AMMCO BEN PEARSON AL-7 NEW STYLE Parts Breakdown





Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7106-02 Cable, Long
1 BH-7106-01 Cable, Short
2 BH-7104-05 Lock Latch Only
3 BH-7101-46 Lock Latch Kit
4 BH-7075-03 3/4 x 5-1/2 Anchor Bolt
5 BH-7101-36 Guard, Offside
6 BH-7110-44 Post, Offside
7 BH-7100-40 Safety Release Cable Assy.
8 BH-7110-82 Nut, Hex 1/2 Washer Head
9 BH-7110-81 Tubing, Bumper
10 BH-7110-80 Pipe, Bumper
11 BH-7103-26 LH Bracket
12 BH-7103-25 End Clips
13 BH-7110-79 Kit, Bumper
14 BH-7110-78 Screw, Hex 1/2 Washer Head
15 BH-7110-36 Extension, Post Offside
16 BH-7110-76 Nut, Hex 3/8 Self Locking
17 BH-7110-75 Nut, Hex 5/16 Self Locking
18 BH-7110-74 Screw, 3/8 Washer Head
19 BH-7110-73 Screw, Hex 5/16
20 BH-7006-01 Power Unit 1PH, 2HP
20 BH-7006-03 Power Unit 3PH, 2HP
21 BH-7110-38 Mounting Bracket
22 BH-7110-37 Post, Pump Side
23 BH-7100-41 Safety Release Handle
24 BH-7101-47 Clamp for Lock Release Cable
25 BH-7103-08 Cable Sear
26 BH-7110-39 Extension, Post Pump Side
27 BH-7103-13 Rod, Spring
28 BH-7110-15 Torsion Spring
29 BH-7103-14 Latch Shaft
30 BH-7100-88 Retaining Ring
31 BH-7101-35 Cover, Pump Side
32 BH-7100-42 Safety Release Ball for Lever
33 BH-7110-71 RH Angle
34 BH-7104-10 Retaining Ring
35 BH-7104-04 Pulley
36 BH-7103-24 Bumper Assy.
37 BH-7106-01 Cable Short
37 BH-7103-10 Cable Short AL-7S
38 BH-7110-70 Cable Nut
39 BH-7103-23 Overhead Beam
40 BH-7106-06 Idler Pulley
41 BH-7104-09 Pulley Shaft
42 BH-7104-08 Idler Pulley
43 BH-7110-69 E-Ring
44 BH-7110-01A Slider Block
45 BH-7110-83 Carriage, Pump Side
46 BH-7103-06 Threaded Segment
47 BH-7103-04 Arm Lock Bar - Short
48 BH-7103-05 Spring
49 BH-7110-46 Arm Extension, Rear
50 BH-7101-02 Extension, 2-5/8
51 BH-7110-47 Arm Extension, Short
52 BH-7110-48 Screw, Hex 3/8 x 1-3/8
53 BH-7101-03 Extension, 5
54 BH-7101-01 Steel Adapter Only
54 BH-7101-01C Steel Adapter & Pad Assy.
55 BH-7101-00 Rubber Arm Pad
55 BH-7101-00-4 Rubber Arm Pad Kit (set of 4)
56 F-HC-0312-18-0750 Capscrew, 5/16 x 3/4
56 F-FW-0375-SAE Flat Washer
57 BH-7110-86 Arm, Front Pump Side
58 BH-7103-03 Arm Lock Bar - Long
59 F-NL-0375-16 Nylock Nut, 3/8
60 BH-7102-76 Guard, Door
61 BH-7110-53 Pin
62 BH-7106-02 Cable, Long
63 BH-7110-70 Hex Nut
64 BH-7106-01 Cable Short
65 BH-7110-87 Carriage, Off Side
66 BH-7110-88 Arm, Rear Pump Side
67 BH-7110-89 Arm, Front Off Side
68 BH-7110-90 Arm, Rear Off Side
69 BH-7103-07 Retaining Ring
70 BH-7111-00 Pad Assy. Pump Side
70 BH-7111-01 Pad Assy. Off Side
71 BH-7101-43 Rubber Pad
72 BH-7111-02 Self Tapping Screw
73 BH-7111-03 Rubber Molding
74 BH-7110-91 Hose Assembly
75 BH-7110-60 Hex Screw
76 BH-7110-61 Locknut
77 BH-7110-92 Hose Assembly
78 BH-7102-89 Hose Assembly
79 BH-7110-65 Tee, Bulkhead w/Nut
80 BH-7110-66 Plug
81 BH-7110-67 Ty-Wrap
82 BH-7110-68 Grommet
83 BH-7100-62 Cylinder
84 BH-7110-60 Hex Screw
85 BH-7110-93 Mounting Bracket
86 BH-7110-94 Hex Screw
87 BH-7110-95 Switch Box Single Phase
88 BH-7110-96 Strain Relief Bushing
89 BH-7110-97 Box Cover Three Phase
90 BH-7004-19 Microswitch
91 BH-7110-98 Box Cover Single Phase
92 BH-7110-99 Switch Box Three Phase
