AMMCO S412OXA0B3 Parts Breakdown



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-1936 Power Pack, 230v/1ph//60hz.
  6-1165 Power Pack, 230v/3ph//60hz.
2 4-0429 Power Post Welding (L.S.)
3 3-0487 Safety Rack Weldment (Rear)
4 4-0679 Alignment Deck Weldment (Left Side)
  4-1024 Service Deck Weldment (Left Side)
5 4-0366 Front Crossmember Weldment (Left Side)
6 22868 Front Wheel Stop Weldment
7 6-0737 Hex Nut
8 6-0738 Flat Washer
9 6-1379 Wedge Anchor
10 6-0668 Hex Hd. Bolt
11 6-0058 Lockwasher
12 6-0625 Flat Washer
13 6-0293 Hex Hd. Bolt
14 6-0674 Lockwasher
15 6-0059 Lockwasher
16 6-0267 Cotter Pin 1/8" X 1"
17 6-0056 Lockwasher
18 6-0423 Hex Hd. Bolt
19 2-1391 Retaining Bar
20 6-0426 Flat Washer
21 6-0069 Shoulder Bolt
22 3-0197 Rear Slip Plate (Full Floating)
23 3-0196 Bearing Cage
24 6-0829 1/4" Ball Bearing
25 2-0772 Glide Bearing
26 2-0557 Sheave Assembly
27 1-0757 Nylon Thrust Washer
28 4-0371 Rear Crossmember (Welding)
29 2-0637 Locking Pin Assembly
30 6-0505 Self Tap Screw
31 1-1887 Ramp Pin
32 6-0978 Cotter Pin, 1/8" X 1 1/2" Lg.
33 4-0430 Post Welding (Front - R.S)
34 6-0294 Hex Nut
35 6-0295 Flat Washer
36 3-0905 Ramp Assembly W/ Roller
37 3-1114 Rear Post Welding
38 4-0680 Alignment Deck Weldment, (Right Side)
  4-1025 Service Deck Weldment, (Right Side)
39 1-0798 Sheave-Spacer 2 1/2"Lg.
40 1-0788 Sheave-Spacer 1 1/4"Lg.
41 2-0566 Deck Sheave Pin
42 6-0206 Shoulder Bolt
43 6-0069 Shoulder Bolt
44 1-1234 Lock Safety Pin (Welding)
45 1-0766 Cable Roller
46 1-0768 Tension Spring
47 1-0771 Crossmember Sheave Pin
48 1-0786 Sheave Spacer, 3/8 Lg
49 2-0990 Safety Shoe Weldment
50 6-1563 Hex. Nylon Locknut
51 1-0767 Compression Spring
52 6-0662 Hex. Nut
53 6-0663 Internal Tooth Lockwasher
54 6-0651 Air Cylinder (Clippard #Srr-12-2-Sp; 5 1/2" Rod Ext.)
55 2-0567 Lock-Safety Ls
  2-1475 Lock Safety Rs
56 6-0674 Lock Washer
57 6-0295 Flat Washer
58 6-0673 Hex Nut
59 1-0799 Sheave-Spacer 1 3/4"Lg.
60 6-0726 Set Screw
61 1-0943 Sheave-Spacer 2 "Lg.
62 6-0060 Flat Washer
63 4-0393 Hydraulic Cylinder 3.5"
64 3-0581 Safety Rack Weldment
71 6-0664 Hex Nut
72 2-1037 Cable Flange
73 6-0665 Hose Clamp 4 1/2"Dia.
74 6-0666 Hex. Bolt
80 6-1386 Hex Hd. Bolt
81 2-0997 Sheave Cover
82 6-1115 Serial Tag
83 6-0988 "Ali" Plate
84 4-0368 Front Crossmember Weldment (Right Side)
85 6-0988 Decal Set, Ali/Wl 200
88 2-0980 Lock Safety Ls
  2-1427 Lock Safety Rs
89 6-1125 "Caution" Tape, (40" Lg.)
90 6-1381 Hex Hd. Bolt
91 6-0027 Hex Hd. Bolt
92 6-0769 Hex Hd. Bolt
93 6-0248 Flat Washer
94 6-0035 Hex Nut
95 2-1125 Top Plate
97 6-1637 Attention Decal
99 2-2593 Safety Retainer Bracket Assembly
100 6-0030 Hex Bolt
101 6-0140 1/2" X 4-1/2"Lg Wedge Anchor
102 6-4086 Warning Label



