BEAR 63-139 Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-1936 Power Pack, 230v/1ph/60hz.
  6-1165 Power Pack, 230v/3ph/60hz.
2 4-0186 Power Post
3 3-0487 Safety Rack Wldmt.
4* 4-0183 Alignment Deck Wldmt, (Left Side)
5 4-0190 Front Crossmember Weldment
6 2-0998 Front Wheel Stop
7 6-0737 Hex Nut
8 6-0738 Flat Washer
9 6-0736 Wedge Anchor
10 6-0668 Hex Hd. Bolt
11 6-0058 Lockwasher
12 6-0625 Flat Washer
13 6-0423 Hex Hd. Bolt
14 6-0674 Lockwasher
15 6-0059 Lockwasher
16 6-0045 Hex Hd. Bolt
17 6-0056 Lockwasher
18 6-0178 Hex Hd. Bolt
19 2-1391 Retaining Bar
20 6-0426 Flat Washer
21 6-0069 Shoulder Bolt
22 3-0197 Rear Slip Plate
23 3-0196 Bearing Cage
24 6-0829 Ball Bearing
26 2-0557 Sheave Assembly
27 1-0757 Nylon Thrust Washer
28 4-0188 Rear Crossmember Weldment
29 2-0637 Locking Pin Assembly
30 6-0505 Self Tapping Screw
31 1-1887 Ramp Pin
32 6-0978 Cotter Pin, 1/8 X 1 1/2lg.
33 6-0178 Hex Hd. Bolt
34 6-0060 Flat Washer
35 6-1125 Caution Tape, (40lg.)
36 3-0285 Approach Ramp
37 3-0347 Post
38 4-0184 Alignment Deck Wldmt, (Right Side)
39 1-0798 Sheave Spacer, 2 1/2lg.
40 1-0788 Sheave Spacer, 1 1/2lg.
41 2-0566 Deck Sheave Pin
42 6-0801 Shoulder Bolt
43 6-0069 Shoulder Bolt
44 1-0769 Lock Safety Pin
45 1-0766 Cable Roller
46 1-0768 Tension Spring
47 1-0771 Crossmember Sheave Pin
48 1-0786 Sheave Spacer, 13/32lg.
49 2-0990 Safety Shoe Wldmt.
50 6-1563 Hex Nylon Locknut
51 1-0767 Compression Spring
52 6-0662 Hex Nut
53 6-0663 Internal Tooth Lockwasher
54 6-0651 Air Cylinder, 5 1/2 Rod Lgth. (Spr-12)
55 2-0567 Safety Lock Ls
  2-1475 Safety Lock Rs
56 1-0775 Plastic Bracket
57 1-0776 Plastic Guide
58 6-0036 Hex Nut
59 1-0799 Sheave Spacer, 1 3/4lg.
60 6-0726 Set Screw
61 1-0943 Sheave Spacer, 2lg.
62 2-0843 Flat Washer
63 0-1654 Hydraulic Cylinder
64 6-1160 Locknut
65 6-0004 Wear Ring
66 2-0564 Piston
67 6-1305 O Ring
68 6-0003 Piston Seal
69 0-0169 Piston Seal Kit
70 2-0565 Piston Rod
71 6-0664 Hex Nut
72 2-0561 Cable Flange
73 6-0665 Clamp
74 6-0666 Hex Hd. Bolt
75 6-0653 Rod Wiper
76 6-0654 Rod Seal
77 3-0348 Gland
78 6-0655 O Ring
79 0-0170 Gland Seal Kit
80 6-0730 Hex Hd. Bolt
81 2-0575 Sheave Cover
82 6-1115 Serial Tag
83 6-0996 Ali/Etl Decal
85 6-0988 Decal Set, Ali/Wl 200
88 6-1637 Attention Decal
* 4-0195 Service Deck Wldmt, (Left Side)
** 4-0196 Service Deck Wldmt, (Right Side)



