 BH-7209-18 Power Post Cover
18 BH-7209-19 Slave Post Cover
19 BH-7209-20 Rubber Car Door Bumper
20 BH-7209-21 Power Post Safety Arm
21 BH-7209-22 Power Post Safety Bolt
22 BH-7209-23 Spring
23 BH-7209-24 Power Post Safety Bracket
24 BH-7209-25 Power Post Hook Cover Spring
25 BH-7201-42 Spring Washer
26 BH-7209-26 Round Head Small Screw
27 BH-7209-27 Power Post Safety Shaft
28 BH-7214-01 Return Spring
29 BH-7209-29 Slave Post Left Safety Arm
30 BH-7209-30 Return Spring
31 BH-7209-31 Slave Post Right Safety Arm
32 BH-7209-32 Spring
33 F-CV-312-1750 Lock Fitting Pin
34 F-HN-0250-11 Hex Nut
