AMMCO BEN PEARSON LASO 7 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7115-25 | Long Lift Arm Structure |
| 2 | BH-7115-26 | Short Lift Arm Structure |
| 3 | BH-7115-27 | Arm Extension Structure Long |
| 4 | BH-7115-28 | Arm Extension Structure Short |
| 5 | BH-7101-06 | Pin Structure |
| 6 | BH-7101-01C | Adapter Base & Pad Assy |
| 6 | BH-7101-00 | Rubber Pads only |
| 6 | BH-7101-00-4 | Rubber Pad Kit (4) |
| 7 | BH-7101-03 | 5 Height Adapter |
| 8 | BH-7101-04 | 3-1/2 Height Adapter |
| 9 | BH-7101-02 | 2-5/8 Height Adapter |
| 10 | BH-7111-08 | Chain |
| 11 | BH-7111-05 | Idler Support Structure |
| 12 | BH-7100-00B | Idler Pin |
| 13 | BH-7100-00C | Retaining Ring |
| 14 | BH-7100-00 | Nylon Cable Sheave |
| 14 | BH-7100-00S | Steel Cable Sheave |
| 15 | BH-7100-14 | Long Cable Assy |
| 16 | BH-7100-13 | Short Cable Assy |
| 17 | BH-7115-29 | Channel Structure Post Ext LH |
| 18 | BH-7115-30 | Channel Structure Post Ext RH |
| 19 | BH-7115-31 | Cross Over Channel |
| 20 | BH-7115-32 | Cable Support Strap |
| 21 | BH-7111-13 | Switch Support Angle |
| 22 | BH-7004-19 | Micro Switch |
| BH-7113-69 | Cover Switch | |
| 23 | BH-7115-33 | Pipe Bumper |
| 24 | BH-7110-42 | Tubing Bumper |
| 25 | BH-7113-67 | Flat Washer |
| 26 | BH-7110-40 | Angle Support LH |
| 27 | BH-7110-33 | Angle Support RH |
| 28 | BH-7100-51 | Cylinder Roller Assembly |
| 29 | BH-7111-06 | Cylinder End Structure |
| BH-7101-95 | Roller Spacer | |
| BH-7114-60 | Cylinder End Pin | |
| BH-7100-00C | Retaining Ring | |
| 30 | BH-7111-07 | Carriage Assy |
| 31 | BH-7115-22 | Post Structure |
| 32 | BH-7115-23 | Channel Stiffener |
| 33 | BH-7115-24 | Spacer Bar |
| 34 | BH-7075-03 | 3/4 x 5-1/2 Wedge Anchors |
| 35 | BH-7512-92 | Shim Kit 150 pcs, 3 Sizes |
| 36 | BH-7006-01 | Power Unit 1 PH, 2 HP |
| 37 | BH-7100-61 | Hydraulic Cylinder |
| 37 | BH-7100-37 | Seal Kit |
| 38 | BH-7102-92 | Female Adapter |
| 39 | BH-7111-64 | Pipe Nipple |
| 40 | BH-7102-93 | 90 Elbow |
| 41 | BH-7101-61 | Dry Pressure Gauge |
| 42 | BH-7111-65 | Coupling (MTE) |
| 43 | BH-7110-63 | 90 Male Elbow |
| 44 | BH-7111-66 | Tube Assy Short |
| 45 | BH-7111-67 | Tube Assy Lower |
| 46 | BH-7111-72 | Union Tee |
| 47 | BH-7111-73 | Tube Assy Offside |
| 48 | BH-7111-74 | Union Connector |
| 49 | BH-7111-75 | Hose Assy |
| 50 | BH-7111-76 | Hose Clamp Bracket |
| 51 | BH-7111-77 | Hose Clamp |
| 52 | BH-7110-66 | Hex Head Plug |
| 53 | BH-7111-71 | Hex Nipple (MTE) |
| 54 | BH-7100-61 | Hydraulic Cylinder |
| BH-7111-07 | Carriage Assy Consists of # 55-72 | |
| 55 | BH-7111-48 | Carriage Structure |
| 56 | BH-7110-03 | Carriage Roller |
| 57 | BH-7111-49 | Retaining Ring |
| 58 | BH-7102-20 | Latch Assy |
| 59 | BH-7102-48 | Cam Structure |
| 60 | BH-7111-50 | Pivot Latch Shaft |
| 61 | BH-7100-90 | Torsion Spring |
| 62 | BH-7100-85 | Retaining Ring |
| 63 | F-CP-093-1000 | Cotter Pin |
| 64 | F-NL-0375-16 | Nylock Nut |
| 65 | BH-7102-36 | Cam Lever |
| 66 | BH-7101-24 | Latch Structure |
| 67 | BH-7111-51 | Latch Pin |
| 68 | BH-7100-86 | Retaining Ring |
| 69 | BH-7111-52 | Bumper Pad |
| 70 | BH-7606-20 | Carriage Roller Bearing |
| 71 | F-RP-437-2000 | Roll Pin |
| 72 | BH-7102-10 | Shaft |
| 73 | BH-7100-13 | Cable Assy Short |
| 73 | BH-7100-14 | Cable Assy Long |
| 74 | BH-7110-54 | Hex Nut |
| 75 | BH-7112-29 | Flat Washer |
| 76 | BH-7111-08 | Chain |
