AMMCO BEN PEARSON AO MECHANICAL Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7101-46 | Latch Assy. |
| 2 | BH-7075-03 | 3/4 x 5-1/2 Wedge Anchor |
| 3 | BH-7101-36 | Cover Slave Side |
| 4 | BH-7112-55 | Post Offside |
| 5 | BH-7112-54 | Roll Pin |
| 6 | BH-7100-40 | Safety Release Cable |
| 7 | BH-7110-82 | Hex Nut |
| 8 | BH-7110-81 | Tubing, Bumper |
| 9 | BH-7110-80 | Pipe Bumper |
| 10 | BH-7103-26 | LH Angle |
| 11 | BH-7103-25 | End Clips |
| 12 | BH-7110-79 | Bumper Kit |
| 13 | BH-7110-78 | Hex Bolt |
| 14 | BH-7104-06 | Post Extension |
| 15 | BH-7110-76 | Hex Nut |
| 16 | BH-7110-75 | Hex Nut |
| 17 | BH-7110-73 | Hex Screw |
| 18 | BH-7110-70 | Cable Nut |
| 19 | BH-7006-01 | Power Unit 1 PH, 2 HP |
| 20 | BH-7110-38 | Mounting Bracket |
| 21 | BH-7112-53 | Post Pump Side |
| 22 | BH-7100-41 | Release Handle |
| 23 | BH-7101-47 | Cable Clamp |
| 24 | BH-7103-08 | Cable Sear with Nut |
| 25 | BH-7104-06 | Post Extension |
| 26 | BH-7103-13 | Rod Spring |
| 27 | BH-7110-15 | Torsion Spring |
| 28 | BH-7103-14 | Latch Shaft |
| 29 | BH-7104-07 | E-Ring |
| 30 | BH-7101-35 | Cover Pump Side |
| 31 | BH-7100-42 | Safety Release Ball |
| 32 | BH-7110-71 | RH Angle |
| 33 | BH-7104-10 | Retaining Ring |
| 34 | BH-7104-04 | Pulley |
| 35 | BH-7100-19 | Equalizer Cable |
| 36 | BH-7103-23 | Overhead Beam |
| 37 | BH-7104-09 | Idler Shaft |
| 38 | BH-7104-08 | Idler Pulley |
| 39 | BH-7104-07 | E-Ring |
| 40 | BH-7110-01A | Slider Block 4.93 x 1.25 x 1.97 |
| 40 | BH-7110-01 | Slider Block 5 x 1.25 x 1.25 |
| 41 | BH-7112-48 | Carriage |
| 42 | BH-7103-05 | Spring |
| 43 | BH-7103-06 | Threaded Segment |
| 44 | BH-7103-04 | Arm Lock Bar Short |
| 45 | BH-7102-12 | Nylock Nut |
| 46 | BH-7110-48 | Hex Screw |
| 47 | BH-7112-56 | RH Arm |
| 48 | BH-7110-46 | Arm Extension 7000# |
| 49 | BH-7101-03 | Extension 5 |
| 50 | BH-7101-02 | Extension 2-5/8 |
| 51 | BH-7112-49 | Arm Extension 9000# |
| 52 | BH-7112-50 | LH Arm |
| 53 | BH-7101-01 | Steel Adapter |
| 54 | BH-7101-00 | Rubber Pad |
| 55 | F-HC-0312-18-0750 | Hex Screw |
| 55 | F-FW-0375-SAE | Flat Washer |
| 56 | BH-7102-76 | Protector Strip |
| 57 | BH-7110-53 | Pin |
| 58 | BH-7100-19 | Equalizer Cable AO Series |
| 58 | BH-7112-57 | Equalizer Cable AO-S Series |
| 59 | BH-7110-70 | Hex Nut |
| 60 | BH-7100-35 | Equalizer Cable AF Series |
| 61 | BH-7103-07 | Retaining Ring |
| BH-7101-01C | Adapter Base and Pad Assy. Consists of items 53, 54 & 55 | |
| 62 | BH-7102-90 | Hose Assembly |
| 63 | BH-7110-60 | Hex Screw |
| 64 | BH-7110-61 | Lock Nut |
| 65 | BH-7110-92 | Hose Assembly |
| 66 | BH-7102-89 | Hose Assembly |
| 67 | BH-7110-65 | Bulkhead Tee w/Nut |
| 68 | BH-7110-66 | Plug |
| 69 | BH-7110-67 | Ty-Wrap |
| 70 | BH-7110-68 | Grommet |
| 71 | BH-7100-62 | Hydraulic Cylinder |
| 72 | BH-7110-60 | Hex Screw |
| 73 | BH-7110-93 | Mounting Bracket |
| 74 | BH-7110-94 | Hex Screw |
| 75 | BH-7110-95 | Single Phase Switch Box |
| 76 | BH-7110-96 | Strain Relief Bushing |
| 77 | BH-7110-97 | Three Phase Box Cover |
| 78 | BH-7004-19 | 1 PH Microswitch |
| 79 | BH-7110-98 | Single Phase Box Cover |
| 80 | BH-7110-99 | Three Phase Switch Box |
