AMMCO BEN PEARSON LTC 9 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7112-69 | Hex Screw |
| 2 | BH-7101-61 | Dry Pressure Guage |
| 3 | BH-7111-65 | Coupling (MTE Only) |
| 4 | BH-7111-71 | Hex Nipple |
| 5 | BH-7110-63 | 90 Elbow |
| 6 | BH-7110-66 | Plug |
| 7 | BH-7006-01 | Power Unit 1 PH, 2 HP |
| 8 | BH-7112-68 | Hose Clamp |
| 9 | BH-7112-67 | Hose Assembly 3/8 |
| 10 | BH-7112-66 | Nylock Hex Nut |
| 11 | BH-7112-65 | Flat Washer |
| 12 | BH-7100-24 | RH Front Cable Assembly |
| 13 | BH-7100-25 | LH Front Cable Assembly |
| 14 | BH-7100-27 | RH Rear Cable Assembly |
| 15 | BH-7100-26 | LH Rear Cable Assembly |
| 16 | Call For Details | Handle Linkage Pivot |
| 17 | BH-7100-54 | Ramp Assembly |
| 18 | BH-7112-64 | Moveable Track Assembly |
| 19 | BH-7112-63 | HFHSL Screw |
| 20 | BH-7112-62 | Stationary Track Assembly |
| 21 | BH-7112-61 | Rear Cross Tube Assembly |
| 22 | BH-7112-60 | Front Cross Tube Assembly |
| 23 | BH-7512-92 | Shim Kit 150 pcs, 3 sizes |
| 24 | BH-7075-03 | 3/4 x 5-1/2 Wedge Anchors |
| 25 | BH-7112-59 | Post Structure w/Power Unit |
| 26 | BH-7112-58 | Post Structure |
| BH-7112-70 | Tire Chock | |
| 26 | BH-7112-76 | Stationary Track Structure |
| 27 | BH-7103-15 | Hydraulic Cylinder Seal Kit |
| 28 | BH-7112-75 | Hair Pin Clip |
| 29 | BH-7112-77 | Cylinder Pin |
| 30 | BH-7112-78 | Cylinder Adapter |
| 31 | BH-7102-02 | Spacer RH Top |
| 32 | BH-7112-79 | Spacer LH Bottom |
| 33 | BH-7102-01 | Spacer Bottom |
| 34 | BH-7102-04 | Spacer Top |
| 35 | BH-7102-05 | Spacer Center Rear |
| 36 | BH-7100-32 | Cable Sheave Assembly |
| 37 | BH-7112-80 | Hex Screw Assembly |
| 38 | BH-7102-00 | Nylock Nut |
| 39 | BH-7100-52 | Track Stop Angle |
| 40 | BH-7110-78 | Hex Screw |
| 41 | F-LW-0500 | Lock Washer |
| 42 | BH-7112-82 | Hex Nut |
| 43 | BH-7112-83 | Breather Plug |
| 44 | BH-7112-84 | 90 Bulkhead Adapter Elbow |
| 45 | BH-7112-85 | Bulkhead Nut |
| 46 | BH-7112-86 | Hose Assembly 3/8 ID |
| 47 | BH-7112-87 | 90 O-Ring Elbow |
| 48 | BH-7112-88 | Cable Guide |
| 48 | BH-7100-26 | Cable Assy Cyl to LH Rear |
| 48 | BH-7100-27 | Cable Assy Cyl to RH Rear |
| 48 | BH-7100-25 | Cable Assy Cyl to LH Front |
| 48 | BH-7100-24 | Cable Assy Cyl to RH Front |
| 48 | BH-7112-66 | Nylock Hex Nut |
| 49 | BH-7102-49 | Orifice |
| 50 | BH-7112-89 | Hex Screw Assembly |
| 51 | BH-7112-90 | Hex Screw Assembly |
| BH-7112-60 | Front Cross Tube Assy (Contains 52-76) | |
| 52 | BH-7112-91 | Front Cross Tube Structure |
| 53 | BH-7100-32 | Cable Sheave |
| 54 | BH-7112-94 | Spacer |
| 55 | BH-7112-95 | Hex Screw Assembly |
| 56 | BH-7102-00 | Nylock Nut |
| 57 | BH-7110-12 | LH Latch Catch |
| 58 | BH-7110-11 | RH Latch Catch |
| 59 | BH-7102-06 | Latch Structure |
| 60 | BH-7100-47 | Latch Structure |
| 61 | BH-7100-89 | Shaft |
| 62 | BH-7100-88 | Retaining Ring |
| 63 | BH-7110-13 | Safety Latch Spring |
| 64 | BH-7102-30 | Flat Washer |
| 65 | BH-7110-18 | Bolt w/Grease Fitting |
| 66 | BH-7110-26 | Flat Washer |
| 67 | F-CP-125-0750 | Cotter Pin |
| 68 | BH-7109-97 | Slack Chain Shaft |
| 69 | BH-7109-96 | Slack Chain Roller |
| 70 | BH-7100-86 | Retaining Ring |
| 71 | F-HC-0375-16-4000 | Hex Screw |
| 72 | F-NL-0375-16 | Hex Nut Nylock |
| 73 | BH-7102-31 | Tube Spacer |
| 74 | BH-7102-11 | Flat Washer |
| 75 | BH-7112-96 | Idler Cover |
| 76 | BH-7112-97 | Flanged Head Screw |
| BH-7112-61 | Rear Cross Tube Assy | |
| 77 | BH-7113-02 | Rear Cross Tube Structure |
| 82 | BH-7101-20 | Bar Tapped |
| 83 | BH-7101-22 | Bar |
| 84 | BH-7101-19 | Pin |
| 85 | F-CP-125-0750 | Cotter Pin |
| 86 | BH-7110-14 | Spring |
| 87 | BH-7101-23 | Trip Rod |
| 88 | BH-7101-21 | Shoulder Screw |
| 89 | BH-7105-08 | Nut |
| 90 | BH-7105-09 | Nut |
| 91 | F-CP-125-1000 | Cotter Pin |
| 92 | BH-7112-98 | Tube Structure Pivot |
| 93 | BH-7112-99 | Handle Structure |
| 94 | BH-7101-72 | Pivot Structure |
| 95 | BH-7101-55 | Hex Screw |
| 96 | BH-7112-24 | Lock Washer |
| 97 | BH-7112-23 | Hex Nut |
| 98 | BH-7110-20 | Pivot Pin |
| 99 | BH-7113-00 | Adjusting Rod Long |
| 100 | BH-7113-01 | Adjusting Rod Short |
| 101 | BH-7112-71 | Free Wheel Device (Contains 102-105) |
| 102 | BH-7112-72 | Wide Side Assembly |
| 103 | BH-7112-73 | Narrow Side Assembly |
| 104 | BH-7112-74 | Retaining Pin Structure |
| 105 | BH-7112-75 | Hair Pin Clip |
| 106 | BH-7112-62 | Stationary Track Assembly |
