ALM 12001 Parts Breakdown
Click on the part number for more information
| ITEM | PART NO | DESCRIPTION |
|---|---|---|
| ITEM | PART NO | DESCRIPTION |
| 1 | Call For Details | Column |
| 2 | Call For Details | Column |
| 3 | F-HC-0375-16-1250 | Hex Bolt 3/8-16 x 1-1/4 |
| 4 | F-HC-0375-16-1000 | Hex Bolt 3/8-16 x 1 |
| 5 | F-FW-0375-SAE | Washer 3/8 |
| 6 | F-LW-0375 | Split Lockwasher 3/8 |
| 7 | F-FW-0250-SAE | Washer 1/4 |
| 8 | Call For Details | Corner Assembly |
| 9 | F-CP-187-1750 | Cotter Pin 3/16 x 1-3/4 |
| 10 | BH-7151-21 | Sheave Axle |
| 11 | BH-7157-51 | Column Extension |
| 12 | Call For Details | Overhead Weldment |
| 13 | BH-7050-01 | Safety Cable |
| 14 | Call For Details | Spacer |
| 15 | BH-7152-05 | Air Release Valve |
| 16 | BH-7151-22 | Cable Sheave 5 |
| 17 | BH-7151-36 | 90 Fitting |
| 18 | F-SS-0375-16-1500 | Dog Point Set Screw 3/8-16 x 1-1/ |
| 19 | BH-7151-33 | Coupling |
| 20 | BH-7151-11 | End Cap |
| 21 | BH-7151-12 | Spring |
| 22 | F-HN-0375-16 | Hex Nut 3/8-16 |
| 23 | F-HN-0375-16 | Hex Nut 3/8-16 |
| 24 | BH-7150-80 | Washer |
| 25 | BH-7157-28 | Hydraulic Cylinder |
| BH-7151-52 | Seal Kit for some 12000-2 Post | |
| 26 | BH-7152-06 | Air Cylinder |
| 27 | BH-7006-01 | Hyd. Power Unit 1PH |
| BH-7006-03 | Hyd. Power Unit 3PH | |
| 28 | BH-7151-26 | Lockwasher |
| 29 | BH-7150-17 | Equalizer Cable |
| 30 | BH-7152-25 | Male Elbow |
| 31 | Call For Details | Carriage |
| 32 | F-FW-0875-USS | Plain Washer 7/8 |
| 33 | BH-7150-14 | Slider Block |
| 34 | BH-7151-16 | Bracket |
| 35 | BH-7151-22 | Cable Pulley 5 |
| 36 | BH-7151-13 | Arm Restraint Plunger |
| 37 | BH-7152-07 | Bracket |
| 38 | F-NL-0500-13 | Nylock Locknut 1/2-13 |
| 39 | BH-7075-03 | 3/4 x 5-1/2 Wedge Anchor |
| 40 | BH-7157-16 | 3/4 Retaining Ring |
| 41 | BH-7150-20A | Sheave Axle |
| 42 | BH-7153-51 | Keeper Plate |
| 43 | F-LW-0250 | Split Lockwasher 1/4 |
| 44 | BH-7153-90 | Wire Tie |
| 45 | BH-7154-03 | Arm Pin |
| 46 | BH-7153-77 | 1-1/2 Snap Ring |
| 47 | BH-7154-06 | LH Arm Assembly |
| 48 | BH-7150-02 | Rubber Pad |
| 49 | BH-7154-07 | Lift Pad Assembly |
| 50 | F-RP-250-1750 | Roll Pin 1/4 x 1-3/4 |
| 51 | BH-7151-63 | Left Front Arm |
| 52 | Call For Details | Adapter |
| 53 | BH-7151-14 | Housing |
| 54 | F-HC-0375-10-30004 | Hex Bolt 3/4-10 x 3 |
| 55 | BH-7151-06 | Arm Lock Rod |
| 56 | BH-7151-17 | Cotter Key |
| 57 | BH-7151-18 | Washer |
| 58 | F-HC-0250-20-1500 | Hex Bolt 1/4-20 x 1-1/2 |
| 59 | Call For Details | Air Line Tubing |
