ALM Epoch 6000 Parts Breakdown


Click on the part number for more information

ITEM PART NO DESCRIPTION
ITEM PART NO DESCRIPTION
1 BH-7156-07 Hex Nut
2 F-MS-0004-40-0500 Machine Screw 4-40 x 1/2
3 F-LW-0004 Split Lockwasher
4 F-MS-0004-40-0500 Machine Screw 4-40 x 1/2
5 BH-7156-03 Potentiometer Meter Plate
6 F-LW-0375 Split Lockwasher
7 F-MS-0008-32-0375 Machine Screw 8-32 x 3/8
8 BH-7156-00 Linear Potentiometer
9 BH-7155-99 Quick Disconnect Coupler
10 BH-7155-98 Hydraulic Hose Assy 13' 5-7/8
11 BH-7155-97 Hydraulic Hose Assy 15' 11-7/8
12 BH-7155-96 Street Elbow 1/4
13 F-JN-0750-10 Hex Jam Nut 3/4-10
14 F-HC-0750-10-4000 Hex Bolt 3/4-10 x 4
15 BH-7153-70 Security Locknut 1/4-20
16 F-HC-0250-20-1750 Hex Bolt 1/4-20 x 1-3/4
17 BH-7155-92 Toe Guard Spring
18 BH-7155-91 Toe Guard Extension
19 BH-7155-90 Toe Guard Assy
20 BH-7155-89 Toe Guard Mounting Assy
21 BH-7075-03L 3/4 x 5-1/2 Wedge Anchor
22 F-FW-0250-SAE Plain Washer 1/4
23 BH-7155-88 Guide Strip
24 F-LW-0312 Split Lockwasher 5/16
25 F-HC-0312-18-0750 Hex Bolt 5/16-18 x 3/4
26 BH-7155-86 Keeper Key
27 BH-7155-85 Hinge Pin
28 BH-7155-84 Hinge Pin
29 F-LW-0250 Split Lockwasher 1/4
30 F-HC-0250-20-0500 Hex Bolt 1/4-20 x 1/2
31 BH-7155-83 Keeper Plate
32 BH-7155-82 Self Tapping Zerk Fitting
33 BH-7155-81 Roller Axle
34 BH-7155-80 Hinge Roller
35 BH-7155-79 Security Locknut 1-1/4-7
36 F-FW-1250-USS 1-1/4 Plain Washer
37 BH-7155-77 Center Pin
38 F-CP-187-2000 Cotter Pin 3/16 x 2
39 BH-7155-76 Spacer
40 BH-7155-75 Upper Cylinder Pin
41 BH-7155-74 Lower Cylinder Pin
42 BH-7155-73 Safety Dog Assy
43 BH-7155-72 Safety Bracket Assy
44 BH-7155-71 Cylinder Assy
45 BH-7155-70 Outside Upper Hinge Assy
46 BH-7155-69 Outside Lower Hinge Assy
47 BH-7155-68 Inside Upper Hinge Assy
48 BH-7155-67 Inside Lower Hinge Assy
49 BH-7155-66 Top Frame w/Extension
50 BH-7155-65 Base Weldment
51 BH-7156-45 External Tooth Lockwasher
52 BH-7156-44 Machine Screw 10-32 x 3/8
53 BH-7156-43 Machine Screw 10-24 x 1/2
54 F-LW-0375 Split Lockwasher
55 BH-7156-41 Machine Screw 10-24 x 3/8
56 F-HN-0006-32 Hex Nut 6-32
57 F-LW-0006 Split Lockwasher
58 BH-7156-38 Machine Screw 6-32 x 1-1/8
59 F-HN-0312-18 Hex Nut 5/16-18
60 F-FW-0312-SAE 5/16 Plain Washer
61 BH-7156-37 Hex Bolt 5/16-18 x 7/8
62 F-HC-0250-20-0875 Hex Bolt 1/4-20 x 7/8
63 BH-7156-36 Grommet
64 BH-7156-35 Quick Disconnect Coupler
65 BH-7156-34 Hex Pipe Nipple 1/4x1/4 MNPT
66 BH-7156-33 Front Cover
67 BH-7154-72 Bulkhead Fitting 1/4 x 1/4 NPT
68 BH-7154-11 Pneumatic Tubing 1/4 x 51
69 BH-7151-55 Tee 5/32 x 5/32 x 5/32
70 BH-7156-32  Pneumatic Tubing 5/32 x 180
71 BH-7156-31 Male Elbow 1/4 x 1/8 NPT
72 BH-7152-25 Elbow 5/32 to 1/8 NPT
73 BH-7156-30 Female Tee 1/8 NPT
74 BH-7156-29 Bell Reducer 1/4 x 1/8
75 BH-7156-28 Close Nipple 1/8 NPT
76 BH-7156-27 Pressure Switch
77 BH-7156-26 Air Valve
78 BH-7156-25 10 AMP Fuse
79 BH-7156-24 1/2 AMP Fuse
80 BH-7156-23 Fuse Block
81 BH-7156-22 Transformer
82 BH-7156-21 Contactor
83 BH-7156-20 Computer
84 BH-7156-19 Control Panel Plate
85 BH-7156-18 2 HP Pump
86 BH-7156-17 Pedestal Weldment
87 BH-7156-16 Box & Pedestal Weldment
88 BH-7153-90 Wire Tie
89 BH-7156-15 Lift Pad Assy
90 F-JN-0010-32 Hex Jam Nut 10-32
91 F-MS-0010-32-0500 Machine Screw 10-32 x 1/2
92 BH-7156-12 Pneumatic Tubing 5/32 x 144
93 BH-7156-11 Tube Elbow 5/32 x 10/32 NPT
94 BH-7156-10 High Collar Lockwasher
95 F-HC-0006-32-0750 Cap Screw 6-32 x 3/4
96 BH-7156-08 Air Cylinder
97 BH-7156-46 Female Stand-Off 10-32
98 F-HN-0008-32 Hex Nut 8-32
99 F-MS-0006-32-0500 Machine Screw 6-32 x 1/2
100 BH-7074-51 5/8 x 4-3/4 Wedge Anchor
101 BH-7156-49 Raise Push Button
102 BH-7156-50 Lower Push Button
103 BH-7156-51 Park Push Button
104 BH-7156-52 Push/Pull Switch
