AMMCO BEN PEARSON ARTO Series Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7111-19 | Bolster Support Structure |
| 2 | BH-7111-18 | Idler Support Structure |
| 3 | BH-7111-17 | Trough Structure |
| 4 | BH-7111-16 | Cover Bottom Idler |
| 5 | BH-7111-15 | Cover Drive Over |
| 6 | BH-7111-14 | Support Struct Top Idler |
| 7 | BH-7110-33 | RH Angle Support |
| 8 | BH-7110-40 | LH Angle Support |
| 9 | BH-7110-42 | Tubing Bumper |
| 10 | BH-7110-41 | Pipe Bumper |
| 11 | BH-7004-19 | Micro Switch |
| 12 | BH-7111-13 | Angle Switch Support |
| 13 | BH-7111-12 | Cable Support Strap |
| 14 | BH-7111-11 | Channel Cross Over |
| 16 | BH-7100-15 | Cable Assy |
| 16 | BH-7100-06 | Cable Assy |
| 17 | BH-7111-10 | Pin Top Idler |
| 18 | BH-7111-09 | Channel Structure |
| 19 | BH-7111-08 | Chain |
| 20 | BH-7101-06 | Pin |
| 21 | BH-7111-07 | Carriage Assy |
| 22 | BH-7111-06 | Cylinder End Structure |
| 23 | BH-7111-78 | Roller Assy |
| 24 | BH-7100-61 | Hydraulic Cylinder All 5 Models |
| 24 | BH-7100-63 | Hydraulic Cylinder All 7 Models |
| 25 | BH-7100-00C | Retaining Ring |
| 26 | BH-7100-00B | Sheave Pin |
| 27 | BH-7111-05 | Idler Support Struct |
| 28 | BH-7100-00 | Cable Sheave |
| 29 | BH-7006-01 | Power Unit 1PH, 2HP |
| 30 | BH-7512-92 | Shim Kit 150 pcs, 3 sizes |
| 31 | BH-7075-03 | 3/4 x 5-1/2 Wedge Anchor |
| 32 | BH-7111-04 | Post Structure |
| BH-7111-07 | Carriage Assy (#'s 33-48) | |
| 33 | BH-7111-48 | Carriage Structure |
| 34 | BH-7110-03 | Carriage Roller |
| 35 | BH-7111-49 | Retaining Ring 1-3/8 |
| 36 | BH-7102-47 | Latch Assembly |
| 37 | BH-7102-48 | Cam Structure |
| 38 | BH-7111-50 | Pivot Latch Shaft |
| 39 | BH-7100-90 | Torsion Spring |
| 40 | BH-7100-85 | Retaining Ring 1/2 |
| 41 | BH-7102-36 | Lever |
| 42 | BH-7101-24 | Latch Structure |
| 43 | BH-7111-51 | Latch Pin |
| 44 | BH-7100-86 | Retaining Ring 3/8 |
| 45 | BH-7111-52 | Bumper Pad |
| 46 | BH-7606-20 | Carriage Roller Bearing |
| 47 | F-RP-437-2000 | Roll Pin |
| 48 | BH-7102-10 | Shaft |
| 49 | BH-7100-01 | Cable Assy (Floor) |
| 49 | BH-7100-06 | Cable Assy (Overhead) |
| 50 | BH-7111-08 | Chain |
| 51 | BH-7111-20 | LH Track Structure |
| 52 | BH-7111-21 | RH Track Structure |
| 53 | BH-7111-22 | Cover Structure Slip Plate |
| 54 | BH-7107-01 | Slip Plate Retainer Sheet |
| 55 | BH-7107-02 | Ball Bearing - Retainer |
| 56 | F-LN-0500-13 | 1/2-13 Lock Nut |
| 57 | BH-7111-24 | Pin Chain |
| 58 | BH-7111-25 | Leg Structure 30 Long |
| 58 | BH-7111-26 | Leg Structure 24 Long |
| 59 | BH-7101-07 | Pull Pin |
| 60 | BH-7101-08 | Compression Spring |
| 61 | BH-7101-09 | Knob |
| 62 | BH-7111-27 | Front Stop & Chock Structure |
