AMMCO BEN PEARSON 9000 FC Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | BH-7116-15 | Crossover Structure |
| 2 | BH-7116-16 | Anchor Bolt 3/8 x 3-3/4 |
| 3 | BH-7116-17 | Actuator Cable |
| 4 | BH-7116-26 | Equalizer Cable 28' 2-3/8 |
| 5 | BH-7116-29 | Arm Structure |
| 6 | BH-7116-30 | Arm Extension Structure |
| 7 | BH-7101-14 | Flatwasher 3/8 |
| 8 | BH-7116-31 | Self Tapping Screw |
| 9 | BH-7116-32 | Lift Pad Assembly |
| 9 | BH-7116-33 | Lift Pad Structure |
| 10 | BH-7116-34 | Bolt On Lift Pad |
| 11 | BH-7116-35 | Self Locking Screw |
| 12 | BH-7116-36 | 2-5/8 Lift Pad Extension |
| 13 | BH-7116-37 | 5 Lift Pad Extension |
| 14 | BH-7116-02 | RH Post Structure |
| 15 | BH-7116-03 | LH Post Structure |
| 16 | BH-7116-11 | Mount Sheave Upper |
| 17 | F-HC-0375-16-3500 | Hex Head Cap Screw 3/8-16 x 3-1/2 |
| 18 | BH-7116-13 | Bar Tie |
| 19 | BH-7110-74 | Washer Head Screw |
| 20 | BH-7110-76 | Self Locking Hex Nut |
| 21 | BH-7006-01 | 2 HP, 1PH Power Unit |
| 22 | BH-7110-73 | Hex Screw 5/16 |
| 23 | BH-7110-75 | Self Locking Hex Nut 5/16 |
| 24 | BH-7116-06 | Sheave Assembly |
| 25 | BH-7116-08 | Sheave |
| 26 | BH-7116-09 | Snap Ring 3/4 |
| 27 | BH-7116-10 | Flatwasher 3/4 |
| 28 | BH-7116-07 | Overhead Sheave Shaft Structure |
| 29 | BH-7075-03 | 3/4 x 5-1/2 Wedge Anchor |
| 30 | BH-7512-92 | Shim Kit 150 pcs, 3 sizes |
| 31 | BH-7116-18 | RH Carriage Latch |
| 32 | BH-7116-19 | LH Carriage Latch |
| BH-7116-20 | Carriage Stop Handle | |
| 33 | BH-7116-10 | Flat Washer 3/4 |
| BH-7205-21 | Handle Ball | |
| 34 | BH-7116-22 | Carriage Stop Pivot Pin |
| 35 | BH-7116-09 | Snap Ring 3/4 |
| 36 | BH-7116-23 | Carriage Stop Torsion Spring |
| 37 | BH-7116-24 | Latch Cover Power Unit Side |
| 38 | BH-7116-25 | Latch Cover Offside |
| 39 | BH-7116-38 | Arm Pin Structure |
| 40 | BH-7116-45 | Arm Restraint Gear |
| 41 | BH-7116-46 | Capscrew 3/8 x 1 |
| 42 | BH-7116-60 | Four Way Cable Tie |
| 43 | BH-7116-61 | Tie Wrap |
| 44 | BH-7116-04 | Carriage Structure |
| 45 | BH-7106-07 | Bearing Block (Slider Block) |
| 46 | BH-7116-39 | Arm Restraint Shaft |
| 47 | F-RP-250-2500 | Roll Pin |
| 48 | BH-7116-44 | Snap Ring 1 |
| 49 | BH-7116-41 | Arm Restraint Actuating Spring |
| 50 | F-RP-0187-500 | Roll Pin |
| 51 | BH-7116-47 | Capscrew 5/16 x 3/4 |
| 52 | BH-7101-50 | Flatwasher 1 |
| 53 | BH-7116-48 | Flatwasher 5/16 |
| 54 | BH-7116-40 | Locking Gear |
| 55 | BH-7116-49 | Cylinder Assembly |
| 56 | BH-7116-58 | Swivel Nut Run Tee |
| 57 | BH-7116-57 | Straight Thread Elbow |
| 58 | BH-7116-56 | Hydraulic Line |
| 59 | BH-7116-55 | Hydraulic Line |
| 60 | BH-7116-54 | Hydraulic Line |
| 61 | BH-7116-51 | Tube Union |
| 62 | BH-7116-52 | Hydraulic Line |
| 63 | BH-7116-53 | Hydraulic Line |
| 64 | BH-7116-50 | Straight Connector |
| 65 | BH-7116-59 | Union Elbow |
