AMMCO BEN PEARSON FAR 12 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7101-59 | 90 Male Elbow |
| 2 | BH-7100-93 | 1/2 ID Hose Assy Short |
| 3 | BH-7101-60 | 1/2 ID Hose Assy Long |
| 4 | BH-7101-61 | Dry Pressure Gauge |
| 5 | BH-7111-65 | Coupling (MTE Only) |
| 6 | BH-7111-71 | Hex Nipple (MTE Only) |
| 7 | BH-7110-63 | 90 Elbow |
| 8 | BH-7006-01 | Power Unit 1PH, 2HP |
| 9 | BH-7512-92 | Shim Kit 150 pcs, 3 sizes |
| 10 | BH-7111-83 | Leaf Chain Long |
| 11 | BH-7111-82 | Leaf Chain Short |
| 12 | BH-7102-40 | Roller |
| 13 | BH-7101-25 | Cylinder End Connector |
| 14 | BH-7100-68 | Hydraulic Cylinder 72 Stroke |
| 15 | BH-7100-95 | Upper Horizontal Tube Structure |
| 16 | BH-7111-81 | Cross Chain Assembly |
| 16 | BH-7101-80 | Chain |
| 16 | BH-7028-01 | Connecting Link |
| 16 | BH-7101-49 | Stud Chain Retainer |
| 17 | BH-7111-80 | Rear Cross Tube Assy |
| 18 | BH-7111-79 | Front Cross Tube Assy |
| 19 | BH-7075-03 | 3/4 x 5-1/2 Wedge Anchor |
| 20 | BH-7110-23 | Passenger Front Column |
| 21 | BH-7101-57 | Driver Column Power Unit Mount |
| 22 | BH-7101-58 | Driver Column |
| 23 | BH-7111-87 | Adjusting Rod Straight Long |
| 24 | BH-7101-54 | Handle Assy. |
| 25 | BH-7111-31 | Pin Roller |
| 26 | BH-7111-30 | Roller |
| 27 | BH-7111-86 | Ramp Structure |
| 28 | BH-7111-28 | Plate Stand |
| 29 | BH-7111-27 | Front Stop & Chock Structure |
| 30 | BH-7101-12 | Tube Spacer |
| 31 | BH-7101-09 | Knob |
| 32 | BH-7101-08 | Compression Spring |
| 33 | BH-7111-25 | Leg Structure 30 Long |
| 33 | BH-7111-26 | Leg Structure 24 Long |
| 34 | BH-7101-07 | Pull Pin |
| 35 | BH-7111-24 | Pin Chain |
| 36 | BH-7107-02 | Ball Bearing Retainer |
| 37 | BH-7107-01 | Slip Plate Retain Sheet |
| 38 | BH-7111-22 | Cover Structure Slip Plate |
| 39 | BH-7111-85 | RH Track Structure |
| 40 | BH-7111-84 | LH Track Structure |
| BH-7111-33 | Turntable Mounting Pkg Ammco/FMC/Hunter/Bee Line | |
| 41 | BH-7111-38 | Spacer Structure / Ammco ... |
| 42 | BH-7111-40 | Adjusting Bar 1/2 / Ammco ... |
| BH-7111-34 | Turntable Mounting Pkg/Bear | |
| 43 | BH-7111-39 | Spacer Structure / Bear |
| 42 | BH-7111-41 | Adjusting Bar 1/2 / Bear |
| 44 | BH-7111-42 | Adjusting Bar 1/8 / Bear |
| BH-7111-35 | Turntable Mounting Pkg / Bender | |
| 42 | BH-7111-43 | Adjusting Bar 1/2 / JH Bender |
| 44 | BH-7111-44 | Adjusitng Bar 1/4 / JH Bender |
| BH-7111-36 | Turntable Mounting Pk/Bishamon | |
| 43 | BH-7111-39 | Spacer Structure / Bishamon |
| 44 | BH-7111-45 | Adjusting Bar 1/4 / Bishamon |
| BH-7111-37 | Turntable Mounting Pkg Snap on | |
| 42 | BH-7111-46 | Adjusting Bar 1/2 Snap-On |