| 63 | BH-7111-28 | Plate Stand |
| 64 | BH-7111-29 | Ramp Structure |
| 65 | BH-7111-30 | Roller |
| 66 | BH-7111-31 | Pin Roller |
| 67 | BH-7111-32 | Bolster |
| 112 | BH-7101-12 | Tube Spacer |
| BH-7111-33 | Turntable Mounting Pkg Ammco/FMC/Hunter/Bee Line | |
| 68 | BH-7111-38 | Spacer Structure / Ammco ... |
| 69 | BH-7111-40 | Adjusting Bar 1/2 / Ammco ... |
| BH-7111-34 | Turntable Mounting Pkg/Bear | |
| 70 | BH-7111-39 | Spacer Structure / Bear |
| 69 | BH-7111-41 | Adjusting Bar 1/2 / Bear |
| 71 | BH-7111-42 | Adjusting Bar 1/8 / Bear |
| BH-7111-35 | Turntable Mounting Pkg / Bender | |
| 69 | BH-7111-43 | Adjusting Bar 1/2 / JH Bender |
| 71 | BH-7111-44 | Adjusitng Bar 1/4 / JH Bender |
| BH-7111-36 | Turntable Mounting Pk/Bishamon | |
| 70 | BH-7111-39 | Spacer Structure / Bishamon |
| 71 | BH-7111-45 | Adjusting Bar 1/4 / Bishamon |
| BH-7111-37 | Turntable Mounting Pkg Snap on | |
| 69 | BH-7111-46 | Adjusting Bar 1/2 Snap-On |
| 71 | BH-7111-47 | Adjusting Bar 1/4 Snap-On |
| 72 | BH-7102-92 | Female Adapter |
| 73 | BH-7111-64 | Pipe Nipple 1/4 x 5 |
| 74 | BH-7102-93 | 90 Elbow |
| 75 | BH-7101-61 | Dry Pressure Gauge |
| 76 | BH-7111-65 | Coupling (MTE Only) |
| 77 | BH-7110-63 | 90 Male Elbow |
| 78 | BH-7111-66 | Tube Assy Upper 1/2 OD |
| 79 | BH-7111-67 | Tube Assy Lower 1/2 OD |
| 80 | BH-7111-72 | Union Tee 3/4-16 JIC |
| 81 | BH-7111-73 | Tube Assy Offside 1/2 OD |
| 82 | BH-7111-74 | Union Connector 3/4-16 JIC |
| 83 | BH-7111-75 | Hose Assy 3/8 ID x 3/4-16 |
| 84 | BH-7111-76 | Hose Clamp Bracket |
| 85 | BH-7111-77 | Hose Clamp |
| 86 | BH-7110-66 | Hex Head Plug |
| 87 | BH-7111-71 | Hex Nipple (MTE Only) |
| 88 | BH-7100-63 | Hydraulic Cylinder |
| 89 | BH-7102-92 | Female Adapter |
| 90 | BH-7111-64 | Pipe Nipple 1/4 x 5 |
| 91 | BH-7102-93 | 90 Elbow |
| 92 | BH-7101-61 | Dry Pressure Gauge |
| 93 | BH-7111-65 | Coupling (MTE Only) |
| 94 | BH-7110-63 | 90 Male Elbow |
| 95 | BH-7111-66 | Tube Assy Upper 1/2 OD |
| 96 | BH-7111-67 | Tube Assy Lower 1/2 OD |
| 97 | BH-7111-68 | 90 Elbow |
| 98 | BH-7111-69 | Tube Union |
| 99 | BH-7111-70 | Hose Assy 3/8 |
| 100 | BH-7110-66 | Hex Head Plug |
| 101 | BH-7100-63 | Hydraulic Cylinder |
| 102 | BH-7111-71 | Hex Nipple (MTE Only) |
| BH-7111-53 | Jacking Channel | |
| BH-7111-54 | Jacking Channel Assy | |
| 103 | BH-7111-55 | Jacking Channel Structure |
| 104 | BH-7111-56 | Spring Support Structure |
| 105 | BH-7111-57 | Roller |
| 106 | BH-7111-58 | Bronze Bushing |
| 107 | BH-7111-59 | Pin |
| 108 | BH-7111-60 | Retaining Ring |
| 109 | BH-7111-61 | Die Spring |
| 110 | BH-7111-62 | Jack Support Structure |
| 111 | BH-7111-63 | Shield |