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-0709 90 Elbow
2 6-0651 Air Cylinder
3 6-0706 1/4" Dia. Poly Tube (50 Lg.)
4 6-0710 Adapter, 3/8" Poly Tube X 1/4"Npt
5 6-0713 Terminal Bolt
6 6-0282 Plug
7 6-0014 1/4" Npt Street Tee
8 6-0015 1/4" Npt Street Elbow
9 6-0707 3/8" Dia. Poly Tube (25 Lg.)
10 6-0804 90 Elbow
11 6-0714 Hose Guard (4 Lg.)
12 6-1936 Power Pack 230v/1 Ph/60 Hz.
  6-1165 Power Pack 230v/3 Ph/60 Hz.
13 6-1692 Hyd.Hose Ass'y, 3/8"Jic-F, 16ft Lg.
14 6-0731 Cable Tie
15 2-1394 Air Valve & Filter AssY
16 6-0797 Adapter, 3/8"Npt M X 3/8"Jic M
17 6-1937 Flow Control
18 6-1775 3-Way Air Valve
19 6-0796 90 Elbow
20 6-0708 Adapter, 1/4" Poly Tube X 1/8"Npt
21 6-1777 Air Valve Pushbutton Kit
22 6-0772 Air Filter Assembly
  6-0180 Air Filter Element, (Replacement)
23 0-0405 Air Valve Fitting Kit
24 6-1684 Velocity Fuse
26 6-2971 1/4 Polytube Pushlock Tee
27 6-3869 1/4 Polytube Pushlock Cross
30 6-0747 1/4 Polytube Adapter
32 6-0593 "Lift Operation" Decal
33 6-0280 Adapter, 1/8"Npt M X 1/4"Jic M



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 2-1504 Cable Assembly, 404.5lg. (Left-Front)
2 2-1505 Cable Assembly, 157.75"Lg. (Left-Rear)
3 2-1506 Cable Assembly, 213.75"Lg. (Right-Rear)
4 2-1507 Cable Assembly, 459.5lg. (Right-Front)
5 6-0724 Hex Nut
6 1-0800 Cable Spacer, 2"Lg.
7 6-0725 Flat Washer
8 1-0801 Cable Spacer, 1"Lg.



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 2-2589 Safety Retainer Bracket
2 1-1674 Safety Retainer Pad
3 6-2048 Shcs 3/8 Nc X 1 Lg
4 6-0816 Flat Washer
5 6-0297 Screw
6 6-0058 Lock Washer
7 6-0034 Hex Nut



Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 6-1087 Valve Cartridge Check
2 6-2136 Label Installation Autohoist
4 6-1376 Breather Cap & Bladder
6 6-2139 Motor Ac 208-230v. 2hp/1ph/60hz, Blk
  6-1079 Motor Ac 208-230v. 2hp/3ph/60hz, Blk
7 6-2149 Label Warning Autohoist
9 6-2151 Spring 0.480 X 0.063 X 0.42 Comp
10 6-2152 Return Hose 3/8 Od X 21.5
11 6-2153 Compression Tube Nut
12 6-2154 Compression Tube Sleeve
13 6-2155 Endhead Universal Autohoist
14 6-1688 Pumpassy 3.1 Cc/Rev. Short Spline
15 6-1317 Relief Assembly Fixed 170 Bar
16 6-0880 Valve Cartridge Release Manual
17 6-2156 Wiring Assembly Ac 1ph Fenner
  6-0918 Wiring Assembly Ac 3ph Fenner
18 6-1090 Bolt
19 6-0774 Coupling Sae 9t-20/40 1.260
20 6-2157 Plumbing Plug
21 6-2158 Seal Shaft 0.500 X 1.00 X 0.25
22 6-2159 Washer
24 6-2161 Plumbing Plug
25 6-2162 Plumbing Magnet
27 6-2164 Screw
28 6-2165 Cover Assy Suction
29 6-2166 Plumbing Clamp Hose Adj. Inlet
30 6-1392 Bolt
31 6-2167 Nut
32 6-2168 Washer
33 6-0776 Bracket - Handle Assy Rel Black
34 6-2169 Bolt
35 6-2170 Washer
37 6-1091 Bolt
38 6-0786 Plumbing Assy Inlet 17.24 (3)
39 6-1089 Relief Valve Cap Assembly
40 6-1399 Tank Plastic 6.7 Os 22.50 Blk
41 6-1846 Cable Tie 8 Long White
42 6-0875 O-Ring 2-348 Buna
