BENWIL GPO-55 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7205 | Rubber Arm Pad |
| 2 | BH-7205-01 | Round Head Screw |
| 3 | BH-7205-02 | Adj. Support w/Nut |
| 4 | BH-7205-05 | Short Slide Arm |
| 4 | BH-7205-07 | Long Slide Arm |
| 5 | BH-7205-11 | Short Arm R |
| 5 | BH-7205-09 | Short Arm L |
| 5 | BH-7202-32 | Long Arm R |
| 5 | BH-7205-10 | Long Arm L |
| 6 | BH-7200-10A | Arm Restraint Assembly |
| 6 | BH-7202-30 | Arm Restraint Assy. "B" 10-5/8" |
| 7 | BH-7201-12 | Lift Arm Pin |
| 8 | BH-7201-81 | Truck Height Adapter |
| 9 | BH-7201-93 | Limit Switch w/Cover for Standard "B" Models |
| 10 | BH-7202-21 | Upper Limit Stop |
| 11 | BH-7202-22 | Limit Switch Assembly |
| 12 | BH-7201-09 | Chain Wheel C Assembly |
| 13 | BH-7201-87 | Chain Wheel Shaft Assembly |
| 14 | BH-7201-02 | Carriage Chain Plate |
| 15 | BH-7201-88 | Chain Fitting Pin |
| 16 | BH-7201-10 | Sub Chain Wheel Assembly |
| 17 | BH-7201-89 | Left Side Base |
| 18 | BH-7201-90 | Right Side Base |
| 19 | F-RR-1562 | Retaining Ring 1-9/16" |
| 20 | BH-7006-01 | Single Phase Power Unit |
| 21 | Call For Details | Leaf Chain-Verify Type |
| 22 | BH-7202-25 | Chain Adjuster |
| 23 | BH-7030-01 | Connecting Link |
| 24 | BH-7201-91 | Safety Bar Holder |
| 25 | BH-7201-92 | Safety Bar |
| 26 | BH-7201-90B | Chain Case |
| 27 | BH-7201-90C | Chain Case - Short |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7201-24 | Cylinder |
| 1 | BH-7215-11 | Cylinder Seal Kit Bolted Mounting Bracket |
| 1 | BH-7214-20 | Cylinder Seal Kit Welded Mounting Bracket |
| 2 | F-RR-1187 | 1-3/16" Snap Ring |
| 3 | BH-7031 | Leaf Chain 57 Pitches |
| 4 | BH-7201-27 | Chain Wheel A Assembly |
| 5 | BH-7201-28 | Chain Wheel Shaft |
| 6 | BH-7201-29 | Chain Bracket/Yoke |
| 7 | BH-7201-25 | Post Chain Plate |
| 8 | BH-7201-03 | Chain Fitting Pin |
| 9 | BH-7202-34 | Chain Pin |
| 10 | BH-7201-02 | Carriage Chain Plate |
| 11 | BH-7030 | Leaf Chain |
| 12 | BH-7201-80 | Guide Roller Assembly |
| 13 | BH-7201-95 | Side Roller Collar |
| 14 | BH-7201-96 | Bearing |
| 15 | BH-7201-00 | Side Roller |
| 16 | F-RP-187-1125 | Roll Pin |
| 17 | BH-7201-97 | Side Roller Shaft |
| 18 | BH-7201-98 | Motor Side Carriage |
| 19 | BH-7201-99 | Hook Shaft Assembly 7/8" |
| 19 | BH-7201-99A | Hook Shaft Assembly 1" |
| 20 | BH-7201-46 | Hook Shaft Collar |
| 21 | BH-7201-45 | Spring |
| 22 | BH-7202-35 | Safety Cam |
| 23 | F-RP-250-1250 | Roll Pin |
| 24 | BH-7201-41 | Door Bumper |
| 25 | BH-7201-43 | Door Bumper Plate |
| 26 | BH-7201-51 | Catch Gear |
| 27 | BH-7201-52 | Catch Gear Spring |
| 28 | BH-7201-56 | Slave Door Bumper |
| 29 | Call For Details | Slave Side Carriage |
| 30 | BH-7202-33 | Catch Gear Shaft |
| 31 | F-RR-1000 | Retaining Ring |
