Bear 63-145 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 6-0650 | Power Pack, 230v/1ph |
| 2 | 4-0186 | Power Post |
| 3 | 3-0487 | Safety Rack |
| 4 | 4-0222 | Alignment Deck Wldmt, (Left Side) |
| 5 | 4-0190 | Front Crossmember Weldment |
| 6 | 2-0998 | Front Wheel Stop |
| 7 | 6-0737 | Hex Nut |
| 8 | 6-0738 | Flat Washer |
| 9 | 6-0736 | Wedge Anchor |
| 10 | 6-0668 | Hex Hd. Bolt |
| 11 | 6-0058 | Lockwasher |
| 12 | 6-0062 | Flat Washer |
| 13 | 6-0423 | Hex Hd. Bolt |
| 14 | 6-0674 | Lockwasher |
| 15 | 6-0059 | Lockwasher |
| 16 | 6-0045 | Hex Hd. Bolt |
| 17 | 6-0056 | Lockwasher |
| 18 | 6-0178 | Hex Hd. Bolt |
| 19 | 2-1391 | Retaining Bar |
| 20 | 6-0426 | Flat Washer |
| 21 | 6-0069 | Shoulder Bolt |
| 22 | 3-0197 | Rear Slip Plate |
| 23 | 3-0196 | Bearing Cage |
| 24 | 6-0829 | Ball Bearing |
| 26 | 2-0557 | Sheave Assembly |
| 27 | 1-0757 | Nylon Thrust Washer |
| 28 | 4-0188 | Rear Crossmember Weldment |
| 29 | 2-0637 | Locking Pin Assembly |
| 30 | 6-0505 | Self Tapping Screw |
| 31 | 1-0095 | Ramp Pin |
| 32 | 6-0115 | Cotter Pin, 1/8 X 2lg. |
| 33 | 6-0178 | Hex Hd. Bolt3/4Lg. |
| 34 | 6-0060 | Flat Washer |
| 35 | 6-1125 | Caution Tape, (40lg.) |
| 36 | 3-0285 | Approach Ramp |
| 37 | 3-0347 | Post |
| 38 | 4-0221 | Alignment Deck Wldmt, (Right Side) |
| 39 | 1-0798 | Sheave Spacer, 2 1/2lg. |
| 40 | 1-0788 | Sheave Spacer, 1 1/2lg. |
| 41 | 2-0566 | Deck Sheave Pin |
| 42 | 6-0801 | Shoulder Bolt |
| 43 | 6-0729 | Shoulder Bolt |
| 44 | 1-0769 | Lock Safety Pin |
| 45 | 1-0766 | Cable Roller |
| 46 | 1-0768 | Tension Spring |
| 47 | 1-0771 | Crossmember Sheave Pin |
| 48 | 1-0786 | Sheave Spacer, 13/32lg. |
| 49 | 2-0990 | Safety Shoe Wldmt. |
| 50 | 6-1563 | Hex Nylon Locknut |
| 51 | 1-0767 | Compression Spring |
| 52 | 6-0662 | Hex Nut |
| 53 | 6-0663 | Internal Tooth Lockwasher |
| 54 | 6-0651 | Air Cylinder, 5 1/2 Rod Lgth. (Spr-12) |
| 55 | 2-0567 | Safety Lock Wldmt. Ls |
| 2-1475 | Safety Lock Wldmt. Rs | |
| 56 | 1-0775 | Plastic Bracket |
| 57 | 1-0776 | Plastic Guide |
| 58 | 6-0036 | Hex Nut |
| 59 | 1-0799 | Sheave Spacer, 1 3/4lg. |
| 60 | 6-0726 | Set Screw |
| 61 | 1-0943 | Sheave Spacer, 2lg. |
| 62 | 2-0060 | Flat Washer |
| 63 | 4-0187 | Hydraulic Cylinder |
| 64 | 6-1160 | Locknut |
| 65 | 6-0004 | Wear Ring |
| 66 | 2-0564 | Piston |
| 67 | 6-1305 | 0 Ring |
| 68 | 6-0003 | Piston Seal |
| 69 | 0-0169 | Piston Seal Kit |
| 70 | 2-0565 | Piston Rod |
| 71 | 6-0664 | Hex Nut |
| 72 | 2-0561 | Cable Flange |
| 73 | 6-0665 | Clamp |
| 74 | 6-0666 | Hex Hd. Bolt |
| 75 | 6-0653 | Rod Wiper |
| 76 | 6-0654 | Rod Seal |
| 77 | 3-0348 | Gland |
| 78 | 6-0655 | O Ring |
| 79 | 0-0170 | Gland Seal Kit |
| 80 | 6-0730 | Hex Hd. Bolt |
| 81 | 2-0575 | Sheave Cover |
| 82 | 6-1114 | Serial Tag |