| 44 | BH-7111-47 | Adjusting Bar 1/4 Snap-On |
| BH-7111-79 | Front Cross Tube Assy (#'s 45-65) | |
| 45 | BH-7111-88 | Front Cross Tube Structure |
| 46 | BH-7101-70 | Lower Chain Retainer |
| 47 | BH-7101-69 | Spacer |
| 48 | BH-7101-68 | Chain Extension |
| 49 | BH-7101-45 | Upper Chain Retainer |
| 50 | BH-7102-40 | Yoke Roller |
| 51 | BH-7102-42 | Spacer |
| 52 | BH-7110-12 | LH Latch Catch |
| 53 | BH-7110-11 | RH Latch Catch |
| 54 | BH-7110-17 | Latch Structure Slack Chain LH |
| 55 | BH-7110-24 | Latch Structure Slack Chain RH |
| 56 | BH-7110-13 | Torsion Spring |
| 57 | BH-7100-89 | Shaft 5/8 |
| 58 | BH-7100-88 | Retaining Ring |
| 59 | F-CP-125-0750 | Cotter Pin |
| 60 | BH-7102-38 | Roller |
| 61 | BH-7102-39 | Shaft 3/8 |
| 62 | BH-7100-86 | Retaining Ring 3/8 |
| 63 | BH-7110-18 | Hex Screw w/Grease Fitting |
| 64 | BH-7102-31 | Tube Spacer |
| 65 | F-HC-0375-16-4000 | Hex Screw |
| BH-7111-80 | Rear Cross Tube Assy | |
| 46 | BH-7101-70 | Lower Chain Retainer |
| 47 | BH-7101-69 | Spacer |
| 48 | BH-7101-68 | Chain Extension |
| 49 | BH-7101-45 | Upper Chain Retainer |
| 50 | BH-7102-40 | Yoke Roller |
| 51 | BH-7102-42 | Spacer |
| 56 | BH-7110-17 | Torsion Spring |
| 57 | BH-7100-89 | Shaft 5/8 |
| 58 | BH-7100-88 | Retaining Ring 5/8 |
| 59 | F-CP-125-0750 | Cotter Pin |
| 60 | BH-7102-38 | Roller |
| 61 | BH-7102-39 | Shaft 3/8 |
| 62 | BH-7100-86 | Retaining Ring 3/8 |
| 63 | BH-7110-18 | Hex Screw w/Grease Fitting |
| 64 | BH-7102-31 | Tube Spacer |
| 65 | F-HC-0375-16-4000 | Hex Screw |
| 66 | BH-7111-90 | Rear Cross Tube Structure |
| 67 | BH-7110-11 | RH Latch Catch |
| 68 | BH-7110-12 | LH Latch Catch |
| 69 | BH-7110-24 | RH Slack Chain |
| 70 | BH-7110-17 | LH Slack Chain |
| 71 | BH-7101-19 | Pin |
| 72 | BH-7110-14 | Spring |
| 73 | F-CP-125-0750 | Cotter Pin 3/4 |
| 74 | F-CP-125-1000 | Cotter Pin 1 |
| 75 | BH-7101-74 | Tube Structure Pivot |
| 76 | BH-7101-54 | Handle Assy |
| 77 | BH-7101-72 | Pivot Structure Trip Release |
| 78 | BH-7110-20 | Pivot Pin |
| 79 | BH-7111-87 | Adjusting Rod Straight Long |
| 80 | BH-7111-92 | Adjusting Rod Straight Short |
| 81 | BH-7101-20 | Bar Tapped |
| 82 | BH-7101-22 | Bar |
| 83 | BH-7101-23 | Rod Structure 3/8 |
| 84 | BH-7105-09 | Nut |
| BH-7111-53 | Jacking Channel | |
| BH-7111-54 | Jacking Channel Assy | |
| 85 | BH-7111-55 | Jacking Channel Structure |
| 86 | BH-7111-56 | Spring Support Structure |
| 87 | BH-7111-57 | Roller |
| 88 | BH-7111-58 | Bronze Bushing |
| 89 | BH-7111-59 | Pin |
| 90 | BH-7111-60 | Retaining Ring |
| 91 | BH-7111-61 | Die Spring |
| 92 | BH-7111-62 | Jack Support Structure |
| 93 | BH-7111-63 | Shield |
