ALM 25000 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | F-NL-0312-18 | Nylock Locknut 5/16-18 |
| 2 | BH-7155-37 | Lift Chain 201 |
| 3 | BH-7155-38 | Connecting Link Assy |
| 4 | BH-7155-39 | Chain Dead End |
| 5 | F-FW-1125-USS | Plain Washer 1-1/8 |
| 6 | BH-7155-41 | Security Locknut 1-1/8-12 |
| 7 | BH-7155-42 | RH Safety Dog Assy |
| 8 | BH-7155-43 | LH Safety Dog Assy |
| 9 | F-HC-1000-14-5500 | Hex Bolt 1-14 x 5-1/2 |
| 10 | BH-7155-45 | Safety Block Spacer |
| 11 | BH-7155-46 | Security Locknut Thin 1-14 |
| 12 | F-HC-0750-10-4500 | Hex Bolt 3/4-10 x 4-1/2 |
| 13 | F-LN-0750-10 | Nylock Locknut 3/4-10 |
| 14 | BH-7151-53 | Air Cylinder |
| 15 | BH-7151-26 | Lockwasher 5/8 |
| 16 | BH-7155-48 | Safety Dog Release Bracket |
| 17 | BH-7151-15 | Hex Jam Nut 1/4-28 |
| 18 | F-FW-0375-SAE | Plain Washer 3/8 |
| 19 | BH-7154-06 | Hair Cotter Pin 1/2 |
| 20 | BH-7152-25 | Elbow 5/32 to 1/8 NPT |
| 21 | BH-7155-49 | Pneumatic Tubing 5/32 x 6 |
| 22 | BH-7153-97 | Male Running Tee |
| 23 | BH-7155-50 | Pneumatic Tubing 5/32 x 109 |
| 24 | BH-7153-86 | Pipe Swivel Adapter 1/8 NPT |
| 25 | BH-7155-51 | Air Hose Assy |
| 26 | BH-7155-52 | Air Hose Assy |
| 27 | BH-7154-01 | Male Air Hose Fitting 5/32x1/8 |
| 28 | BH-7155-53 | Pneumatic Tubing 5/32 x 276 |
| 29 | BH-7155-54 | Branch Tee 5/32 Hose x 1/8 |
| 30 | BH-7155-55 | Pneumatic Tubing 5/32 x 36 |
| 31 | BH-7153-99 | Plug In Elbow 5/32 to 5/32 |
| 32 | BH-7155-56 | Male Air Hose Elbow 5/32 - 1/4 |
| 33 | BH-7151-28 | Air Valve |
| 34 | BH-7153-98 | Hex Bolt 1/4-20 x 1 |
| 35 | F-LW-0250 | Split Lockwasher 1/4 |
| 36 | F-HN-0250-20 | Hex Nut 1/4-20 |
| 37 | BH-7155-57 | Front Wheel Stop |
| 38 | BH-7155-58 | Ramp Weldment |
| 39 | F-HC-0750-10-2500 | Hex Bolt 3/4-10 x 2-1/2 |
| 40 | F-HN-0750-10 | Hex Nut 3/4-10 |
| 41 | F-HC-0500-13-2250 | Hex Bolt 1/2-13 x 2-1/4 |
| 42 | BH-7150-80 | Plain Washer 1/2 |
| 43 | F-LW-0500 | Split Lockwasher 1/2 |
| 44 | F-HN-0500-13 | Hex Nut 1/2-13 |
| 45 | BH-7155-11 | Track Spacer |
| 46 | F-HC-0375-16-1000 | Hex Bolt 3/8-16 x 1 |
| 47 | F-LW-0375 | Split Washer 3/8 |
| 48 | F-HN-0375-16 | Hex Nut 3/8-16 |
| 49 | F-FW-0312-SAE | Plain Washer 5/16 |
| 50 | F-LW-0312 | Split Lockwasher 5/16 |
| 51 | F-HN-0312-18 | Hex Nut 5/16-18 |
| 52 | BH-7075-03L | 3/4 X 5-1/2 Wedge Anchor |
| 53 | BH-7155-62 | Rear Wheel Chock |
| 54 | BH-7155-63 | Hose Tie Mounting Clip |
| 55 | BH-7153-90 | Wire Tie 5-/12 |
| 56 | BH-7155-64 | Hydraulic Hose Support Pad |
| 57 | BH-7155-12 | Front Drive Column Assy |
| 58 | BH-7155-13 | Rear Pump Mounting Column |
| 59 | BH-7155-14 | Idle Side Column |
| 60 | BH-7155-15 | Track Weldment |
| 61 | BH-7155-16 | Front Crosstube Weldment |
| 62 | BH-7155-17 | Rear Crosstube Weldment |
| 63 | BH-7155-18 | Cylinder Tube Weldment |
| 64 | BH-7155-19 | Hydraulic Unit 4 HP 8 Gal. |
| 65 | BH-7155-20 | Hydraulic Cylinder |
| 66 | BH-7155-21 | Hydraulic Cylinder Mounting Pin |
| 67 | F-CP-187-2000 | Cotter Pin 3/16 x 2 |
| 69 | BH-7151-34 | Hex Pipe Nipple 1/4 - 3/8 |
| 70 | BH-7153-37 | Female Elbow 3/8 x 1/4 |
| 71 | BH-7155-22 | Hydraulic Hose Assy |
| 72 | BH-7155-23 | Female Elbow 3/8 NPT |
| 73 | BH-7155-24 | Nipple 3/8 NPT x 2-1/2 |
| 74 | BH-7155-25 | Chain Sheave Assy |
| 75 | BH-7155-26 | Hex Bolt 3/4-10 x 7 |
| 76 | F-LN-0750-10 | Nylock Locknut 3/4-10 |
| 77 | BH-7155-27 | Chain Dead End |
| 78 | BH-7155-28 | Lifting Chain 91 |
| 79 | BH-7155-29 | Lifting Chain 325 |
| 80 | BH-7155-30 | Capscrew 3/8-24 x 5-3/4 |
| 81 | BH-7155-31 | Security Locknut 3/8-24 |
| 82 | BH-7155-32 | Chain Dead End |
| 83 | BH-7155-33 | Capscrew 3/8-24 x 5 |
| 84 | BH-7155-34 | Security Locknut 3/8-24 |
| 85 | BH-7155-35 | Shoulder Screw 3/4 x 2 |
