AMMCO BEN PEARSON NDL 5500 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7110-41 | Bumper Pipe |
| 2 | BH-7110-42 | Bumper Tubing |
| 3 | BH-7113-67 | Flat Washer |
| 3 | BH-7101-55 | Hex Screw |
| 3 | BH-7112-24 | Lock Washer |
| 3 | BH-7112-23 | Hex Nut |
| 4 | BH-7113-68 | Cable Support Strap |
| 4 | BH-7110-73 | HFHSL Screw |
| 4 | BH-7110-75 | HFHSL Nut |
| 5 | BH-7113-13 | Switch Support Angle |
| 5 | BH-7110-73 | HFHSL Screw |
| 5 | BH-7110-75 | HFHSL Nut |
| 6 | BH-7004-19 | Micro Switch |
| 7 | BH-7110-33 | Angle Support RH |
| 7 | BH-7110-73 | HFHSL Screw |
| 7 | BH-7110-75 | HFHSL Nut |
| 8 | BH-7110-70 | Angle Support LH |
| 9 | BH-7113-66 | Top Channel Structure |
| 9 | BH-7110-74 | HFHSL Screw |
| 9 | BH-7110-76 | HFHSL Nut |
| 10 | BH-7113-64 | Post Extension Structure RH |
| 10 | BH-7113-65 | HFHSL Screw |
| 10 | BH-7112-63 | HFHSL Screw |
| 10 | BH-7110-82 | HFHSL Nut |
| 11 | BH-7113-63 | Post Extension Structure LH |
| 12 | BH-7100-17 | Cable Assy Long |
| 12 | BH-7100-54 | Hex Nut |
| 13 | BH-7100-16 | Cable Assy Short |
| 14 | BH-7100-00C | Retaining Ring |
| 15 | BH-7100-00B | Idler Pin |
| 16 | BH-7100-00 | Cable Sheave (Nylon) |
| 16 | BH-7100-00S | Cable Sheave (Steel) |
| 17 | BH-7100-00A | Idler Support Structure Bottom |
| 17 | BH-7112-36 | HFHSL Screw |
| 18 | BH-7101-02 | 2-5/8 Height Adapter |
| 19 | BH-7101-04 | 3-1/2 Height Adapter |
| 20 | BH-7101-03 | 5 Height Adapter |
| 21 | BH-7101-00 | Rubber Arm Pad |
| 21 | BH-7101-00-4 | Rubber Arm Pad Kit |
| 22 | BH-7101-01 | Steel Adapter |
| 23 | BH-7101-01C | Adapter Base & Pad Assy. |
| 24 | BH-7101-06 | Carriage Arm Pin |
| 25 | BH-7113-07 | Hex Screw |
| 26 | BH-7113-60 | Arm Ext. Structure Short |
| 27 | BH-7113-59 | Lift Arm Structure RH Short |
| 28 | BH-7113-58 | Lift Arm Structure LH Short |
| 29 | BH-7113-57 | Arm Extension Structure Long |
| 30 | BH-7113-56 | Lift Arm Structure Long |
| 31 | BH-7113-54 | Carriage Assy |
| 32 | BH-7100-62 | Hydraulic Cylinder |
| 32 | BH-7100-76 | Seal Kit Hex Bleeder |
| 32 | BH-7100-77 | Seal Kit Allen Bleeder |
| 33 | BH-7006-01 | Power Unit 1 PH, 2 HP |
| 34 | BH-7512-92 | Shim Kit 150 pcs, 3 sizes |
| 35 | BH-7075-03 | 3/4 x 5-1/2 Wedge Anchor |
| 36 | BH-7113-51 | Post Structure RH |
| 37 | BH-7113-49 | Post Structure LH |
| BH-7113-70 | Front Arm Ext Pkg (Optional) | |
| 38 | BH-7102-92 | Female Adapter |
| 39 | BH-7111-64 | Pipe Nipple |
| 40 | BH-7102-93 | 90 Elbow |
| 41 | BH-7113-73 | Tube Assy - Main Lower |
| 42 | BH-7111-72 | Union Tee |
| 43 | BH-7113-74 | Tube Assy - Main Upper |
| 44 | BH-7110-63 | 90 Male Elbow |
| 45 | BH-7110-66 | Hex Head Plug |
| 46 | BH-7113-75 | Tube Assy Offside |
| 47 | BH-7111-74 | Union Connector |
| 48 | BH-7113-76 | Hose Assy |
| 49 | BH-7111-77 | Hose Clamp |
| 49 | BH-7110-73 | HFHSL Screw |
| 49 | BH-7110-75 | HFHSL Nut |
| 50 | BH-7101-61 | Dry Pressure Gauge |
| 51 | BH-7111-65 | Coupling (MTE Only) |
| 52 | BH-7111-71 | Hex Nipple (MTE Only) |
| 53 | BH-7100-62 | Hydraulic Cylinder |
| 54 | BH-7113-54 | Carriage Assembly |
| 54 | BH-7113-77 | Carriage Structure |
| 55 | BH-7110-01 | Carriage Slider Block |
| 56 | BH-7113-79 | Bumper Pad |
| 57 | BH-7102-34 | Latch Assy |
| BH-7113-46 | Grease Fitting | |
| 58 | BH-7102-10 | Shaft |
| 59 | BH-7100-90 | Torsion Spring |
| 60 | BH-7100-85 | Retaining Ring |
| 61 | BH-7102-27 | Cam Structure |
| 62 | F-NL-0375-16 | Nylock Nut |
| 63 | F-CP-093-1000 | Cotter Pin |
| 64 | BH-7102-36 | Cam Lever |