| 83 | 6-0996 | Ali/Etl Decal |
| 85 | 6-0592 | Caution Decal |
| 86 | 6-0351 | Safety Instructions Decal |
| 87 | 6-0595 | Warning Decal |
| 88 | 6-1637 | Attention Decal |
| * | 4-0272 | Service Deck Wldmt., (Left Side) |
| ** | 4-0305 | Service Deck Wldmt., (Right Side) |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 6-0709 | 90 Elbow |
| 2 | 6-0651 | Air Cylinder |
| 3 | 6-0706 | 1/4 Dia. Poly Tube |
| 4 | 6-0710 | Adapter, 3/8 Poly Tube X 1/4npt |
| 5 | 6-0713 | Terminal Bolt |
| 6 | 6-0282 | Plug |
| 7 | 6-0014 | 1/4 Npt Street Tee |
| 8 | 6-0015 | 1/4 Npt Street Elbow |
| 9 | 6-0707 | 3/8 Dia. Poly Tube |
| 10 | 6-0804 | 90 Adapter, 3/8jic M X 9/16-18 M |
| 11 | 6-0714 | Hose Guard |
| 12 | 6-0650 | Power Pack 230v/1 Ph |
| 13 | 6-0715 | Hyd.Hose AssY,3/8swivelx3/8jic M,147lg. |
| 14 | 6-0731 | Cable Tie |
| 15 | 2-1394 | Air Valve & Filter AssY |
| 16 | 6-0797 | Adapter, 3/8npt M X 3/8jic F, Swivel |
| 17 | 6-0090 | Flow Control |
| 18 | 6-1775 | Air Valve |
| 19 | 6-0796 | 90 Elbow |
| 20 | 6-0708 | Adapter, 1/4 Poly Tube X 1/8npt |
| 21 | 6-1777 | Air Valve Pushbutton Kit |
| 22 | 6-0180 | Air Filter |
| 23 | 0-0405 | Air Valve Fitting Kit |
| 24 | 6-0025 | Velocity Fuse |
| 25 | 6-0182 | Plug |
| 26 | 1-1057 | Manifold |
| 27 | 6-0205 | Hex Hd.Cap Screw |
| 28 | 6-0032 | Hex Nut |
| 29 | 6-0056 | Lockwasher |
| 32 | 6-0593 | Lift Operation Decal |
| 33 | 6-0280 | Adapter, 1/8npt M X 1/4jic M |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 2-0643 | Cable Assembly, 318lg. (Left-Front) |
| 2 | 2-0644 | Cable Assembly, 15 Lug. (Left-Rear) |
| 3 | 2-0645 | Cable Assembly, 203lg. (Right-Rear) |
| 4 | 2-0646 | Cable Assembly, 367lg. (Right-Front) |
| 5 | 6-0724 | Hex Nut |
| 6 | 1-0800 | Cable Spacer, 2lg. |
| 7 | 6-0725 | Flat Washer |
| 8 | 1-0801 | Cable Spacer, 1lg. |
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | 6-0881 | Microswitch And Wiring Assembly |
| 2 | 6-1084 | Microswitch Boot |
| 3 | 6-0773 | Motor, 230v Ac, 1 Phase, 60 Hertz' |
| 4 | 0-0197 | Motor Ad Apter Kit |
| 5 | 6-1085 | Socket Hd.Cap Scw. L/4-20unc X 1 5/8lg. |
| 6 | 6-0056 | Lock Washer |
| 7 | 6-1086 | Allen Flat Hd.Scw. L/4-20unc X 3/4lg. |
| 8 | 6-0774 | Coupling |
| 9 | 6-0776 | Release Bracket & Handle Assembly |
| 10 | 6-0880 | Valve Cartridge Release |
| 11 | 6-1087 | Valve Cartridge Check |
| 12 | 6-1317 | Fixed Relief Valve Assembly (Rv 17) |
| 13 | 6-1089 | Relief Valve Cap |
| 14 | 6-0875 | Reservoir 0 Ring |
| 15 | 6-0782 | Pump Assembly |
| 16 | 6-1090 | Pump Mounting Bolt |
| 17 | 0-0198 | Inlet Plumbing Kit |
| 18 | 6-0786 | Inlet Hose / Filter Assembly |
| 19 | 0-0199 | Pump O Ring Kit |
| 20 | 6-0783 | Return Tube |
| 21 | 6-0784 | Breather Filler Cap |
| 22 | 6-0785 | Reservoir |
| 23 | 6-1091 | Reservoir Screw |