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0709 90 Elbow
2 6-0651 Air Cylinder
3 6-0706 1/4 Dia. Poly Tube
4 6-0710 Adapter, 3/8 Poly Tube X 1/4npt
5 6-0713 Terminal Bolt
6 6-0282 Plug
7 6-0014 1/4 Npt Street Tee
8 6-0015 1/4 Npt Street Elbow
9 6-0707 3/8 Dia. Poly Tube
10 6-0804 90 Adapter, 3/8jic M X 9/16-18 M
11 6-0714 Hose Guard
12 6-1936 Power Pack 230v/1ph/60hz.
  6-1165 Power Pack 230v/3ph/60hz.
13 6-0715 Hyd.Hose AssY, 3/8swivelx3/8jic M,147lg.
14 6-0731 Cable Tie
15 2-1394 Air Valve & Filter AssY
16 6-0797 Adapter, 3/8npt M X 3/8jic F, Swivel
17 6-0090 Flow Control
18 6-1775 3 Way Air Valve
19 6-0796 90 Elbow
20 6-0708 Adapter, 1/4 Poly Tube X 1/8npt
21 6-1777 Air Valve Pushbutton Kit
22 6-0772 Air Filter Assembly
  6-0180 Air Filter Element, (Replacement)
23 0-0405 Air Valve Fitting Kit
24 6-0025 Velocity Fuse
25 6-0182 Plug
26 1-1057 Manifold
27 6-0205 Hex Hd.Cap Screw
28 6-0032 Hex Nut
29 6-0056 Lockwasher
32 6-0593 Lift Operation Decal
33 6-0280 Adapter, 1/8npt M X 1/4jic M



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 2-0539 Cable Assembly, 376lg. (Left-Front)
2 2-0540 Cable Assembly, 181lg. (Left-Rear)
3 2-0541 Cable Assembly, 233lg. (Right-Rear)
4 2-0542 Cable Assembly, 427lg. (Right-Front)
5 6-0724 Hex Nut
6 1-0800 Cable Spacer, 2lg.
7 6-0725 Flat Washer
8 1-0801 Cable Spacer, 1lg.



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-1087 Valve Cartridge Check
2 6-2136 Label Installation Autohoist
4 6-1376 Breather Cap & Bladder
6 6-2139 Motor Ac 208-230v. 2hp/1ph/60hz, Blk
  6-1079 Motor Ac 208-230v. 2hp/3ph/60hz, Blk
7 6-2149 Label Warning Autohoist
9 6-2151 Spring 0.480 X 0.063 X 0.42 Comp
10 6-2152 Return Hose 3/8 Od X 21.5
11 6-2153 Compression Tube Nut
12 6-2154 Compression Tube Sleeve
13 6-2155 Endhead Universal Autohoist
14 6-1688 Pumpassy 3.1 Cc/Rev. Short Spline
15 6-1317 Relief Assembly Fixed 170 Bar
16 6-0880 Valve Cartridge Release Manual
17 6-2156 Wiring Assembly Ac 1ph Fenner
  6-0918 Wiring Assembly Ac 3ph Fenner
18 6-1090 Bolt
19 6-0774 Coupling Sae 9t-20/40 1.260
20 6-2157 Plumbing Plug
21 6-2158 Seal Shaft 0.500 X 1.00 X 0.25
22 6-2159 Washer
24 6-2161 Plumbing Plug
25 6-2162 Plumbing Magnet
27 6-2164 Screw
28 6-2165 Cover Assy Suction
29 6-2166 Plumbing Clamp Hose Adj. Inlet
30 6-1392 Bolt
31 6-2167 Nut
32 6-2168 Washer
33 6-0776 Bracket - Handle Assy Rel Black
34 6-2169 Bolt
35 6-2170 Washer
37 6-1091 Bolt
38 6-0786 Plumbing Assy Inlet 17.24 (3)
39 6-1089 Relief Valve Cap Assembly
40 6-1399 Tank Plastic 6.7 Os 22.50 Blk
41 6-1846 Cable Tie 8 Long White
42 6-0875 O-Ring 2-348 Buna
